  • Page 2: Contact Information

    Contact Information If you need to contact ASRock or want to know more about ASRock, you’re welcome to visit ASRock’s website at http://www.asrock.com; or you may contact your dealer for further information. For technical questions, please submit a support request form at https://event.asrock.com/tsd.asp ASRock Incorporation e-mail: info@asrock.com.tw...

  • Page 3: Table Of Contents

    Package Contents Specifications Motherboard Layout I/O Panel Block Diagram 802.11axe Wi-Fi 6E Module and ASRock WiFi 2.4/5/6 GHz Antennas (For A620AM Pro RS WiFi) Chapter 2 Installation Installing the CPU Installing the CPU Fan and Heatsink Installing Memory Modules (DIMM)
  • Page 4 2.14 Post Status Checker 2.15 M.2 2230 WiFi/BT PCIe WiFi module Installatio Guide (A620AM Pro RS) 2.16 M.2 SSD Installation Guide (M2_1) 2.17 M.2 SSD Installation Guide (M2_2) 2.18 M.2 SSD Installation Guide (M2_3)

  • Page 5: Chapter 1 Introduction

    ASRock’s website without further notice. If you require technical support related to this motherboard, please visit our website for specific information about the model you are using. You may find the latest VGA cards and CPU support list on ASRock’s website as well. ASRock website http://www.asrock.com.

  • Page 6: Specifications

    • Supports AMD Socket AM5 Ryzen 9000, 8000 and 7000 Series Processors* * Please refer to CPU Support List on ASRock's website for more information. (http://www.asrock.com/) * The availability of expansion slots may vary by CPU. Please refer to PCIe/M.2 Bandwidth Table for details. (http://www.
  • Page 7 A620AM Pro RS WiFi A620AM Pro RS • 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz • 1 x DisplayPort 1.4 with DSC (compressed), supports HDCP 2.3 and max. resolution up to 4K 120Hz • 7.1 CH HD Audio (Realtek ALC897 Audio Codec)
  • Page 8 • 8 x USB 2.0 (4 Rear, 4 Front) * All USB ports support ESD Protection Rear Panel • 2 x Antenna Ports (For A620AM Pro RS WiFi) • 2 x Antenna Mounting Points (For A620AM Pro RS) • 1 x HDMI Port • 1 x DisplayPort 1.4...
  • Page 9 • ErP/EuP ready (ErP/EuP ready power supply is required) * For detailed product information, please visit our website: http://www.asrock.com Please realize that there is a certain risk involved with overclocking, including adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using third-party overclocking tools.

  • Page 10: Motherboard Layout

    1.3 Motherboard Layout CPU_FAN2 CPU_FAN1 AIO_PUMP ATX12V1 BIOS _FB1 DRAM BOOT USB 3.2 Gen1: T: USB32_1 B: USB32_TC1 USB 2.0: T: USB_2 B: USB_1 USB 2.0: T: USB_4 B: USB_3 USB 3.2 Gen1 Top: T: USB32_3 LAN1 B: USB32_2 PCIE1 SPI_TPM_J1 CMOS BIOS...
  • Page 11 A620AM Pro RS WiFi A620AM Pro RS No. Description ATX 12V Power Connector (ATX12V1) CPU Fan Connector (CPU_FAN1) 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1) 2 x 288-pin DDR5 DIMM Slots (DDR5_A2, DDR5_B2) CPU Fan Connector (CPU_FAN2) AIO Pump Fan Connector (AIO_PUMP)

  • Page 12: I/O Panel

    1.4 I/O Panel A620AM Pro RS WiFi: No. Description No. Description 2.5G LAN RJ-45 Port* USB 3.2 Gen1 Type-A Port (USB32_1) Line In (Light Blue)** USB 3.2 Gen1 Type-C Port (USB32_TC1) Front Speaker (Lime)** DisplayPort 1.4 Microphone (Pink)** HDMI Port USB 3.2 Gen1 Type-A Ports (USB32_23) 12...
  • Page 13 A620AM Pro RS WiFi A620AM Pro RS * There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port Activity / Link LED Speed LED...

  • Page 14: Block Diagram

    1.5 Block Diagram...

  • Page 15: 802.11Axe Wi-Fi 6E Module And Asrock Wifi 2.4/5/6 Ghz Antennas (For A620Am Pro Rs Wifi)

    A620AM Pro RS WiFi A620AM Pro RS 1.6 802.11axe Wi-Fi 6E Module and ASRock WiFi 2.4/5/6 GHz Antennas (For A620AM Pro RS WiFi) 802.11axe Wi-Fi 6E + BT Module This motherboard comes with an exclusive 802.11 a/b/g/n/ac/ax/axe Wi-Fi 6E + BT v5.2 module that offers support for 802.11 a/b/g/n/ac/ax/axe Wi-Fi 6E connectivity...
  • Page 16 WiFi Antennas Installation Guide Step 1 Prepare the WiFi 2.4/5/6 GHz Antennas that come with the package. Step 2 Connect the two WiFi 2.4/5/6 GHz Antennas to the antenna connectors. Turn the antenna clockwise until it is securely connected. Step 3 Set the WiFi 2.4/5/6 GHz Antenna as shown in the illustration.

  • Page 17: Chapter 2 Installation

    A620AM Pro RS WiFi A620AM Pro RS Chapter 2 Installation This is a Micro ATX form factor motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it. Pre-installation Precautions Take note of the following precautions before you install motherboard components or change any motherboard settings.

  • Page 18: Installing The Cpu

    2.1 Installing the CPU 1. Before you insert the 1718-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 19 A620AM Pro RS WiFi A620AM Pro RS Carefully place the CPU in as flat as possible. Do not drop it.
  • Page 20 Make sure the CPU is aligned with the socket before locking it into place. Make sure the black cover plate is always in place until it pops off when closing the socket lever. Please save the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.

  • Page 21: Installing The Cpu Fan And Heatsink

    A620AM Pro RS WiFi A620AM Pro RS 2.2 Installing the CPU Fan and Heatsink After you install the CPU into this motherboard, it is necessary to install a larger heatsink and cooling fan to dissipate heat. You also need to apply thermal paste between the CPU and the heatsink to improve heat dissipation.
  • Page 23 A620AM Pro RS WiFi A620AM Pro RS Installing the CPU Cooler (Type 2)
  • Page 25 A620AM Pro RS WiFi A620AM Pro RS +12V *The illustrations shown here are for reference purposes only and may not exactly match the model you purchase.
  • Page 26 Installing the CPU Cooler (Type 3)
  • Page 27 A620AM Pro RS WiFi A620AM Pro RS...
  • Page 29 +12V Please note that only one cable should be used at a time in this step. If you select RGB_LED1, please install ASRock utility "ASRock Polychrome SYNC". If you select USB connector, please install AMD utility "SR3 Settings Software". *The illustrations shown here are for reference purposes only and may not exactly match...

  • Page 30: Installing Memory Modules (Dimm)

    2.3 Installing Memory Modules (DIMM) This motherboard provides four 288-pin DDR5 (Double Data Rate 5) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, you always need to install identical (the same brand, speed, size and chip-type) DDR5 DIMM pairs. 2.
  • Page 31 A620AM Pro RS WiFi A620AM Pro RS...

  • Page 32: Connecting The Front Panel Header

    2.4 Connecting the Front Panel Header Power SW (-) RESET SW (+) Power SW (+) RESET SW (-) Power LED (-) HDD LED (-) Power LED (+) HDD LED (+) PANEL1...

  • Page 33: Installing The Motherboard

    A620AM Pro RS WiFi A620AM Pro RS 2.5 Installing the Motherboard...

  • Page 34: Installing Sata Drives

    2.6 Installing SATA Drives Optical Drive SATA Drive SATA Data Cable...
  • Page 35 A620AM Pro RS WiFi A620AM Pro RS SATA Power Connector SATA Data Connector...

  • Page 36: Installing A Graphics Card

    2.7 Installing a Graphics Card CLICK!
  • Page 37 A620AM Pro RS WiFi A620AM Pro RS Expansion Slots (PCIe Slots) There are 2 PCI Express slot on the motherboard. Before installing an expansion card, please make sure that the power supply is switched off or the power cord is unplugged. Please read the documentation of the expansion card and make necessary hardware settings for the card before you start the installation.

  • Page 38: Connecting Peripheral Devices

    2.8 Connecting Peripheral Devices...

  • Page 39: Connecting The Power Connectors

    A620AM Pro RS WiFi A620AM Pro RS 2.9 Connecting the Power Connectors...

  • Page 40: Power On

    2.10 Power On...

  • Page 41: Jumpers Setup

    A620AM Pro RS WiFi A620AM Pro RS 2.11 Jumpers Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”.

  • Page 42: Onboard Headers And Connectors

    2.12 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header (9-pin PANEL1) (see p.6, No.
  • Page 43 A620AM Pro RS WiFi A620AM Pro RS Power LED and Speaker Header (7-pin SPK_PLED1) (see p.6, No. 17) Please connect the chassis power LED and the chassis speaker to this header. SPK_PLED1 SPEAKER DUMMY DUMMY PLED+ PLED+ PLED- Serial ATA3 Connectors Vertical: (SATA3_1) (see p.6, No.
  • Page 44 USB 2.0 Headers (9-pin USB_5_6) (see p.6, No. 19) (9-pin USB_7_8) (see p.6, No. 20) There are two headers on this motherboard. Each USB 2.0 header can support two ports. USB_7_8 USB_PWR DUMMY USB_PWR USB_5_6 USB_PWR DUMMY USB_PWR USB 3.2 Gen1 Header (19-pin USB32_4_5) (see p.6, No.
  • Page 45 A620AM Pro RS WiFi A620AM Pro RS Front Panel Type C USB 3.2 Gen1 Header (20-pin USB32_TC2) (see p.6, No. 13) There is one Front Panel Type C USB 3.2 Gen1 Header on this motherboard. This header is used for connecting a USB 3.2 Gen1 module for additional USB 3.2 Gen1 ports.
  • Page 46 Chassis Fan Connectors (4-pin CHA_FAN1) (see p.6, No. 21) (4-pin CHA_FAN2) (see p.6, No. 22) (4-pin CHA_FAN3) (see p.6, No. 26) These headers allow you to connect Case or Radiator fans. If you plan to connect a 3-pin fan, please connect it to Pin 1-3. CHA_FAN3 FAN_VOLTAGE CHA_FAN_SPEED...
  • Page 47 A620AM Pro RS WiFi A620AM Pro RS CPU Fan Connector (4-pin CPU_FAN1) (see p.6, No. 2) This header allows you to connect CPU fan. If you plan to connect a 3-pin fan, please connect it to Pin 1-3. CPU_FAN1 +12V...
  • Page 48 AIO Pump Fan Connector (4-pin AIO_PUMP) (see p.7, No. 6) This header allows you to connect AIO (All-in-One) pump or fan. If you plan to connect a 3-pin AIO cooler fan, please connect it to Pin 1-3. AIO_PUMP FAN_VOLTAGE AIO_PUMP_SPEED FAN_SPEED_CONTROL ATX Power Connector (24-pin ATXPWR1) (see p.6, No.
  • Page 49 A620AM Pro RS WiFi A620AM Pro RS ATX 12V Power Connector (8-pin ATX12V1) (see p.6, No. 1) This motherboard provides a 8-pin ATX 12V power connector. To use a 4-pin ATX power supply, please plug it along Pin 1 and Pin 5.
  • Page 50 RGB LED Header (4-pin RGB_LED1) (see p.6, No. 24) This RGB header is used to connect RGB LED extension cable which allow users to choose from various LED lighting effects. Caution: Never install the RGB LED cable in the wrong orientation; otherwise, the cable may be damaged.
  • Page 51 A620AM Pro RS WiFi A620AM Pro RS Addressable LED Headers (3-pin ADDR_LED1) (see p.6, No. 23) (3-pin ADDR_LED2) (see p.6, No. 7) (3-pin ADDR_LED3) (see p.6, No. 9) These headers are used to connect Addressable LED extension cables which allow users to choose from various LED lighting effects.
  • Page 52 1. Never install the Addressable LED cable in the wrong orientation; otherwise, the cable may be damaged. 2. Before installing or removing your Addressable LED cable, please power off your system and unplug the power cord from the power supply. Failure to do so may cause damages to motherboard components.

  • Page 53: Smart Button

    A620AM Pro RS WiFi A620AM Pro RS 2.13 Smart Button The motherboard has one smart button: BIOS Flashback Button, allowing users to flash the BIOS. BIOS Flashback Button (BIOS_FB1) (see p.8, No. 12) BIOS Flashback Button allows users to flash the BIOS.
  • Page 54 ASRock BIOS Flashback feature allows you to update BIOS without powering on the system, even without CPU. Before using the BIOS Flashback function, please suspend BitLocker and any encryp- tion or security relying on the TPM. Make sure that you have already stored and backup-ed the recovery key.

  • Page 55: Post Status Checker

    A620AM Pro RS WiFi A620AM Pro RS 2.14 Post Status Checker Post Status Checker (PSC) diagnoses the computer when users power on the machine. The LEDs light up to show what component is running into an issue. They emit red, yel- low, white and yellow-green lights to indicate, respectively, the CPU, memory, VGA and storage are not detected or fail.
  • Page 56 2.15 M.2 2230 WiFi/BT PCIe WiFi module Installatio Guide (A620AM Pro RS) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The M.2 Socket (Key E) supports type 2230 WiFi/BT PCIe WiFi module.
  • Page 57 A620AM Pro RS WiFi A620AM Pro RS Step 3 Align and gently insert the 2230 WiFi/BT PCIe WiFi module into the M.2 slot. Please be aware that the module only fits in one orientation. Step 4 Tighten the screw with a screwdriver to secure the module into place.
  • Page 58 2.16 M.2 SSD Installation Guide (M2_1) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Hyper M.2 Socket (M2_1, Key M) supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode. * M2_1 is the first priority for M.2 installation. Installing the M.2 SSD Step 1 Prepare a M.2 SSD and the screw.
  • Page 59 A620AM Pro RS WiFi A620AM Pro RS Step 4 Peel off the yellow protective film on the nut A. Prepare the M.2 standoff that comes with the package, and hand tighten it into the nut A. Skip Step 4 if your M.2 SSD is Type 2280.
  • Page 60 Step 7 Before securing the M.2 heatsink, make sure to align the notch on the SSD to the standoff on the motherboard if you use a Type 2280 SSD module; otherwise, the SSD module may be damaged. Correct Installation: The SSD's PCB is in proper place, and the M.2 heatsink can be screwed in.
  • Page 61 A620AM Pro RS WiFi A620AM Pro RS Step 8 Tighten the screws with a screwdriver to secure the module (if your M.2 SSD is Type 2280) and M.2 heatsink into place in the order shown. Tighten screw opposite the M.2 connector first (2), and then tighten the one next to the M.2 connector (3).
  • Page 62 2.17 M.2 SSD Installation Guide (M2_2) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Hyper M.2 Socket (M2_2, Key M) supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode. * M2_2 will run at Gen4x4 with 9000 and 7000 series processors, Gen4x4 with 8000 (Phoenix 1) series processors and Gen4x2 with 8000 (Phoenix 2) series processors.
  • Page 63 A620AM Pro RS WiFi A620AM Pro RS Step 3 Move the standoff based on the module type and length. The standoff is placed at the nut location B by default. Skip Step 3 and 4 and go straight to Step 5 if you are going to use the default nut.
  • Page 64 2.18 M.2 SSD Installation Guide (M2_3) The M.2 is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. The Ultra M.2 Socket (M2_3, Key M) supports type 2260/2280 PCIe Gen3x4 (32 Gb/s) mode. Installing the M.2 SSD Step 1 Prepare a M.2 SSD and the screw.
  • Page 65 A620AM Pro RS WiFi A620AM Pro RS Step 3 Move the standoff based on the module type and length. The standoff is placed at the nut location B by default. Skip Step 3 and 4 and go straight to Step 5 if you are going to use the default nut.

  • Page 66: Copyright Notice

    ASRock does not provide warranty of any kind, either expressed or implied, including but not limited to the implied warranties or conditions of merchantability or fitness for a particular purpose. In no event shall ASRock, its directors, officers, employees, or agents be liable for any indirect, special, incidental, or consequential...

  • Page 67: Fcc Compliance Statement

    FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 68 ASRock follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASRock product is in line with global environmental regulations. In addition, ASRock disclose the relevant information based on regulation requirements.
  • Page 69 If you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard International call charges apply)
  • Page 70 European Community Radio Equipment Directive Compliance Statement This device complies with directive 2014/53/EU issued by the Commision of the European Community. This equipment complies with EU radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator &...
  • Page 72 BSMI 限用物質及元素清單 限用物質及其化學符號 單元 鉛 (Pb) 鎘 (Cd) 汞 (Hg) 六價鉻 (Cr ) 多溴聯苯 (PBB) 多溴聯苯醚 (PBDE) 電路板 電子元件 線材 配件 備考 1.〝超出 0.1 wt %〞及〝超出 0.01 wt %〞係指限用物質之百分比含量超出百分比含 量基準值。 備考 2.〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。 備考 3.〝－〞係指該項限用物質為排除項目。...
  • Page 73 China RoHS 电子信息产品污染控制标示 依据中国发布的「电子信息产品污染控制管理办法」及 SJ/T 11364-2014「电子信息 产品污染控制标示要求」，电子信息产品应进行标示，藉以向消费者揭露产品中含有 的有毒有害物质或元素不致发生外泄或突变从而对环境造成污染或对人身、财产造成 严重损害的期限。依上述规定，您可于本产品之印刷电路板上看见图一之标示。图一 中之数字为产品之环保使用期限。由此可知此主板之环保使用期限为 10 年。 图一 有毒有害物质或元素的名称及含量说明 若您欲了解此产品的有毒有害物质或元素的名称及含量说明，请参照以下表格及说明。 有害物质或元素 部件名称 铅 (Pb) 镉 (Cd) 汞 (Hg) 六价铬 (Cr(VI)) 多溴联苯 (PBB) 多溴二苯醚 (PBDE) 印刷电路板 及电子组件 外部信号连 接头及线材 以上表格依据 SJ/T 11364-2014 的规定编制。 O: 表示该有害物质在该部件所有均质材料中的含量均在 GB/T 26572 规定的限量要求以下。 X: 表示该有害物质至少在该部件的某一均质材料中的含量超出...
