INSTRUCTIONS FOR THERMOWELD GROUNDING CONNECTIONS
RS-1
Place stud in mold so end to be welded is 1/8" from steel
surface. If this is not possible due to using short stud,
cut end of stud to a 25
must be cut at the 25 angle, and position as shown.
O
RR-1
Insert lower rod up to center of tap hole. For
3/4" and smaller, pointed rod is butted. Blunt
rod is gapped 3/8". For 1"
rod cut upper rod at 45
O
and butt as shown. Use
the 38-0330-00 cable
clamp to position the
mold and support align
the upper rod
as shown.
+1 (918) 627-5210 • 1-800-558-1373 • WWW.THERMOWELD.COM
ELECTRICAL GROUNDING • CATHODIC PROTECTION • ELECTRIC UTILITY • RAIL
ROD TO ROD - STUD OR ROD TO STEEL
angle. All 3/4" and 1" studs
O
®
The Contractors Choice
RS-2
Place stud in mold so end to be welded is 1/8" from steel
surface. If this is not possible due to using short stud,
cut end of stud to a 25
must be cut at the 25
RR-2
For 3/4" and smaller, pointed rod is butted. Blunt
rod is gapped 3/8". For 1" rod cut upper rod at
45 and butt as shown. Use the 38-0330-00
O
cable clamp to position the mold and support
align the upper rod as shown.
Tel. +1.800.558.1373
Tel. +1.918.627.5210
www.thermoweld.com
angle. All 3/4" and 1" studs
O
angle, and position as shown.
O
ECN 2552 REV "E" 03/05/13 34-5381-31
