Package Contents
Plastic access point covers (20)
AP-615-CVR-20 Installation Guide
Introduction
The AP-615-CVR-20 cover clips onto the exterior of the access point, offering a practical and aesthetic
solution for concealment and customization.
Installing the AP-615-CVR-20
1. Align the holes on the cover with the LEDs on the access point (see
Figure 1 Aligning cover with LEDs
2. Press the cover onto the access point (see
into the first and fourth chassis slot near the Ethernet port (see
0512245-01 |
November 2021
AP-615-CVR-20
Installation Guide
Figure
2, step 1), making sure the cover clips are clipped
Figure
Figure
1).
3).
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Aruba Networks AP-615-CVR-20
Summary of Contents for Aruba Networks AP-615-CVR-20
- Page 1 AP-615-CVR-20 Installation Guide Introduction The AP-615-CVR-20 cover clips onto the exterior of the access point, offering a practical and aesthetic solution for concealment and customization. Installing the AP-615-CVR-20 1. Align the holes on the cover with the LEDs on the access point (see...
- Page 2 Figure 3 Securing cover clips into chassis slots 3. Press the top side of the cover (see Figure 2, step 2) until it snaps on the access point (see Figure Figure 4 Securing cover onto access point (completed) | Installation Guide AP-615-CVR-20...
