- Page 1 INSTALLATION AND SETUP GUIDE V-6042T and V-6044T Fixed Turret Camera...
-
Page 2: Get Started
The V-6042T and V-6044T are indoor/outdoor video cameras that allow users to view live and recorded HD video clips in Virtual Keypad™. The V-6042T records video in 2 Megapixels and the V-6044T records video in 4 Megapixels. To activate the camera, you need an active Dealer Admin account at dealer.securecomwireless.com. -
Page 3: Standard Power Connection
Seat Turn o-Ring between cover and Ethernet connector, then slip Cover cover over connector Wire O-Ring crimp, then plug in to camera Ethernet connector Figure 1: Installing the Waterproof Ethernet Cap V-6042T/V-6044T Installation and Setup Guide | Digital Monitoring Products... -
Page 4: Mount The Camera
Note: Before continuing, remove the film over the IR lens. The IR lens is the lens without indentations, located below the camera lens. See Figure 2. Camera Lens Rotate Tilt 0° ~ 80° 0° ~ 360° IR Lens 0° ~ 360° Figure 2: Mount the Camera Figure 3: Adjust the Camera V-6042T/V-6044T Installation and Setup Guide | Digital Monitoring Products... -
Page 5: Activate The Camera
Enter a name for the camera. Under Advanced, you can configure the following basic settings: ▶ Video Quality ▶ Flip Image ▶ Record on Alarm ▶ Time Zone ▶ Observe DST Press Save. V-6042T/V-6044T Installation and Setup Guide | Digital Monitoring Products... - Page 6 Enter a Name for the camera. Under Advanced, you can configure the following basic settings: ▶ Video Quality ▶ Flip Image ▶ Record on Alarm ▶ Time Zone ▶ Observe DST 10. Tap Save. V-6042T/V-6044T Installation and Setup Guide | Digital Monitoring Products...
- Page 7 Dealer Admin will populate a 4-point rectangle in camera view screen. Click and drag an endpoint to change the size of the region. admin@gmail.com Figure 6: Configure a Motion Detection Region in Dealer Admin V-6042T/V-6044T Installation and Setup Guide | Digital Monitoring Products...
- Page 8 If +Line Cross has been selected, Dealer Admin will populate a 2-point line in the camera view screen. Click and drag an endpoint to change the length of the line. admin@gmail.com Figure 8: Configure Video Analytics in Dealer Admin V-6042T/V-6044T Installation and Setup Guide | Digital Monitoring Products...
-
Page 9: Additional Information
Remove the original SD card from the slot behind the camera lens, then insert the replacement SD card. Reattach the camera’s cover to the mounting base. Mounting Base SD Card Cover Figure 9: Camera Details V-6042T/V-6044T Installation and Setup Guide | Digital Monitoring Products... -
Page 10: Ordering Information
Dimensions 4.4” x 3.8” (15.59 cm x 6.31 cm x 6.27 cm) Housing Material Metal Environmental Operating Temperature -22°F to 140°F (-30°C to 60°C) Operating Humidity 95% RH or less, non-condensing V-6042T/V-6044T Installation and Setup Guide | Digital Monitoring Products... - Page 11 I N T R U S I O N • F I R E • A C C E S S • N E T W O R K S manufactured in Springfield, MO 2500 North Partnership Boulevard using U.S. and global components. Springfield, Missouri 65803-8877 LT-2608 23405 800.641.4282 | DMP.com © 2025...
