Summary of Contents for ITRON Solar Battery AP
- Page 1 Solar Battery AP Installation Guide ITRON INSTALLATION GUIDE February 19, 2024 LDI-0046REV 000 Itron, Inc. Page 1 of 26...
- Page 2 Trademark notice Itron and the Itron logo are registered trademarks of Itron Inc. in the United States and other countries and regions. All other product names and logos in this documentation are used for identification purposes only and may be trademarks or registered trademarks of their respective companies.
-
Page 3: Table Of Contents
USA, FCC Part 15 spectrum compliance USA, FCC Class B-Part 15 Modifications and repairs Canada, ISED spectrum compliance RF exposure (FCC/ISED) Transportation classification Lithium battery safety Intrinsic safety Electrostatic ignition hazard February 19, 2024 LDI-0046 REV 000 Itron Inc. Page 3 of 26... - Page 4 SBAP Installation Guide Contents Module cleaning Do not drop February 19, 2024 LDI-0046 REV 000 Itron Inc. Page 4 of 26...
-
Page 5: New In This Document
SBAP Installation Guide New in this document New in this document Revision Date Description REV 000 February 19, 2024 Publication for safety certification. February 19, 2024 LDI-0046 REV 000 Itron, Inc. Page 5 of 26... -
Page 6: Introduction
I ntroduction The Itron Solar Battery AP (SBAP) is an access point (AP) that provides a lower total cost of ownership (TCO) for gas-only and/or water-only deployments without relying on any overhead infrastructure or mounting assets. The SBAP communicates using Extended FAN Connectivity+ (EFC+) with a limited number of gas and water meters, and then backhauls the data over a cellular network. -
Page 7: About The Sbap
Table 1 SBAP variants Part Part number SOLAR BATTERY AP, PRIMARY, EFC+, VERIZON, USA 200-900000 SOLAR BATTERY AP, EXT MESH, EFC+, VERIZON, USA 200-900001 SOLAR BATTERY AP, PRIMARY, EFC+, ATT, USA 200-900002 SOLAR BATTERY AP, EXT MESH, EFC+, ATT USA 200-900003 Table 2 Mounting kit variants... -
Page 8: Extended Fan Connectivity (Efc)
(CPD), like a meter or streetlight controller. Dimensions The SBAP is 236 millimeters (9.3 inches) high, 160 millimeters (6.3 inches) long, and 77 millimeters (3 inches) wide. February 19, 2024 LDI-0046 REV 000 Itron, Inc. Page 8 of 26... -
Page 9: Installation
The image below illustrates the ideal direction an SBAP faces, where red indicates a poor direction, yellow indicates an okay direction, and green indicates the preferred direction. February 19, 2024 LDI-0046 REV 000 Itron, Inc. Page 9 of 26... -
Page 10: Prerequisites
Pipe mount kit. The kit part number varies based on the size of the pipe you're mounting on. See Table 2 for ordering information. The mounting kits include the components listed in Table February 19, 2024 LDI-0046 REV 000 Itron, Inc. Page 10 of 26... -
Page 11: Horizontal Mount
1. Place the U-bolt around the pipe or pole and thread the U-clamp through the threads on the U-bolt. 2. Align the mounting holes on the mounting bracket with the U-bolts. February 19, 2024 LDI-0046 REV 000 Itron, Inc. Page 11 of 26... - Page 12 3. Secure the mounting bracket to the U-bolts with the four flange nuts; finger tighten the nuts. 4. Torque the flange nuts to 50-60 inch-pounds. February 19, 2024 LDI-0046 REV 000 Itron, Inc. Page 12 of 26...
- Page 13 7. Torque the captive screws to 10-12 inch-pounds. 8. Place new tamper seals over the screws. Press tamper seals into place using an 11/32 inch nut driver or similar blunt tool. February 19, 2024 LDI-0046 REV 000 Itron, Inc. Page 13 of 26...
-
Page 14: Vertical Mount
2. Align the mounting holes on the mounting bracket with the U-bolts. 3. Secure the mounting bracket to the U-bolts with the four flange nuts; finger tighten the nuts. February 19, 2024 LDI-0046 REV 000 Itron, Inc. Page 14 of 26... - Page 15 5. Align the mounting holes on the SBAP to the mounting holes on the mounting bracket. 6. Secure the SBAP to the mounting bracket with the four captive screws; hand tighten the captive screws. February 19, 2024 LDI-0046 REV 000 Itron, Inc. Page 15 of 26...
- Page 16 8. Place new tamper seals over the screws. Press tamper seals into place using an 11/32 inch nut driver or similar blunt tool. This completes the vertical pipe or pole assembly. February 19, 2024 LDI-0046 REV 000 Itron, Inc. Page 16 of 26...
-
Page 17: Wall Mount
2. Set the mounting bracket aside and drill four holes according to where you marked the wall in step 1. February 19, 2024 LDI-0046 REV 000 Itron, Inc. Page 17 of 26... - Page 18 Tighten the screws with a Phillips screwdriver until the SBAP is snugly attached to the backplate. Torque the captive screws February 19, 2024 LDI-0046 REV 000 Itron, Inc. Page 18 of 26...
- Page 19 7. Place new tamper seals over the screws. Press tamper seals into place using an 11/32 inch nut driver or similar blunt tool. This completes the wall mount installation. February 19, 2024 LDI-0046 REV 000 Itron, Inc. Page 19 of 26...
- Page 20 SBAP Installation Guide 3 Installation February 19, 2024 LDI-0046 REV 000 Itron, Inc. Page 20 of 26...
-
Page 21: Activating Your Sbap
(such as Check Cellular Coverage or troubleshooting). For more information about activating the SBAP, see the Field Tools for North American Gas and Water ERTs and Meters Help. February 19, 2024 LDI-0046 REV 000 Itron, Inc. Page 21 of 26... -
Page 22: Programming
P rogramming Important! You must program the device before use. Program the device using an approved programming device loaded with Field Tools software version 2.6 or later. February 19, 2024 LDI-0046 REV 000 Itron, Inc. Page 22 of 26... -
Page 23: Events And Alarms
No Cellular Network Coverage. The SBAP could not find a cellular network. For complete information about the tampers or events and alarms available in your SBAP, see Advanced Metering Manager (AMM) 5.2 Events. February 19, 2024 LDI-0046 REV 000 Itron, Inc. Page 23 of 26... -
Page 24: Important Safety And Compliance Information
To ensure system performance, this device and antenna shall not be changed or modified without the express approval of Itron. Per FCC and ISED rules, unapproved modifications or operation beyond or in conflict with these instructions for use could void the user's authority to operate the equipment. -
Page 25: Canada, Ised Spectrum Compliance
Transportation classification The Federal Aviation Administration prohibits operating transmitters and receivers on all commercial aircraft. The Itron device is considered an operating transmitter and receiver and cannot be shipped by air. All product returns must be shipped by ground transportation. -
Page 26: Intrinsic Safety
Itron device. Module cleaning Warning! Clean only with a damp cloth. Do not drop Warning! While Itron modules are designed to withstand a drop, dropping the SBAP may damage the device and void the warranty. February 19, 2024 LDI-0046 REV 000...
