LTN-486(S), LTN-485(S), LTN-483(S/L)

Features :

48X CD-ROM with Pure-CAV Technology
E-IDE Interface, Support all PIO, MW-DMA, Ultra DMA/33 modes
Supporting Power Saving Function
Supporting High Speed Digital Audio Extration (DAE)
Supporting High Speed VCD Data Extration
Supporting Plug & Play ; Emergency Manual Eject
High Speed CD-Audio Playback Technology to Improve Audio Playability
Access All Format CD , CD-R , CD-RW Title & Disc (Support up to 99min)
Easy-Tray® Design for Both Horizontally & Vertically Use
Gear-Driven Tray Loading Mechaniasm to Improve Reliability
ABS® Auto Balance System (486,485) Mecha to Reduce Vibration & Noise
WSS® Wire Suspension System (483) Mecha to Reduce Vibration & Noise

Specifications :

Speed: CD-ROM 48X (20X~48X, Average 36X)
Interface: ATAPI-E/IDE
Sustained Transfer Rate: 3000~7200KB/sec (Average:5400KB/sec)
Burst Transfer Rate:
PIO mode 4
SW DMA 2
MW DMA 2
Ultra-DMA/33 33.3MB/sec
Access Time: 80ms (typical)
Support Disc Format:
CD-ROM/XA, CD-DA, Mixed-Mode, CD-I, VCD, Photo-CD, CD-Extra, CD-TEXT
CD-R, CD-RW, Single/Multi-Session, Karaoke-CD, I-Trax, E-CD, 8cm & 12cm disc
Support Operating System: DOS 6.xx, Windows 95/98/NT/ME/2000, OS2 Warp
MTBF: 120'000 Power On Hours with 10% Duty
Audio: S/N >= 60dB
Earphone >= 0.5Vrms @ 1KHz
Temperature & Humidity:
Operating:
Non-Operating: -20C to 60C ; RH: 15% to 90% , Non-Condensing
Dimension :
WxHxD: 145.8 x 41.3 x 190.0mm
Weight: <= 1.0Kg
Power Requirement:
DC + 5 V (+/- 5%, 100mVpp ripple)
DC +12 V (+/- 5%, 200mVpp ripple)

User Interface:

LED Indicator, Stereo Ear Phone Jack, Volume Knob, Stop/Eject Button, Play/Skip Button
IDE Socket, Power Input, Analog Audio Output, Digital Out, Master/Slave/CS Jumper
Copyright © LITE-ON IT Corp. All Rights Reserved.
48X
C C C C D D D D - - - - R R R R O O O O M M M M D D D D R R R R I I I I V V V V E E E E
MAX
16.6MB/sec
8.3MB/sec
16.6MB/sec
5C to 45C ; RH: 15% to 80% , Non-Condensing
1.0 A (max), 0.3 A (min)
1.5 A (max), 0.05 A (min)
