Dalton P8017 User Instruction Manual

User Instruction Manual for P8017 Smart Lock
Thank you for choosing the DALTON P8017 Smart Lock. This manual provides guidance on how to install and use the
lock, and includes important safety and precautionary measures. Please read this manual carefully before using the
product to ensure proper operation and maximum safety.
1.
Safety and Precautions:
1. Read all instructions in their entirety to ensure that you have a complete understanding of the lock's features,
installation requirements, and operation procedures.
2. We highly recommend seeking the assistance of a professional installer to ensure proper installation.
3. Before installation, please ensure that the lock and lock body are selected correctly according to the door opening
direction. Failure to do so may result in improper function or damage to the lock.
4. Familiarize yourself with all warning and caution statements provided in this manual, as they are designed to
protect you and others from harm or injury.
5. It is important to remind all family members of the safety precautions associated with using the lock, including
keeping access to the back panel restricted and regularly checking the lock's settings to ensure they have not been
altered without your knowledge.
6. To prevent unauthorized access, it is recommended to protect your user codes and master code.
7. Dispose of used batteries in accordance with local laws and regulations to avoid environmental hazards.
CAUTION:
1. Keep the lock away from children to prevent any accidents.
2. Do not use any cleaning agents that contain corrosive chemicals to clean the lock. Use a soft cloth and mild
detergent instead.
3. Do not attempt to disassemble or modify the lock in any way. Contact the manufacturer for any repairs or
maintenance.
4. In case of emergency, use a backup mechanical key to unlock
Note: different door types have different accessories, please check
whether they match before starting the installation.
2.
Pre-installation Tools:
You will need:
Phillips screwdriver (You can use either a manual or electric screwdriver, but avoid using a power drill.)
Measuring Tape
Pencil
Level
PACKAGE CONTENTS LIST
A
DESCRIPTION QTY
PART
A Connection Assembly Screws
2
B
Connection Column 2
B
C Square Steel 1
Spindle 1
D
Spring 1
E
C
Pin 1
F
G Mechanical Keys 2
H 1
Key Cylinder
D
I Cylinder Assembly Screw 1
J Rubber Pads 2
K Lock Body + 4 Screws 1
E
L Drilling Template 1
M1 4
Rubber Mat
M2
Back Assembly Screws 4
F
N Back Sealing Panel 1
O
Battery 1
P Back Lock Panel 1
G
Q Front Lock Panel 1
3.
Door Preparation:
DOOR & LOCK DIRECTION
H L
I
M1
J
M2
N
K
O
Q
P
