- Page 1 SENSE NODE PLUS USER MANUAL Multiple Sensor Device Abstract LoRaWAN Sense Node Plus is a rechargeable device that reads temperature, relative humidity, CO2, ambient light, and atmospheric pressure and sends collected data over the LoRaWAN network. UM0003 Document Code...
-
Page 2: Table Of Contents
Sense Node Plus User Manual Contents Document overview ......................3 1.1. Introduction ........................3 1.2. Version History ......................... 3 1.3. Purpose ..........................3 1.4. Scope ..........................3 1.5. Definitions, Acronyms, and Abbreviation ..............3 Product Description ....................... 4 2.1. General Description ....................... 4 2.2. - Page 3 Sense Node Plus User Manual Compliance ........................16 Warranty ..........................17 Warning ..........................17 Disposal ..........................17 UM0003 Version: 1.2 Create Date: 05 February 2020 Version Date: 19 June 2023 P a g e...
-
Page 4: Document Overview
The purpose of this document is to guide users on how to use and deploy PTS Sense Node Plus devices. 1.4. Scope This document will mainly focus on Sense Node Plus and its implementation as an environmental sensing device. 1.5. Definitions, Acronyms, and Abbreviation... -
Page 5: Product Description
Sense Node Plus User Manual 2. Product Description 2.1. General Description The PTS Sense Node Plus is a device that measures temperature, relative humidity, CO concentration, Ambient Light, & Atmospheric Pressure and transmits the data to a Gateway through LoRaWAN Communication Protocol. -
Page 6: Enclosure
Sense Node Plus User Manual 2.3. Enclosure Ambient Light Sensor Power ON Button Power OFF Button *Press this button together with the Power ON button to turn OFF the device. Battery Status LED Activity Status LED CO2 Sensor TRH Sensor... -
Page 7: Technical Specifications
Sense Node Plus User Manual 2.4. Technical Specifications Parameters Value Frequency Band 868 MHz (Europe) Electrical Rating Charging: 5V 500mA Operating Temperature Range 5°C to 40°C Temperature Accuracy ±0.3°C (typical) Relative Humidity Operating Range 20% to 80% RH (recommended)* Relative Humidity Accuracy ±2% (typical) -
Page 8: Product Operation
Sense Node Plus User Manual 3. Product Operation 3.1. Standby Mode When the device is shipped, it will be on Sleep Mode. The power consumption in this mode will be minimal. At sleep mode, the device will not be measuring and transmitting sensor data. -
Page 9: Payload
Sense Node Plus User Manual 4. Payload 4.1. Payload Decoding The payload contains the following data from the sensors and battery percentage onboard the device: 1. Temperature (°C) 2. Relative Humidity (%RH) 3. CO2 concentration (ppm) 4. Ambient Light (lux) 5. - Page 10 Sense Node Plus User Manual In the example above, if payload = 0A 86 01 AE 03 68 01 00 03 F0 59, decoded value will "temperature": 26.94, ▪ “humidity”: 43, ▪ "co2": 872, ▪ "lightIntensity": 256, ▪ "pressure": 1008, ▪ "battPercent": 89 ▪ UM0003 Version: 1.2 Create Date: 05 February 2020...
-
Page 11: Deployment Procedure
Sense Node Plus User Manual 5. Deployment Procedure When requesting for Sense Node Plus device only (no gateway and network server), the user/client should already have an existing LoRaWAN System in their site. The device is set to OTAA (Over-the-Air Activation) mode and it has pre-defined Device EUI (DevEUI), Application EUI (AppEUI), and Application Key (AppKey). -
Page 12: Activate The Device
Sense Node Plus User Manual 5.3. Activate the Device The device is shipped in Standby Mode to conserve battery power. Activation is done by pressing the button on the left side of the device. Please refer to section 2.3. Upon activation, LED will blink 5 times to indicate device activation. -
Page 13: Installation
Sense Node Plus User Manual 6. Installation 6.1. Environmental Conditions The Sense Node Plus must be installed on the following conditions a. Indoor Use. b. Altitude up to 2000m. c. Temperature 5ºC to 40ºC. d. Pollution degree 2. e. Not for wet location. -
Page 14: Battery
Sense Node Plus User Manual 7. Battery 7.1. Charging the Device Charge the device when the battery’s state of charge is low. To charge, use a micro USB cable and a wall adapter. Charging from desktop or laptop is also applicable. -
Page 15: Maintenance
Sense Node Plus User Manual 8. Maintenance Ambient Light Sensor CO2 Sensor TRH Sensor Micro USB Port Pressure Sensor 8.1. Cleaning the device Cleaning the Enclosure Use a damp cloth to remove the dirt on the enclosure. Cleaning the Ambient Light Sensor Use a damp cloth to wipe the dirt on the transparent cover. -
Page 16: Repair Of Device
Sense Node Plus User Manual 8.2. Repair of Device Parts Repair Repair of parts are done by the manufacturer. The device must be returned to the manufacturer for assessment. Spoilt or bloated battery must be removed from the device and must be handled accordingly. -
Page 17: Manufacturer Contact
Sense Node Plus User Manual 9. Manufacturer Contact Name: PTS Technologies Address: 2 Kaki Bukit Avenue 1, #04-05, 417938 Ph Number: +65 67494474 Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 18: Warranty
Sense Node Plus User Manual Warranty Warranty claims only be valid If the instruction in the manuals have been correctly followed. The warranty may be rendered invalid if the product is incorrectly used and maintained. Warning If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired.
