Summary of Contents for Pure Clean PUCWM33
- Page 1 Visit Our Website SCAN ME PyleUSA.com PUCWM33 Foldable Washing Machine USER GUIDE...
-
Page 2: Table Of Contents
PLEASE KEEP THIS MANUAL CAREFULLY FOR FUTURE REFERENCE. FOR HOUSEHOLD USE ONLY. TABLE OF CONTENTS FEATURES AND TECHNICAL SPECS SAFETY PRECAUTIONS INSTALLATION STEPS KNOW YOUR FOLDING WASHING MACHINE ELECTRICAL SCHEMATIC DIAGRAM USAGE CLOTHING PRETREATMENT & PLACEMENT UNFOLDING THE MACHINE FOLDING THE MACHINE USAGE WASHING MACHINE OPERATION CLEANING AND MAINTENANCE... -
Page 3: What's In The Box
Features: • With Semi-Automatic Cleaning Function • High-Frequency Vibration • Energy-Saving and Environmental Protection • Foldable and Portable Bucket Type • Convenient to Use and to Store • Easy to Use • Saving Water and Electricity • Perfect for Use in Camping, Apartments, Dorms and Business Trip What's in the Box: •... -
Page 4: Safety Precautions
PLEASE READ THIS MANUAL CAREFULLY BEFORE OPERATING THE MACHINE AND KEEP IT IN A SAFE PLACE. Safety Precautions To ensure better usage of this product and to prevent personal injury or damage to items, please read and follow the instructions in this manual. An act or practice that must be prohibited An act or practice that must be followed Failure to do so may result in damage to property or personal injury... -
Page 5: Installation Steps
DO NOT: • Tilt or move the machine during operation as it may cause water leakage. • Touch the power plug with wet hands. • Pull the power plug by the cord. • Store gasoline or other ammable gases/liquids near the washing machine. •... - Page 6 Select Installation Location Place the unit away from heat sources and direct sunlight to prevent fading or peeling of the exterior coating. Unfold the washing machine rst, and place it on a stable, level surface. Drainage 1. Lower Drainage: Pull out the outlet plug at the bottom of the pedestal. Water will drain naturally.
-
Page 7: Know Your Folding Washing Machine
Know Your Folding Washing Machine 1. Bucket Lid 2. Barrel frame 3. Handle 4. Folding bucket 8. Bucket bottom 5. Drain 6. Knob 7. Base 9. Pulsator Detergent Use • Function: Detergent reduces the adhesion of stains to clothing and improves cleaning. -
Page 8: Electrical Schematic Diagram
Electrical schematic diagram Brown Wash timer Yellow Brown Green Yellow Yellow Yellow Washing motor Brown Blue Yellow/Blue Usage (Clothing Pretreatment & Placement) Pretreatment: Remove visible dirt, bers, or debris from clothing before washing to prevent drain blockage. Placement: Unfold clothing before placing it in the tub to avoid tangling and ensure e ective cleaning. -
Page 9: Unfolding The Machine
Unfolding the Machine 1. Remove the bucket lid. 2. Hold the handle with one hand. 3. Press the bucket bottom with the other hand (do not press the pulsator to avoid damage). 4. Fully extend the bucket. Folding the Machine 1. -
Page 10: Washing Machine Operation
Program Setting: 1. Select the desired program. 2. Turn the timer knob to 15. 3. The machine will reset after the cycle ends. 4. If needed, repeat the program. Note: Always turn o the power after completing a cycle. Interrupting a cycle may damage internal components. -
Page 11: Troubleshooting
Thank you for choosing PyleUSA. By registering your product, you ensure that you receive the full bene ts of our exclusive warranty and personalized customer support. Complete the form to access expert support and to keep your Model Number: PyleUSA purchase in perfect condition. PUCWM33 PyleUSA.com/pages/register www.PyleUSA.com... - Page 12 Questions or Comments? We are here to help! Phone: 1.718.535.1800 PyleUSA.com/ContactUs...
