Sony NEX-6 Service Manual

SERVICE MANUAL
Ver. 1.0 2012.09
Image: NEX-6 (Main body)
SERVICE NOTE (Check the following note before the service.)
– ENGLISH –
1-1. PRECAUTION ON REPLACING THE SY-345 BOARD
1-2. PRECAUTION ON REPLACEMENT OF IMAGER
1-3. ADDITION OF DESTINATION DATA FILE
1-4. CHECKING THE Wi-Fi FUNCTION
– JAPANESE –
1-1. SY-345基板交換時の注意
1-2. イメージャ交換時の注意
1-3. Destination Dataファイルの追加について
1-4. Wi-Fi機能の確認
[About the service of this model]
NEX-6L/6Y are commodity that packed the Interchangeable Lens Digital Camera and Interchangeable Lenses.
Refer to each following service manual the Interchangeable Lens kit, when you repair.
Model Lens
NEX-6L SEL1650 (E PZ 16-50 mm F3.5-5.6 OSS)
NEX-6Y SEL1650 (E PZ 16-50 mm F3.5-5.6 OSS)
SEL55210 (E 55-210 mm F4.5-6.3 OSS)
INTERCHANGEABLE LENS DIGITAL CAMERA
The components identified Les composants identifiés par
by mark 0 or dotted line with une marque 0 sont critiques
mark 0 are critical for safety. pour la sécurité.
Replace only with part number Ne les remplacer que par une
specified. pièce portant le numéro spécifié.
NEX-6/6L/6Y_L2
9-834-689-31
NEX-6/6L/6Y
Canadian Model
Russian Model
Australian Model
Chinese Model
Korea Model
Japanese Model
Tourist Model
Service Manual of Lens
9-834-690-1[]
9-834-690-1[]
9-834-603-1[]
Ver. Date
2
1.0 2012.09
LEVEL
US Model
AEP Model
UK Model
E Model
Sony Corporation
Revision History
History Contents
Official Release —
983468931.pdf
S.M. Rev.
issued
—
2012I08-1
© 2012.09
Published by Sony Techno Create Corporation
