- Page 1 Quick Start Guide Smart Wi-Fi Door Lock Tapo DL110 Visit www.tapo.com/support for technical support, user guides, warranty, and more information 7106511314 REV1.0.0 © 2024 TP-Link...
- Page 2 Welcome to Tapo! Setup Video https://www.tp-link.com/support/ setup-video/#cloud-cameras Contact Us Our expert Technical Support team is ready to assist you. Please don't hesitate to reach out with any questions. EMAIL CHAT CALL https://www.tp-link.com/support/contact-technical-support/...
- Page 3 Contents Parts in the Box Installation Preparation Installation Set Up What if the battery is dead while you are outside? Appearance...
- Page 4 Parts in the Box Exterior Interior Battery Pack Assembly Assembly Install the Bolt Install Strike Plate Packaged Together Bolt Strike Plate Dust Box Bolt Screws (ST4*25)×2 Strike Plate Screws (ST4*25)×2...
- Page 5 Install Mounting Plate Actual Size (M5*58)×2 (M5*68)×2 Mounting Plate Interior Assembly Stickers...
- Page 6 Install Exterior Assembly Actual Size Actual Size (M4*7.5)×3 (ST4*20)×1 USB Adapter Measuring Keys ×2 Silicone Cover Cable Template guide Vertical Installation Quick Start Reference Line Stickers Guide...
- Page 7 Installation Preparation...
- Page 8 Charge Your Battery Plug the provided USB cable into the battery pack's Type-C port, then connect it to a power outlet via a USB adapter with 5V output. LED Indication: Charging: Solid amber Fully charged: Solid green Note: 1. Charge the battery before use. This will take a few hours. It is recom- mended to use a 5V/2A adapter for best charging performance.
- Page 9 Check door lock compatibility. Place the measuring template on the door, aligning the door edge line with the door edge. Use the dimensions on the template to measure your door. Use the measuring Door template to measure Thickness 1-3/8’’ to your door 2-11/64’’...
- Page 10 Installation...
- Page 11 Installation Overview [Door]...
- Page 12 Remove your existing lock. Remove your existing door lock.
- Page 13 Install the bolt. Ensure the word "Top" is facing up. T O P If the latch hub is not centered in the door hole, twist the bolt Actual Size to extend it. Packaged together with the bolt...
- Page 14 Install the exterior assembly. If the door hole is [OUTSIDE] 2-1/8‘’ (54 mm), keep the spacer. If it’s 1-1/2’’ (38 mm), remove the spacer first. For 2-1/8‘’ (54 For 1-1/2’’ (38 mm) door hole mm) door hole To help mount vertically, place the sticker aligning its door edge line with the door edge.
- Page 15 Cable goes under the bolt. [OUTSIDE] Align the tailpiece with the center hole of the bolt, and insert it into the center hole.
- Page 16 Install the mounting plate. Place the appropriate [INSIDE] interior assembly sticker aligning with the door edge. Route the cable through the mounting plate hole.
- Page 17 mounting plate Do Not use an electric drill screws to secure the to secure the screws. mounting plate. For door thickness of 1-3/8’’ to 1-49/64’’ (35-45 mm): choose screw A For door thickness of 1-49/64’’ to 2-11/64’’ (45-55 mm): choose screw B Actual Size M5*58 M5*68...
- Page 18 Install the interior assembly. Remove the [INSIDE] battery cover. Connect the cable tightly. Tuck the excess Ensure the color side faces up. cable into the groove. Red marking facing up Not tightly connected...
- Page 19 Align the tailpiece with Rotate the thumb the key cylinder. Attach latch to ensure the the interior assembly to latch retracts the mounting plate. normally.
- Page 20 Use the three provided Do Not use an electric drill to secure the screws. M4*7.5 screws to affix the interior assembly. Actual Size (Optional) Use the provided ST4×20 screw (Optional) to secure the interior assembly. Actual Size This screw will firmly secure the interior assembly and mounting plate to the inside door.
- Page 21 Install the battery. Insert the battery into Replace the cover by the interior assembly sliding it down. with correct direction. Insert the silicone cover into the bottom hole. Remove the two stickers.
- Page 22 Install the strike. Insert the dust box and strike plate into the strike hole on the door frame. Ensure the depth of the strike hole is at least 1’’ (25.4 mm). [Frame] Actual Size Strike Hole Depth 1’’ (25.4 mm) Packaged together with the bolt If you do not need to push or pull the door to...
- Page 23 Set Up...
- Page 24 Set Up 1. Get the Tapo app from the App Store or Google Play and log in with your TP-Link ID. If you do not have an account, create one first. 2. Tap the button in the app. Select Door Locks and then your model.
- Page 25 What if the battery is dead while you are outside? Unlock via the provided key Gently pull out the doorbell cover to expose the cylinder. Unlock the door with the provided key. Temporarily charge the lock Connect the lock to a power outlet or power bank using a USB cable.
- Page 26 Appearance...
- Page 27 Appearance Exterior Assembly Fingerprint Scanner Lock/unlock with your fringerprint. Status LED Indicates the status of your device. Key Pad Lock/unlock the door by entering your PIN code. Unlocking/Locking Button When you enter your PIN code starting with scramble digits, press this button to confirm unlocking.
- Page 28 Interior Assembly Wi-Fi On/Off Button Turn on Wi-Fi and connect your device to a Wi-Fi network for remote control. Turn off Wi-Fi and only control your device locally via Bluetooth. Thumb Latch Rotate to lock/unlock the door. Battery Compartment Insert the provided battery to power your lock.
- Page 29 Status LED Indications Blinking red and green Ready for setup Pulsing green Connecting to Wi-Fi Blinking amber Low battery Blinking green Lock updating Solid red, then turn off Updating failed after 3 seconds Blinking red three times Door jammed Specifications Type-C Emergency Power Supply: 5V Battery Power: 3.6V Rainproof Rating: IP65 (only for the exterior assembly)
- Page 30 Safety Information • Do not use damaged charger or USB cable to charge the device. • Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us. • Do not use the device where wireless devices are not allowed. •...
- Page 31 FCC compliance information statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 32 L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes : 1) L’appareil ne doit pas produire de brouillage; 2) L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
