Edifiel QS30 Manual

EN
1. Mobile app and computer app
● With the mobile app or the computer app, you can
•Switch EQs,
•Select or customize light effects,
•Upgrade the firmware, and
•More functions.
EDIFIER ConneX mobile app
●
1. With your smart device, scan the QR code on the quick start guide or the packaging.
•You can also search for "EDIFIER ConneX" in Apple App Store (iOS devices) or
Google Play (Android devices).
2. Download and install the app.
3. Connect your smart device with the speaker via Bluetooth.
4. In Bluetooth mode, open EDIFIER ConneX App on your smart device.
5. Tap the menu for settings and playback control.
Note: The BLE connection between your smart device and the speaker remains
active when the speaker is switched to USB mode.
● EDIFIER TempoHub computer app
1. Access the link below to open the download page.
https://www.edifier.com/PC.html
2. Download and install the application on your computer.
3. Connect the speaker to your computer with the attached USB cable.
4. Switch the speaker to USB audio streaming mode.
5. Run the app on your computer for controls and settings.
Note: The following operating systems are supported: Windows 11, Windows 10,
and MacOS 10.15 or later versions.
2. What's in the box?
Cleaning cloth
Note:
•Images are for illustrative purposes only and may differ from the actual product.
•For the need of technical improvement and system upgrade, information and
specifications contained herein may be slightly different from actual product.
If any difference is found, the actual product prevails.
3. Cable connection
Power input: 5V
4. Power on/off
Press and hold the "
5. Audio inputs
USB audio streaming input
●
1. When the speaker is powered on for the first time, it will auto-enter USB audio
streaming mode (red LED).
•You can also press the "
2. Connect the speaker to your computer with the attached USB cable.
3. On the computer, open the sound settings, select "EDIFIER QS30" as its output
device, and then start playback.
Note:
•In USB audio streaming mode, volume sync is not supported. To adjust the volume,
adjust on the speaker and your computer separately.
•The following operating systems support USB audio streaming: Windows 11,
Windows 10, Windows 8, and Windows 7.
● Bluetooth input
1. Press the " " button to switch to Bluetooth mode (LED blinking in blue).
2. On your device, select "EDIFIER QS30" in its Bluetooth device list to connect,
and the blue LED will be steady lit when the connection is established.
•To disconnect from the current Bluetooth device, press and hold the "
button for 1.5 seconds.
Note:
•Pin code for connection is "0000" if needed.
•To enjoy all Bluetooth functions of this product, make sure that your audio
source device supports A2DP, HFP and AVRCP profiles.
•If no device is connected in 10 minutes, the speaker will switch to Bluetooth
hidden mode. The blue indicator will be in a breathing pattern. In this mode,
(1) new devices cannot find the speaker, but (2) for a device that exists in the
pairing record of this speaker, you can select "EDIFIER QS30" from its Bluetooth
device list to reconnect. To exit from Bluetooth hidden mode, press the "
button on the speaker.
● Bluetooth speakerphone
When the speaker is connected to your phone via Bluetooth and there is an incoming
call, you can
• press and hold the "
• press the "
• press the "
6. Light effects
•Press the " " button to switch light effects.
•Press and hold the "
7. Playback control
Button Action
Press to pause or resume the playback
Press to increase volume
Press and hold to skip to the next track
Press to decrease volume
Press and hold to skip to the previous track
8. Indicator status
Indicator status
Blinking in blue per 0.2s
Breathing in blue
Solid blue
Solid red
Blinking in blue and red
9. Specifications
Total output power (RMS): 2.5W+2.5W
Frequency response: 90Hz-18kHz
10. Troubleshooting
Cannot connect to your Bluetooth device
•Make sure that the distance between this product and your Bluetooth
device is less than 10 meters and there are no obstacles between them.
•Make sure that no device is connected to this product via Bluetooth.
•Make sure that this product is in Bluetooth pairing mode. If not, manually
switch it to this mode.
•Restart this product, enable Bluetooth function on your Bluetooth device,
and then try again.
•Reset this product to factory settings and try again.
No sound
•Make sure that this product is powered on.
•Make sure that this product and your device is properly connected.
•Make sure that the playback is not paused.
•Increase the volume of this product and your device.
To learn more about EDIFIER, please visit www.edifier.com
For EDIFIER warranty queries, please visit the relevant country page on
www.edifier.com and review the section titled Warranty Terms.
USA and Canada: service@edifier.ca
South America: Please visit www.edifier.com (English) or www.edifierla.com
(Spanish/Portuguese) for local contact information.
Multimedia Speaker
1A
" button to power on/off the product.
EDIFIER QS30
" button to switch to this mode.
x1
" button to reject the call,
" button to answer the call, and
" button to end the conversation.
" button to turn on/off the light.
QS30
Manual
Speaker
Quick start guide
EDIFIER QS30
2:12
2:12
Settings Bluetooth
Settings Bluetooth
Bluetooth
Bluetooth
DEVICES
EDIFIER D32
EDIFIER QS30
Speaker status
Bluetooth pairing mode
Bluetooth hidden mode
Bluetooth device connected
Switched to USB audio streaming mode
Upgrading the firmware
Important safety
instructions
"
"
