Summary of Contents for BSM BSM-FC40
- Page 1 Electrically Heated Furnace BSM-FC40 User Manual V4.1 2024.06.14 updated Chengdu Besmile Biotechnology Co., Ltd www.bsmdental.com...
-
Page 2: Table Of Contents
Content Chapter 1 Introduction ....................1 1.1 Preface ......................1 Chapter 2 Safety Information ..................2 2.1 Electrical safety ....................2 2.2 Operation safety ....................2 2.3 Safety signs ......................3 Chapter 3 Product Description ...................4 3.1 Product introduction ..................4 3.2 Appearance and dimension ................4 3.3 Main components .....................5 3.4 Technical parameters .................. -
Page 3: Chapter 1 Introduction
Chapter 1 Introduction 1.1 Preface Dear Customer, Thank you for purchasing BSM-FC40 from Chengdu Besmile Biotechnology Co., Ltd. The BSM-FC40 is an electrically heated sintering furnace specially designed for sintering zirconia material. The BSM-FC40 zirconia sintering furnace features a sintering chamber made with 1800-high purity alumina fiber boards, delivering exceptional insulation for flawless sintering outcome of zirconia restorations. -
Page 4: Chapter 2 Safety Information
The BSM-FC40 is exclusively designed for sintering zirconia restorations ONLY. Do NOT use it for sintering any flammable, explosive, or toxic objects. -
Page 5: Safety Signs
During the sintering process, the temperature of the furnace surface will reach up to about 60℃ and the temperature on the top of the furnace may reach over 80℃, posing a burn hazard, please avoid any direct skin contact. Please do not place any inflammable or explosive objects on the top of the furnace to avoid safety risks. -
Page 6: Chapter 3 Product Description
Standard sintering. It can also provide standard sintering for long bridges up to full arch. BSM-FC40 adopts 4 silicon carbide heating elements located all around the sintering chamber for sintering, which implements homogeneous temperature distribution and guarantees excellent sintering performance. -
Page 7: Main Components
①Sintering chamber: composed of high-purity silicon carbide heating elements and unique high-purity thermal insulation refractory materials, ensuring the purity of zirconia dental prosthetics after sintering. ②Sintering table: carrying the sintering tray with restorations; ③Electric control system: composed of controller, regulator, transformer, relay, etc., controlling the normal operation of BSM-FC40. -
Page 8: Technical Parameters
3H (cooling time including) Heating type Fast & Standard Table 2 Technical parameters 3.5 Data Interface The BSM-FC40 features a USB interface for system upgrades and updates. The USB port is located behind the display screen. Please contact the manufacturer if necessary. -
Page 9: Nameplate
3.6 Nameplate If the device goes wrong, please send the picture of nameplate with clear problem description to BSM authorized dealer or BSM. Figure 6 Nameplate... -
Page 10: Chapter 4 Transportation And Installation
BSM immediately. If no damage occurs, unpack the box. 2) Check the appearance of device for damage, deformation, etc. after unpacking. If any damage occurs, please take photos or videos and contact BSM immediately. 3) After unpacking，please check whether the components and parts are complete according to the accessories list (Refer to attachment). -
Page 11: Calibration
220V/50HZ) may cause damage to the control system. It is recommended to use voltage stabilizer. 6) Power on the device, click ‘BSM’ logo page anywhere once to enter main screen page， then click the 'Down' button to lower the sintering table, and remove protective material inside the sintering chamber. - Page 12 1) Put one PTCR ring and some waste of zirconia (especially white or light shade disc) into the sintering tray, then put the tray on the sintering table. 2) Click ‘Select program’，choose ‘BSM-S’ and click ‘Apply’, then click ‘Main screen’.
-
Page 13: Chapter 5 Operation And Cautions
The device is in boot state when the power switch is on. Figure 11 Power switch When it shows the ‘BSM’ logo page, single click the screen to enter the main screen Figure 12 Startup page... - Page 14 Figure 13 Main screen 5.1.2 Load the sintering trays with restorations Click “down” to lower the sintering table Figure 14 Lower the sintering table Put the restorations into the sintering tray, make sure that all the restorations have no contact with each other.
- Page 15 Figure 15 Load the sintering tray Click “Up” to lift up the platform Figure 16 Lift up the platform 5.1.3 Choose and apply the program you need Click “Select Program” to the program list page...
- Page 16 Figure 18 Sintering program list 5.1.3.1 For Aconia Zirconia blanks, you can choose the preset sintering program directly. For example, if you want to use the fast sintering program for BSM Aconia, please click “BSM-F” to the program edit page...
- Page 17 Figure 19 Choose “BSM-F” Then click “Apply” Figure 20 BSM-F When it shows “Saved successfully”, click “Confirm” then click “Main screen” Figure 21 Saved successfully...
-
Page 18: Operation
5.1.5 After sintering, take out the tray from sintering table. It is suggested to do it when the temperature is close to room temperature. 5.2 Operation page introduction BSM-FC40 is equipped with a touch screen for daily operation. Click anywhere on the ‘Startup page’ as shown in Figure 24 to enter the main screen. - Page 19 Figure 24 Startup page Figure 25 Main screen It shows the chamber temperature during sintering. (When the device is standby, this number is not the real temperature of sintering chamber.) The name of program which has been loaded for sintering The working segment of sintering program The total time for each segment...
- Page 20 Therefore, some parameters are write- protected, and changing these parameters requires an authorized password. Please contact BSM authorized dealers or BSM for assistance. To lift up the sintering table To lower the sintering table...
- Page 21 Figure 26 Current program Go back to main screen To set the temperature and time range for line chart PV: Process value, it’s the temperature in the sintering chamber during sintering. (When the device is standby, this number is not the real temperature of sintering chamber.) SV: Set point value, it’s the desired value for the PV.
-
Page 22: Sintering Programs
Figure 27 Data Click to show alarm or error message Figure 28 Alarm 5.3 Sintering programs 5.3.1 BSM-FC40 Sintering programs introduction After the device is turned on, click to enter sintering program list. - Page 23 Figure 29 Sintering program list BSM-FC40 fast sintering program, NO editing needed for most BSM Aconia (For TT white, the top temperature needs to be changed to 1480℃.) It’s only for single crowns and 3 units bridges. BSM-FC40 standard sintering program, NO editing needed for most BSM Aconia(For TT white, it needs to change the top temperature to 1480℃.)
- Page 24 5.3.2 BSM-FC40 fast sintering program Figure 30 BSM fast sintering program Temp Time/ Temp Time/ Temp Time/ Temp Time/ Temp Time/ eratur eratur eratur eratur eratur e/℃ e/℃ e/℃ e/℃ e/℃ 1530 1530 1000 Table 3 BSM fast sintering program...
-
Page 25: Customized Program
5.3.5 BSM-FC40 calibration program Figure 33 BSM calibration program Please use it under the guideline of BSM or BSM authorized dealer. 5.4 Customized program For other Zirconia brands, you need to edit the sintering program as the manufacturers’ requirement. - Page 26 Click “Select Program” to the program list page Figure 34 Select program Select any one from FOR5 to FOR20. Figure 35 Free program For example, when selecting FOR6 and entering the program setting interface, you can set a new program named ‘TEST’ and set temperature and time.
-
Page 27: Automatic Two-Stage Cooling Procedure
Figure 36 Program setting page In this context, "SP" represents each temperature stage, and "T" indicates the time required to change the temperature to the next stage. For example, in the above picture, SP1 is 40, T1 is 25, SP2 is 900, it means the furnace will take about 25min to increase the temperature from 40℃... -
Page 28: Operation Cautions
When temperature drops to 500℃, the sintering table will drop completely. If any question, please contact BSM or BSM authorized dealer. 5.6 Operation cautions Silicon carbide rods are ceramic products. Handle and install them with care to ... -
Page 29: Chapter 6 Maintenance
The suggested cleaning method is as following: ● Load the sintering tray with waste scraps of zirconia white disc. ● Sinter with the built-in 'BSM-CL' cleaning program. ● After sintering, check if the waste has any pigmentation. ● Repeat this cleaning process until the waste shows normal shade and... -
Page 30: Chapter 7 Trouble-Shooting
Chapter 7 Trouble-shooting 7.1 Heating element broken If the heating element is broken, for consistent performance, it is recommended to replace all the 4 rods in the same batch at the same time, as mixing old and new rods with different resistances can lead to uneven loads and premature wear. If older rods are still functional, keep them in the same batch. -
Page 31: Sintering Result Problem
4.4 for detailed information. 7.3 Other problems If you meet any other problems, please take some pictures or videos, and also a picture of the nameplate, contact BSM authorized dealer or BSM, we will help you as soon as possible. -
Page 32: Chapter 8 Warranty And Liability
Chapter 8 Warranty and liability Within 12 months from the date of delivery, if the equipment unable to work due to product quality problems, the company shall provide users with the free services (except artificial damage). Vulnerable accessories: heating element, sintering table, crucible, zirconium beads are not covered by the warranty. -
Page 33: Chapter 9 Contact Information
Chapter 9 Contact Information 9.1 Company information Thank you for choosing Besmile Zirconia Sintering Furnace for your laboratory needs. For any questions or additional support, please contact us and we will look forward to assisting you. Chengdu Besmile Biotechnology Co., Ltd. No.9,Sec.2, Shengwucheng North Rd., Chengdu Tianfu International Bio-Town, Shuangliu District, Chengdu, Sichuan 610200, P.R.China.
