- Page 1 Level 2 Electric Vehicle Charger ADJUSTABLE CURRENT □ □ 8A-32A or 8A-40A TIMER DELAY BETWEEN 1-8 HOUR RANGE □ □ NEMA 14-50 or 6-50 PLUG NEMA 14-50 or 6-50 -> 5-15 Level 1 Adapter User Manual & Instruction Guide...
- Page 2 Product Safety Certifications...
- Page 3 TABLE OF CONTENTS Product Information, Specs & Safety Model & Product Overview…..………………..………………..……………… Page 4 Display Screen Functions…..………………..………………..……………….. Page 4 Product Specs………..………………..………………..………………..…… .. Page 5 Safety Instructions………………………………………………………………. Page 6-9 Charging with NEMA 14-50 or NEMA 6-50 to NEMA 5-15 Adapter………. Page 10 Charger Features.………………..………………..………………..…………..
-
Page 4: Model Numbers
Model & Product(s) Overview MODEL NUMBERS: HWP132A HWP140A HWP132A-650 HWP140A-650 HWP1-32A-1450 HWP1-40A-1450 HWp1 HWp1 Level 2 EV Charger (23ft. or 25ft. Cable) Level 2 EV Charger (23ft. or 25ft. Cable) ADJUSTABLE CURRENT ADJUSTABLE CURRENT 8A/12A/16A/20A/24A/32A 8A/10A/12A/16A/20A/24A/32A/40A TIMER DELAY TIMER DELAY 1-8 HOUR RANGE 1-8 HOUR RANGE NEMA 14-50 or 6-50 PLUG... - Page 5 Product Specifications Specifications Description Current (Adjustable) 8-32 Amps (8,12,16, 20, 24, 32) 8-40 Amps ((8,12,16, 20, 24, 32, 40) EV Connector Type SAE J1772 (Type 1) Power Plug Type(s) - NEMA 14-50 or 6-50 (Wired to EV Charger) - NEMA 14-50 or 6-50 to 5-15 Connector Portable Cable Adapter (MAX AMPERAGE 12 AMPS &...
-
Page 6: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This document contains instructions and warnings that must be followed when installing and using the Hardwiire Electric Vehicle Supply Equipment (EVSE). Before installing or using the EVSE, read this document thoroughly to understand any WARNING and CAUTION symbols. PLEASE NOTE: It is highly recommended that electrical outlets for your charger should be installed by a licensed and qualified electrician. - Page 7 • Only use a charger with a dedicated circuit breaker with a fault current. • DO NOT put fingers into the J1772 EV connector plug. • DO NOT touch live electrical parts. • DO NOT step on the charging cable, pull it, fold it up or knot it. •...
- Page 8 NOTE: PLEASE BE AWARE THAT IMPROPER USE OR MISUSE OF THIS EV CHARGER CAN RESULT IN PERSONAL INJURY, ELECTRIC SHOCK, OR FIRE. NORMALLY GROUNDED CONDUCTORS AND EXPOSED CONDUCTING PARTS MAY BE UNGROUNDED & ENERGIZED. FOLLOW THE INSTRUCTIONS AND ENSURE YOU SET YOUR AMPERAGE TO THE APPROPRIATE DRAW FOR YOUR ELECTRIC BREAKER.
- Page 9 WARNING The Hardwire Charging Station should be connected to a Standard NEMA 14-50 or 6-50 Receptacle when charging for extended and repetitive periods of time. This charging station can be OCCASIONALLY used with the NEMA 14-50 or 6-50 to NEMA 5-15 Adapter ensuring the MAXIMUM AMPERAGE is adjusted to 12 AMPS and/or UNDER (example 8A, 12A).
- Page 10 IMPORTANT NOTE PRIOR TO USING NEMA 14-50 or 6-50 to NEMA 5-15 ADAPTER: DO NOT EXCEED 12 AMPS WHEN USING THE NEMA 14-50 or 6-50 to NEMA 5-15 ADAPTER. THE ADAPTER IS NOT RATED FOR A CURRENT HIGHER THAN 12 AMPS.
-
Page 11: Amperage Draw
Before we get into the instructions on Page 15 on How To Set Up and Use Your Charger, you should know your charger is capable of the following settings: AMPERAGE DRAW This amperage current on the chargers are adjustable to the following draws: 8-32A: 8 Amps, 12 Amps, 16 Amps, 20 Amps, 24 Amps &... - Page 12 Introduction & Unpacking Your charger - All Parts & Buttons...
-
Page 13: Carrying Case
Back of Charger. Mount Hole & Screws Carrying Case & NEMA 14-50 or 6-50 to NEMA 5-15 Adapter CARRYING CASE NEMA 14-50 or 6-50 to NEMA 5-15 Adapter J1772 Connector Holder & Cable Management System... -
Page 14: Safety Check
Installation of Housing Control Box Step 1) Using a Screwdriver or Drill with a Phillips Drill bit; Fasten the Anchor/Screw Combo or Screw securely to a wall in a well-structured area (preferably a stud). Step 2) Once the screw is secured, insert the back of the charger screw hole to the fastened screw on the wall. - Page 15 Charger Set Up Guide - Plugging In & Setting up...
- Page 16 Charging Charging Status & Technical Information INDICATOR LIGHT MEANING DEFINITION COLORS POWER ON (J1772 Connector Not STAYS ON Plugged Into Car) ( SOLID GREEN) SUCCESSFUL CONNECTION & TIMER DELAY SET FLASHING GREEN (Upon Plugging J1772 Connector Into Car) CHARGING VEHICLE FLASHING BLUE CHARGING COMPLETE...
- Page 17 Troubleshooting & Technical Support When a charging session is interrupted due to a temporary error condition, it is best to perform a reset by doing the following: 1. Count the number of flashes to identify the error type. 2. Unplug the charging Connector from your EV. 3.
- Page 18 The warranty for the cable does not include normal tear and wear. Plugs that have been exposed to snow or water for a prolonged period of time are not covered by this warranty. The warranty will apply only if the product is defective. Hardwiire assumes no liability for any dismantling, removal, installation, re-installation, or labor costs or any consequential damages associated with this warranty.
