- Page 1 USER’S OPERATION MANUAL Before operating this unit, please read this manual thoroughly, and retain for future reference. WD105M3P WD105M3* English...
- Page 2 Thank you very much for choosing our product. Please install and operate this product correctly. Do not use it for any laundry labelled as not suitable for machine washing. The pictures shown in the manual are for illustrative purposes only. Appearance, printing and other details are subject to actual product.
-
Page 3: Table Of Contents
CONTENTS SAFETY PRECAUTIONS INTRODUCTION PRODUCT DESCRIPTION Specifications PREPARATION INSTALLATION AND CONNECTION BEFORE Removing the transport screws/rods FIRST USE Moving and transport after installation Installation location Adjustable feet Installation clearance Connecting to water supply Connecting and securing the discharge hose Connecting to power mains BEFORE USING THE APPLIANCE FOR THE FIRST TIME PROGRAMME AND FUNCTIONS WASHING STEPS... -
Page 4: Safety Precautions
SAFETY PRECAUTIONS Please read this manual carefully before operating the Please read this manual carefully before operating the Please read this manual carefully before operating the Please read this manual carefully before operating the Please read this manual carefully before operating the Please read this manual carefully before operating the appliance. -
Page 5: Electrical Safety
To connect the washer dryer to water supply, make sure to use the supplied To connect the washer dryer to water supply, make sure to use the supplied To connect the washer dryer to water supply, make sure to use the supplied To connect the washer dryer to water supply, make sure to use the supplied To connect the washer dryer to water supply, make sure to use the supplied To connect the washer dryer to water supply, make sure to use the supplied... -
Page 6: Installation
Do not connect multiple power sockets, extension cords or dual adapters to the Do not connect multiple power sockets, extension cords or dual adapters to the Do not connect multiple power sockets, extension cords or dual adapters to the Do not connect multiple power sockets, extension cords or dual adapters to the Do not connect multiple power sockets, extension cords or dual adapters to the Do not connect multiple power sockets, extension cords or dual adapters to the appliance. - Page 7 Do not install the appliance near heaters or flammable materials. Do not install the appliance near heaters or flammable materials. Do not install the appliance near heaters or flammable materials. Do not install the appliance near heaters or flammable materials. Do not install the appliance near heaters or flammable materials.
- Page 8 Place laundry completely into the drum to prevent it from getting caught in the Place laundry completely into the drum to prevent it from getting caught in the Place laundry completely into the drum to prevent it from getting caught in the Place laundry completely into the drum to prevent it from getting caught in the Place laundry completely into the drum to prevent it from getting caught in the Place laundry completely into the drum to prevent it from getting caught in the...
-
Page 9: Child Safety
WATER OVERFLOW PROTECTION (WITH APPLIANCE SWITCHED ON) WATER OVERFLOW PROTECTION (WITH APPLIANCE SWITCHED ON) WATER OVERFLOW PROTECTION (WITH APPLIANCE SWITCHED ON) WATER OVERFLOW PROTECTION (WITH APPLIANCE SWITCHED ON) WATER OVERFLOW PROTECTION (WITH APPLIANCE SWITCHED ON) WATER OVERFLOW PROTECTION (WITH APPLIANCE SWITCHED ON) If the water level in the appliance rises above normal level, then the excess If the water level in the appliance rises above normal level, then the excess If the water level in the appliance rises above normal level, then the excess... -
Page 10: Product Description
PRODUCT DESCRIPTION FRONT Control unit Programme selector knob Detergent drawer Door Pump filter cover BACK Water supply hose Power cord Water discharge hose Adjustable feet Transport screws/rods The illustrations in this manual are for illustrative purposes only. Due to product improvements and series expansion, the appearance, color, and functional components of the product you receive may differ from those shown in this manual. -
Page 11: Specifications
SPECIFICATIONS (DEPENDING ON THE MODEL) WD105M3/WD105M3* Model 10.5kg/7kg Maximum Washing/Drying Capacity 64kg Net Weight 220-240V~ Rated Voltage 50Hz Frequency 1600W/1200W Rated/Drying Power DIMENSIONS (MM) Index Dimensions (mm) 1060 E = Washer dryer depth F = Depth with door open... -
Page 12: Installation And Connection
INSTALLATION AND CONNECTION First remove all packaging and foam, especially the foam base. When removing the packaging, make sure not to damage the appliance with a sharp object. Keep the packaging materials (plastic bags, other plastic parts etc.) out of reach of children. Check for any damage on the appliance. -
Page 13: Removing The Transport Screws/Rods
REMOVING THE TRANSPORT SCREWS/RODS Disassemble the transport screws/rods once all packaging has been removed. A blocked appliance may be damaged when it is switched on for operation. Such damage is not covered by the warranty. Move aside the water discharge hoses and use an appropriate wrench to loosen the four screws on the back in the counterclock-... -
Page 14: Installation Location
INSTALLATION LOCATION Place the appliance on a solid and level floor to keep it stable. The floor should be clean and dry; otherwise, the washer dryer may slide. Also, clean the bottom surface of adjustable feet. ADJUSTABLE FEET Use a spirit level and the supplied wrench. Rotate the adjustable feet to level the After adjusting the height of the feet, use the washer dryer lengthwise and crosswise. -
Page 15: Connecting To Water Supply
CONNECTING TO WATER SUPPLY The supplied water supply hose varies by model. Please choose the appropriate connection method based on the actual water supply hose. EUROPEAN WATER SUPPLY HOSE CONNECTION AQUA STOP CONNECTION CHINESE WATER SUPPLY HOSE CONNECTION For normal washer dryer operation, the pressure in the water mains should be between 0.03-0.8MPa (1-10 bar;... - Page 16 AQUASTOP CONNECTION If an internal tube or hose is damaged, a shut-off system is activated that cuts the water supply to the appliance. In such case, the control glass (a) will turn red. Replace the water supply hose. Do not dip the water supply hose with the AquaStop system in water as it contains an electric valve.
- Page 17 CHECKING THE CONNECTION BETWEEN THE WATER SUPPLY HOSE AND THE TAP 1. Gently pull the water supply hose to check if the connection is secure. 2. Open the tap to check for leaks. 3. The water supply hose should not be twisted or bent. 4.
-
Page 18: Connecting And Securing The Discharge Hose
CONNECTING AND SECURING THE WATER DISCHARGE HOSE Feed the water discharge hose into a washbasin or a bathtub, or connect it directly to a drain (discharge hose minimum diameter 4 cm). The vertical distance from the floor to the end of the discharge hose may be 70 to 100 cm. -
Page 19: Connecting To Power Mains
CONNECTING TO POWER MAINS 2 hours Before connecting the washer dryer to the power mains, wait for at least 2 hours until it reaches room temperature. Connect the washer dryer to a grounded power socket. After installation, the socket should be freely accessible. -
Page 20: Before Using The Appliance For The First Time
BEFORE USING THE APPLIANCE FOR THE FIRST TIME FIRST USE This appliance has been tested at the factory and may contain a small amount of water residue. It is recommended to run a “Drum Clean” (or other high-temperature) programme to remove any residual water from the drum. - Page 21 NON-WASHABLE AND NON-DRYABLE LAUNDRY Leather and fur products Rayon and its blended products (risk Large thick rubber cushions (risk of (risk of deformation) of discolouration or deformation) damage or malfunction) Others: Wrinkled or embossed clothes; coated down jackets; crepe fabrics; easily deformed clothes (suits, Cushions, pillows, articles with jackets, ties, dresses, etc.);...
-
Page 22: Precautions For Use
ADDING DETERGENT/SOFTENER DETERGENT DRAWER Detergent drawer Detergent dispenser compartment Softener dispenser compartment Water magic box * The water magic box can be used to treat water quality, effectively reducing scale buildup and preventing fabrics from yellowing and hardening. * Do not add detergent/softener to the water PRECAUTIONS FOR USE purification compartment of the water magic box. - Page 23 LOADING THE WASHER DRYER Open the washer dryer door, and insert the laundry loosely into the drum after making sure the drum is empty. Close the washer dryer door. The door is closed when you here a click. Do not overload the drum! For maximum load, see "PROGRAMME TABLE". If the washer dryer drum is too full, the laundry will not be washed as thoroughly.
-
Page 24: Programme And Functions
PROGRAMME AND FUNCTIONS CONTROL UNIT Final layout may vary. Power Cycle Selector Start/Pause Briefly press the button to Rotate the main knob to Switch on/off the appliance. start/pause the programme. select a desired One Touch AI Wash programme. Press and hold the button to enable the AI Wash programme. -
Page 25: Programme Table
PROGRAMME TABLE Choose the programme by rotating the main knob to the left or right (depending on the type of laundry and how heavily soiled it is). During operation, the main knob will not rotate automatically. Max. Max. spinning Programme Programme description Functions load (kg) - Page 26 Max. Max. spinning Programme Programme description Functions load (kg) rate rpm Additional Cycles Shirts It is suitable for washing shirts made from cotton, linen, synthetic fibers, or (-- ,20℃,30℃, 40℃, 1400 blended fabrics. 60℃) Outdoor It is suitable for washing athletic and leisure wear made from microfiber 1400 (-- ,20℃,30℃, 40℃,...
-
Page 27: Other Settings And Functions
OTHER SETTINGS AND FUNCTIONS Most programmes feature basic settings, but these settings can be changed. Adjust the settings by pressing the relevant function button (before pressing the START/PAUSE button). Certain settings cannot be selected with some programmes. Such settings will not be lit, and when the corresponding button is pressed, an acoustic signal will be emitted (see function table). - Page 28 Rinse Adjust the washing time before starting the programme. Press this button repeatedly to cycle through the preset values. Each press adjusts the number of rinses, from a maximum of 4 (P-4) to a minimum of 1 (P-1). Spin Adjust the spinning rate before starting the programme. Press this button to display the current set spinning rate.
- Page 29 Child Lock The appliance features a child lock to prevent accidental operation by children and ensure their safety. Press and hold the 'Wash + Rinse' buttons simultaneously to activate the child lock. The child lock icon " " lights up. Repeat the same operation to deactivate the child lock. When the Child Lock is set, all buttons except the power button are locked.
-
Page 30: Function Table
FUNCTION TABLE Programme Cotton Al Wash Quick 15' W/D60' Colors Baby Care Intensive Bedding Air Wash Rinse+Spin Spin Drum Clean Shirts Outdoor Underwear Optional functions Non-optional functions Non-cancellable built-in default functions... -
Page 31: Smart Networking
SMART NETWORKING Enter the “Settings” interface on your smartphone or tablet, enable Bluetooth and wireless connections, and connect to a wireless network. NOTE: This appliance supports 2.4 GHz Wi-Fi. When the Wi-Fi function is enabled, the power consumption of the appliance increases. However, the Wi-Fi power is less than 2W, so it does not affect the energy efficiency rating of the appliance. -
Page 32: Starting Programme
STARTING PROGRAMME Once you have selected the programme and extra functions, and added the detergent into the detergent drawer, press the "Start/Pause" button to start the programme. Once you have pressed the Start/Pause button, you cannot change any settings except to enable/disable Child Lock and Mute (if available) and adjust the Water Level (if available). -
Page 33: Interruptions And Changing The Programme
INTERRUPTIONS AND CHANGING THE PROGRAMME INTERRUPTION THE PROGRAMME To stop or cancel the programme during operation, you must switch off the appliance. CHANGING THE PROGRAMME To change the programme during operation, switch the appliance off and on again, select the desired programme and extra functions, then press the Start/Pause button to start the new programme. -
Page 34: Emergency Door Opening
EMERGENCY DOOR OPENING In case of failure to open the door due to power outage or other special circumstances, the door lock lever at the pump cover can be used for emergency opening. NOTE: 1. Do not use this function when the appliance is working normally. 2. -
Page 35: Maintenance And Cleaning
MAINTENANCE AND CLEANING Regular maintenance can extend the service life of the appliance. Before maintenance, unplug the washer dryer from the power mains and close the water tap. Children should not clean the washer dryer or perform maintenance tasks without proper supervision. -
Page 36: Cleaning The Water Supply Hose, Detergent Dispenser Housing, And Rubber Door Gasket
CLEANING THE WATER SUPPLY HOSE, DETERGENT DIS- PENSER HOUSING, AND RUBBER DOOR GASKET Clean the water supply hose filter regularly. Use a brush to clean the entire detergent dispenser housing, especially the nozzles on the top. After every wash, wipe the rubber door seal to extend its life cycle. -
Page 37: Cleaning The Pump Filter
CLEANING THE PUMP FILTER Water may be spilled when cleaning the pump filter. lt is therefore recommended to place an absorbent cloth on the floor. Make sure the water has cooled down before you release it from the appliance. Open the pump filter cover.Type 1: Press the pump filter cover to pop it open.Type 2: Use a suitable... -
Page 38: Cleaning The Inlet Filter
CLEANING THE INLET FILTER Check and clean the inlet filter regularly. Close the water tap Clean the inlet filter immediately if water supply is slow. and unscrew the Operation procedures are as follows: water supply hose. Remove the inlet filter. Clean the inlet filter. -
Page 39: Troubleshooting
TROUBLESHOOTING The appliance is equipped with a number of automatic safety features to detect faults and take effective safety measures in a timely manner. These faults are usually minor and can be rectified quickly. If the appliance cannot operate normally, a fault message will appear on the screen. Please refer to the warning message for the appropriate action. - Page 40 Fault phenomenon Recommended countermeasures Foreign objects such as keys, coins or pins may have fallen into the drum. Stop the appliance and check for foreign Abnormal objects in the drum. If noise persists after restarting, please sound/noise during contact after-sales service. washing Laundry may be unevenly distributed in the drum.
- Page 41 DRY FAULT (FOR TUMBLE DRYER MODELS) Fault phenomenon Recommended countermeasures Check whether the drying programme is set up. Check whether the water tap is unopened. Washer dryer Check whether the door is properly closed. does not carry out Check whether the load is excessive (see PROGRAMME drying process TABLE for capacity requirements), and take out part of the laundry to dry again.
-
Page 42: Fault Codes And Troubleshooting
FAULT CODES AND TROUBLESHOOTING If the unit is not operating normally and the following codes are displayed, this may not indicate a fault. Please refer to the FAULT CODES for appropriate action. Problem/Fault Description What to do? Check the following: Water inflow fault 1. -
Page 43: Servicing
SERVICING BEFORE CALLING A SERVICE TECHNICIAN When you contact the service centre, please specify your appliance model. The model, code / lD, type and serial number are indicated on the nameplate of the appliance. In case of a defect, only use spare parts approved by authorised manufacturers. Repairs or warranty claims due to incorrect connections or misuse of the appliance are not covered by the warranty. -
Page 44: Stain Removal Tips
STAIN REMOVAL TIPS Before using special-purpose stain removers, try using the natural methods that do not harm the environment on less stubborn stains. However, timely treatment makes stain removal easier! Remove stains by rinsing with cold (lukewarm) water - but never with hot water! Stains Stain removal When the stain is dry, first scrape it off the laundry before washing it in the washer... - Page 45 Stains Stain removal Place the laundry in a bag and put it in the freezer until the stain hardens. Then Glue, chewing gum remove it with a blunt knife. Dilute the stain with a prewash stain remover and rinse thoroughly. Finally, wash the laundry in the appliance.
-
Page 46: Disposal
DISPOSAL Packaging is made of environmentally friendly materials that can be recycled, disposed of, or destroyed without any hazard to the environment. To this end, packaging materials are labelled appropriately. The symbol on the product or its packaging indicates that the product should not be treated as normal household waste. - Page 47 Careline Operation Hours:Monday to Sunday 8am to 7pm. 2433679-X08063399A...
