Summary of Contents for JOYROOM JR-OE2
- Page 1 JR-OE2 开放式 TWS 蓝牙运动耳机 Open-Ear True Wireless Headphones User Manual 一、封面 I. Product picture...
- Page 2 二、产品图示 II. Product diagram ①耳机多功能按键 ②耳机指示灯 ③耳机麦克风 ④耳机充电触点 ⑤耳机出音孔 ① Headphone multifunctional button ② Headphone indicator ③ Microphone ④ Headphone charging contact ⑤ Audio out ⑥充电盒充电触点 ⑦充电盒指示灯 ⑧充电盒多功能按键 ⑨充电盒 Type-C 充电接口 ⑥ Case charging pin ⑦ Case indicator ⑧ Case multifunctional button ⑨...
- Page 3 三、包装清单 III. Packing list 1. JR-OE2 耳机 2. 充电配线 3. 消毒棉签 4. 说明书&保修卡 1. JR-OE2 headphones 2. Charging cable 3. Disinfection cotton swab 4. User Manual & Warranty Card 四、基本参数 IV. Basic parameters 产品名称：开放式 TWS 蓝牙运动耳机 型号：JR-OE2 蓝牙版本：V5.3 音频解码：AAC、SBC 支持协议：HFP、A2DP、AVRCP 工作频率：2402MHz-2480MHz...
- Page 4 Name: Open-Ear True Wireless Headphones Model: JR-OE2 BT version: V5.3 Audio decoding: AAC, SBC Supported protocols: HFP, A2DP, AVRCP Working frequency: 2402MHz-2480MHz BT range: 10m (barrier-free open environment) Frequency response range: 20Hz-20KHz Speaker: φ16.2mm Music time: about 10h (70% volume)
- Page 5 2. When the main headphone indicator flashes orange and white alternatively, and the auxiliary headphone indicator flashes white every 5s, it means the headphones are ready for pairing. 3. Turn the phone’s BT function on and search for the BT device " Joyroom Openfree OE2", connect with it.
- Page 6 通话状态功能 Call function 接听/挂断电话 单击耳机多功能按键 Answer/end call Click the multifunctional button of the headphone 拒接来电 长按耳机多功能按键 2 秒 Reject call Press and hold the multifunctional button of the headphone for 2s 语音助手功能 Voice assistant 唤醒语音助手 三击耳机多功能按键 Activate voice Triple-click the multifunctional button of the headphone assistant 充电盒多功能按键功能说明...
- Page 7 ② If your phone uses iOS system, it may be that the headphones did not reconnect to your phone in time. You can check whether the device name "Joyroom Openfree OE2" is in the phone’s BT list. If so, please directly click the device name for connection.
- Page 8 Q： 耳机单边无音如何解决？ A： ①请将手机蓝牙列表中已连接的耳机配对名删除； ②关闭手机蓝牙，将两只耳机放入充电盒； ③30 秒后，将耳机从充电盒取出，重新开启手机蓝牙进行搜索配对； ④若以上操作无效，您可以对耳机进行恢复出厂设置。 Q: Why only one headphone has sound? A: ① Please delete the connected headphones’ name from your phone’ BT list. ② Turn off the phone’s BT function, put the two headphones into the charging case. ③...
- Page 9 安全准则 1. 请遵循本说明书的使用说明，勿以任何理由拆卸或改装产品，否则可能导致 产品发生故障或烧毁； 2. 请勿将产品浸入任何液体或用水冲洗产品； 3. 请使用符合国家/地区安全性标准的适配器搭配充电配线给产品充电，否则容 易造成产品电池损坏或发生危险； 4. 请在常温环境中使用和存放本产品，勿将产品置于温度过低或过高（0℃以下 或者 45℃以上）的环境中； 5. 请勿堵塞产品的开口处，如充电口、指示灯口等； 6. 请避免过大音量或者过长时间使用产品，避免造成头晕或对听力造成伤害。 7. 请勿在雷暴天气下使用设备，雷暴可以导致产品工作不正常，信号中断等现 象。 Safety Criteria 1. Please follow the instructions, do not disassemble the product or refit it for any reason, otherwise it may break down or burn down. 2.
- Page 10 保修卡 用户姓名： 用户电话： 用户地址(含邮编) 购机日期： 发票编号： 销售单位名称： 销售单位地址(含邮编)： 销售单位电话： 保修服务： Warranty Card User Name: User Tel: User address (with postcode): Purchase date: Invoice No.: Dealer Name: Dealer address (with postcode): Dealer Tel: Warranty service:...
- Page 11 保修服务说明 A.在正常使用本产品过程中,如果本产品出现非人为损坏的性能故障,自购买之日 起,消费者享受 免费保修服务。保修期为 12 个月。 B.有下列情况之一,消费者不能享受免费保修权益: *人为损坏; *超过保修期; *不能提供有效的购买凭证; *未按说明书要求使用、维护、保养而造成产品损坏; *未经授权,擅自拆卸、维修产品,或产品浸水; *其他不可抗力造成的损坏。 Warranty service instructions: A. If there is performance failure on this product and it’s not caused by human error, we will provide a 12-month free warranty service for consumers from the date of purchase. B.
- Page 12 FCC Caution： This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
