DEFORD New Power Li+HUB HV20 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
+
Li
HUB HV20 User Manual
V1.0
+
Li
HUB HV20
User Manual
Prior to installation and use, read and understand product safety information. Failure to follow the
instructions may result in Electric Shock, Explosion, or Fire, which may result in Serious Injury, Death,
Damage to Device or Property. Do not discard this information.
Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Li+HUB HV20 and is the answer not in the manual?

Questions and answers

Related Manuals for DEFORD New Power Li+HUB HV20

Summary of Contents for DEFORD New Power Li+HUB HV20

  • Page 1 Electric Shock, Explosion, or Fire, which may result in Serious Injury, Death, Damage to Device or Property. Do not discard this information. Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 2: Table Of Contents

    6. Operating Energy Storage System……………………………………………..…………………………..26 6.1 Start-Up Energy Storage System…………………………………….…………………………………………………….26 6.2 Shutdown Energy Storage System………………………………………………………………..……………………….27 7. Maintenance……………….…………………………….…….……………………………………………..28 8. Uninstallation & Disposal……………………………………………………………………………………29 8.1 Uninstallation…………………………………………………………………………………………………………………29 8.2 Disposal……………….………………………….…………………….…………………………………………………….29 Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 3: Safety Precautions

    Bind cables of the same type together. When routing cables of different types, ensure that they are at least 30 mm away from each other. Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 4: Battery Safety

    Eye contact: Immediately flush your eyes with water for at least 15 minutes, do not rub your eyes, and seek medical attention immediately. Skin contact: Wash the affected areas immediately with soap and water and seek medical attention immediately. Ingestion: Seek immediate medical attention. Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 5: Storage And Transportation

    Recommendations on the Transport of Dangerous Goods: Manual of Tests and Criteria) and SN/T 0370.2-2009 (Part 2: Performance Test of the Rules for the Inspection of Packaging for Exporting Dangerous Goods). This product belongs to Class 9 dangerous goods. Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 6: Installation Safety

    Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 7: Maintenance And Replacement

    If the equipment is not used for a long time, store and recharge batteries according to this document.  If the equipment is faulty, contact your dealer, distributor, or installer.  Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 8: Product Specifications

    3 phase hybrid inverter (not included) 10 kVA for continuous Output AC Power 11 kVA for peak Frequency Range 50/60 Hz Round Trip Efficiency @ AC coupled Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.
  • Page 9 Indoor and outdoor Altitude 2000 m Installation Floor mount Environmental RoHS Directive 2011/65/EU UL 1973, UL 9540 Certifications (pending) EN62619, EN62477-1, EN61000-6-1/3 UN38.3 Shipping UN3480, Class 9 Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 10: Appearance

    HUB HV20 User Manual V1.0 2.3 Appearance Figure 2-1 HV20 Drawing Liquid Cooling Device HV20 Cabinet Protective Cover Power Connector - DC Switch COM Port input/output Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.
  • Page 11 Battery module positive output output Shunt trip circuit breaker Battery module positive input Battery module negative input Power connector - Liquid cooling device power input/output supply + COM Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 12: Working Mode

    Battery control unit (BCU) gets into shut down mode. HV20 Sleep mode ≤500uA output is closed, but input is opened. 2.5 Label Description Figure 2-4 Label on MagicPack 2.0 Battery Module Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 13: Function

    Please contact your local support team to set up the ToU mode. Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 14: Backup Mode

    1. If the battery SOC drops to a minimum threshold during backup mode. The microgrid will be deactivated, and the system will go to ‘sleep mode’. The backup loads and the external PV inverter on the micro-grid will disconnect consequently. Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.
  • Page 15 (Refer to 2.5 Working Mode). 3. Otherwise, the microgrid will keep in “sleep mode” to prevent battery over-discharge event. Figure 3-2 Partial Home Backup Figure 3-3 Whole Home Backup Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 16: System Installation

    Cable cutter Screwdriver Torque socket Wire strippers Hammer drill Torque wrench wrench Personal protective equipment (PPE) Safety gloves Safety goggles Dust mask Safety boots Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 17: Installation Positioning

    During installation, ensure that there is no other devices or flammable or explosive materials around the HV20. Reserve adequate space for heat dissipation and safety isolation. Figure 4-1 Installation Space. Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 18: Wall Mount Installation

    The forklift needs to be operated by certified personnel, and any impact on the HV20 should be avoided during operation. Figure 4-2 Concrete Base Concrete base height is ≥150mm User level ruler to check surface is flat Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.
  • Page 19 It is necessary to use forklift to place HV20 on the concrete base.  The forklift needs to be operated by certified personnel, and any impact on HV20 should be avoided during operation. Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.
  • Page 20 M12x60 expansion bolts delivered with HV20 are used to fix the corner code. If the length and quantity of the bolts do not meet installation requirements, prepare expansion bolts by yourself. Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.
  • Page 21 Install and tighten all the screws, nuts on the left and right corner codes.  If specification, or quantity of the screws, nuts do not meet installation requirements, prepare them by yourself. Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 22: Electrical Connection

    The DC Input/Output power cable and COM cable between the product and (hybrid) inverter must be less  than or equal to 5 m. Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 23: Install External Ground Cable

    External ground cable is delivered with the product. Re-work the OT terminal if it is not compatible with external ground point. Figure 5-1 Install External Ground Cable. Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 24: Install External Power Cables

    Wrap the wire crimping area with heat shrink tubing or insulation tape.  When using a heat gun, protect the equipment from being scorched. Figure 5-2 Install External Power Cables. Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 25: Install External Com Cable

    When laying out a COM cable, separate it from power cables and keep it away from strong interference sources to prevent communication interruption.  Refer to Figure 5-3 to check COM port definitions. Figure 5-3 Install External COM Cable Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 26: Operating Energy Storage System

    Turn on PV switch on hybrid inverter if available. Turn on HV20 shunt trip circuit breaker. Turn on HV20 DC switch. Figure 6-1 Power ON HV20 Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 27: Shutdown Energy Storage System

    Disconnect the AC circuit breaker to prevent it from being reactivated. Turn off HV20 shunt trip circuit breaker. Turn off PV switch on hybrid inverter if available. Figure 6-2 Power OFF HV20 Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 28: Maintenance

    Table 7-2 SOC vs charge interval Power-Off SOC Before Storage Maximum Charge Interval SOC > 10% 30 days 0% < SOC ≤ 10% 7 days Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.

  • Page 29: Uninstallation & Disposal

    The HV20 and the batteries it contains must not be disposed of as domestic waste!  Dispose of the HV20 and the batteries it contains in an environmentally friendly way through suitable collection systems. Copyright © LiHUB Energy is a wholly owned subsidiary of DEFORD New Power Co., Ltd.
