Summary of Contents for Broadata Communications LINK BRIDGE LB-H2-SGA

Page 1 IGNAL ENERATOR AND NALYZER BCI reserves the right to make changes to the products described herein without prior notice or consent. No liability is assumed as a result of their use or application. All rights reserved. ©2013 Broadata Communications, Inc.
Page 2 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer SAFETY INSTRUCTIONS AND COMPLIANCE DECLARATIONS PLEASE OBSERVE THE FOLLOWING SAFETY PRECAUTIONS AS OUR PRODUCTS CONTAIN SURGE PROTECTION DEVICE RECOMMENDED This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lightning strikes, etc.
Page 3: Table Of Contents
LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer TABLE OF CONTENTS 1.0 PRODUCT DESCRIPTION ..........5 2.0 OPERATION CONTROL AND FUNCTIONS ....6 2.1 FRONT PANEL ...............6 2.2 TOP PANEL ..............10 2.3 BOTTOM PANEL ............10 2.4 LEFT PANEL ..............11 2.5 RIGHT PANEL ...............
Page 4: Product Description
LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer 1.0 PRODUCT DESCRIPTION Features · HDMI 2.0 (up to 4K@60Hz 4:4:4) and HDCP 1.4/2.2 compliant · Not only extend HDMI video, but also provide in-line control I/O paths, over HDBaseT link ·...
Page 5: Operation Control And Functions
LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer OPERATION CONTROLS AND FUNCTIONS 2.1 Front Panel No Signal 5V=0 CKDT=0 SCDT=0 ENTER MENU OPTION EDID HDCP COLOR TIMING PATTERN PATTERN PATTERN SPACE AUDIO HDCP DEEP OUTPUT ANALYSER LPCM ON/OFF COLOR FORMAT...
Page 6 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer No Signal 5V=0 CKDT=0 SCDT=0 +5v pin Sync signal detection detection TMDS clock detection 3D HDMI/DVI Resolution 1920x1080p24 HDMI HDCP1 M Y444 12B LPCM HDCP Color Color 1.4/2.2 space depth Audio General control...
Page 7 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer 2. IR Window: Accepts IR signals from the included IR remote for control of this unit only. 3. MENU: Press to enter the OSD menu, or to back out from menu items.
Page 8 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer FACTORY RESET: Press and hold this button while powering the unit on to perform a factory reset of the unit. 9. EDID PATTERN: Press to enable selection of the EDID to use on the HDMI input port.
Page 9: Top Panel
LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer 15. OUTPUT FORMAT: Press to switch between DVI (LED=Blue) and HDMI (LED=Red) output formats. Press and hold the button for 2 seconds to disable/enable video output completely. The button’s LED will turn off when output is disabled. 2.2 Top Panel AUDIO OUT VGA OUT...
Page 10: Left Panel
LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer 2.4 Left Panel POWER 1. POWER: Flip this switch to turn the unit ON or OFF after connecting an appropriate power source. 2.5 Right Panel CONTROL SERVICE DC 5V RS-232 1.
Page 11: Remote Control
LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer 2.6 Remote Control 1. Analyzer/Pattern: Press to switch between Analyzer Mode and Pattern Mode. 2. EDID: Press repeatedly to switch between the available EDIDs for the HDMI input. 3. Color Space: Press repeatedly to space formats (RGB, YCbCr 4:4:4, YCbCr 4:2:2 and YCbCr 4:2:0).
Page 12 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer 10. Menu: Press to enter the OSD menu. 11. Exit: Press to exit the OSD or cancel the selection. 12. Source*: Press to display source signal information on the OSD. Video T*.: Press to display video analysis details on the OSD.
Page 13: Rs-232 Protocol
LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer 2.7 RS-232 Protocol Baud Rate: 115200bps Data Bits: 8 Parity: None Flow Control: None Stop Bit: 1 Broadata Technical Support, (800) 214-0222...
Page 14: Rs-232 And Telnet Commands
LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer 2.8 RS-232 and Telnet Commands Broadata Technical Support, Sales@Broadatacom.com...
Page 15 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer Broadata Technical Support, (800) 214-0222...
Page 16 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer Broadata Technical Support, Sales@Broadatacom.com...
Page 17 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer Note: • All commands MUST start with the “$” character or the command will not be recognized by the unit. • Commands are not case-sensitive. • Commands must end with a carriage return (0x0D). Use of a line feed(0x0A) is optional.
Page 18: Telnet Control
LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer 2.9 Telnet Control Before attempting to use telnet control, please ensure that both the unit and the PC/Laptop are connected to the same active networks. To access Telnet in Windows 7, click on the “Start” menu and type “cmd”...
Page 19 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer This will connect us to the unit we wish to control. Type “$help” or “$?” to list the available commands. Note: Commands will not be executed unless followed by a carriage return.
Page 20: Osd Menu
LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer 2.10 OSD Menu 2.10.1 Analyzer Mode Broadata Technical Support, Sales@Broadatacom.com...
Page 21 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer Broadata Technical Support, (800) 214-0222...
Page 22 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer Broadata Technical Support, Sales@Broadatacom.com...
Page 23 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer Broadata Technical Support, (800) 214-0222...
Page 24 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer Note: • SCDC= Status and Control Data Channel • CED= Character Error Detection • PoR= Power on Reset (setting is reset when the unit is powered off) • Image file format: 640×480/1920×1080 (RGB, 24-bit, bitmap) Broadata Technical Support, Sales@Broadatacom.com...
Page 25 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer Source HDR Ability: - Parse the HDR Static Metadata data block in the sink’s EDID. - Output 4K60 (4:2:0, 10/12-bit), or 4K30 (4:4:4, 10/12-bit). - Output DRMI (Dynamic Range & Mastering InfoFrame). Sink HDR Ability: - Build an RX EDID that includes the HDR Static Metadata data block.
Page 26 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer IR Settings: - The IR remote uses one out of 4 available address channels for control of the test pattern generator, allowing up to 4 to be located in the same area while being controlled by different remotes.
Page 27: Pattern Mode
LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer 2.10.2 Pattern Mode Broadata Technical Support, (800) 214-0222...
Page 28 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer Broadata Technical Support, Sales@Broadatacom.com...
Page 29 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer Broadata Technical Support, (800) 214-0222...
Page 30 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer Note: • SCDC= Status and Control Data Channel • CED= Character Error Detection • PoR= Power on Reset (setting is reset when the unit is powered off) Broadata Technical Support, Sales@Broadatacom.com...
Page 31: Test Timings
LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer 2.11 Test Timings 2.11.1 Input Timings Broadata Technical Support, (800) 214-0222...
Page 32: Output Timings
LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer 2.11.2 Output Timings Broadata Technical Support, Sales@Broadatacom.com...
Page 33 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer Note: • RB=Reduced Blanking • 87 total resolutions. • VGA output limitations: - Only supports RGBHV. (No YUV, RGBS or RGsB support) - In Analyzer mode: VGA output is turned off. - In Pattern mode: VGA output has limited resolution support.
Page 34: Test Patterns
LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer 2.12 Test Patterns The Border pattern presents 4 equal-sized squares dividing the screen into 4 quadrants, forming a central white cross, with red, green, blue and white inner squares. Ideal for testing screen boundary, alignment and pincushion issues.
Page 35 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer The Circle 4 pattern provides 4 smaller white circles in each of the 4 corners of the screen. This pattern can help confirm that the display is maintaining correct geometry at the edges of the screen.
Page 36 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer The Colorbar Delay pattern provides a sequence of standard 100% color bars with a full set of smaller color squares within each bar. This test is primarily to detect if any of the color components of the video signal are delayed/skewed relative to each other.
Page 37 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer The Colorbar S. pattern is a standard SMPTE color bar pattern which is used for rapid verification of signal color accuracy and for display setup using the Blue-Only option on your display, if it has one.
Page 38 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer The Cross Hatch 8 pattern is a full field black & white pattern of crossing vertical and horizontal lines dividing the screen into 8 sections in each direction. This pattern is primarily used to check for color convergence and pincushion issues in projectors.
Page 39 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer The Diagonal 1 pattern is a set of 3 diagonal colored lines (red, white and blue) within a white square in the middle of the screen. This pattern is used to check for distortion and alignment issues in the center of the screen.
Page 40 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer The General pattern is an all-purpose, multi-pattern test to visually check for multiple issues simultaneously. It includes color bars, 8-step greyscale, vertical and horizontal multi-burst, cross hatch, circle and motion patterns. There are 3 variations: No motion, slow motion and fast motion.
Page 41 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer The Grayscale 32 pattern provides a way to check and adjust the contrast, brightness and grayscale tracking of your display with 32 bars progressing from 0% to 100% brightness in even steps.
Page 42 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer The Grayscale 256 pattern provides a way to fine tune the con- trast, brightness and grayscale tracking of your display with a full 265 step gradient progressing from 0% to 100% brightness. When testing a display, no color should be visible at any point across the gradient, and the transition from black to white should appear even and consistent.
Page 43 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer The Grayscale H pattern provides 4 distinct gray fields in an “H” arrangement for testing luminance transition stability. No color or interference should be visible at the transitions between sections The Grid pattern provides a selection of red, green, blue and white boxes with 2×2 grids within and above them to test for...
Page 44 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer The Letter H pattern is a screen filled with a series of large capital “H” characters moving vertically up the screen. This is a basic test to confirm motion detail. There are 2 variations: Large “H”...
Page 45 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer Note: The red and green variation is not available if the selected output resolution is 4K. The following timings use dual-pixel lines: 3840×2160@50/60Hz & 4096×2160@25/30/50/60Hz. The Motion-H patterns are a collection of horizontal motion tests. These can be used to test your display’s pixel on/off response time.
Page 46 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer The Multiburst pattern provides a standard multiburst pattern consisting of vertical white lines that decrease in thickness from left to right allowing the user to analyze the bandwidth and frequency response of the video path and connected display.
Page 47 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer The Pluge pattern is used to perform the accurate and consistent brightness and contrast configuration of a display. Typically you will want to adjust the brightness control of the monitor so that the first bar is just barely indistinguishable from the background black while the second bar is still clearly visible.
Page 48 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer The Square H32 pattern is a full field black & white pattern of squares dividing the screen horizontally into 32 sections. This pattern is primarily used to check projector linearity. There are 2 variations: Normal (white lines, black field) and Inverse (black lines, white field).
Page 49 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer Broadata Technical Support, (800) 214-0222...
Page 50 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer These Window patterns are additional screen purity tests offering seven different patterns with different sized windows of each color on a black field: Blue, Cyan, Green, Magenta, Red, White, Yellow.
Page 51: Specifications
LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer 3.0 SPECIFICATIONS Signal Generator/Analyzer Input One (1) HDMI Input port One L/R analog audio (3.5mm jack) Output One (1) HDMI Output port One (1) VGA Output port, HD-15 One L/R analog audio (3.5mm jack) VGA Output Resolutions support 350p, 480p, 576p, 720p, 1080i, 1080p, 640×480,...
Page 52: Service Procedure
U.S. Please call Customer Service at 800-214-0222 for information. 4.2 Return/Repair Service The Link Bridge LB-H2-SGA System contains no user serviceable components. If you have a problem with your unit, please contact the Customer Service Department. To facilitate our return/repair processing please contact Broadata Communications, Inc.
Page 53: Limited Warranty
HDMI 2.0 Signal Generator and Analyzer 5.0 LIMITED WARRANTY Broadata Communications, Inc. (BCI) warrants, for a period of one year from date of shipment, each product sold shall be free from defects in material and workmanship. BCI will correct, either by repair, or at BCI’s...
Page 54 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer Broadata Technical Support, Sales@Broadatacom.com...
Page 55 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer Broadata Technical Support, (800) 214-0222...
Page 56 LB-H2-SGA User Manual Link Bridge HDMI 2.0 Signal Generator and Analyzer Broadata Technical Support, Sales@Broadatacom.com...
Page 57 Broadata Communications, Inc. 2545 West 237th Street, Suite K Torrance, CA 90505 1-800-214-0222 (310) 530-1416 (310) 530-5958 (Facsimile) e-mail: CustomerService@Broadatacom.com Website: www.broadatacom.com 60000-LBH2SGA...
