- Page 1 Micronet Union User Manual AC1200 Dual Band XPON Terminal Model: X122 Package Content: 1. X122 *1 2. Power Adapter *1 3. Quick Installation Guide *1...
- Page 2 Products in kind prevail. For details, please check with the dealer. PROMPT Pictures used in this manual are for reference only. The information provided in this manual may be amended without notice, and Micronet Union reserves the right of final explanation of the said information.
-
Page 3: Table Of Contents
Micronet Union CONTENTS Warnings and Precautions ....................4 Introduction ........................... 5 Product Features ........................5 Technical Parameters ......................6 Interface and Button ......................7 Installation ..........................8 Configuration .........................8 LED Description ........................9 Button Description .......................10 Manufacture Information ..................... 11... -
Page 4: Warnings And Precautions
Micronet Union Warnings and Precautions 1. Before using and operating the equipment, please read and follow the following precautions to ensure that The standby performance is stable and dangerous or illegal situations are avoided. 2. To reduce the risk of fire or electric shock, do not expose this device to rain or moisture. -
Page 5: Introduction
They can take this product for environmental safe recycling. Introduction X122 is a gateway ONT that uses GPON/EPON technology to achieve ultra-broadband access for users. It supports 802.11ac dual-band WiFi, provides four GE Ethernet ports, one POTS voice port, and one USB port, and provides high-performance forwarding function to ensure high-quality voice, Internet, and high-definition video services. -
Page 6: Technical Parameters
Micronet Union Technical Parameters Module Parameters Product Size: 186mm(L)×115mm(W)×39mm(H) Weight: 340g 4*10/100/1000M RJ45 port 1*POTS Interfaces: 1*USB 2.4G Wi-Fi 5G Wi-Fi EPON&GPON mode adaptive Interface Type: SC-UPC/SC-APC Security: ONU authentication mechanism Network Coverage Radius: 20KM GPON: upstream 1.25Gbps/downstream 2.5Gbps PON: Optical Receive Sensitivity: -7dBm~-28dBm Continuous Light Power: 0.5dBm~5dBm... -
Page 7: Interface And Button
Micronet Union Operating Operating Temperature:0℃~55℃ Temperature Operating Humidity: 5%~95%(non-condensing) &Humidity: Storage Storage Temperature: -10℃~70℃ Temperature Storage Humidity: 5%~95%(non-condensing) &Humidity: Buttons: Power ON/OFF,WPS,WLAN,RESET Power,LOS,PON,LAN1~LAN4,NET,2.4G,5G,USB, Indicators: VOIP Interface and Button... -
Page 8: Installation
Micronet Union Installation 1. Take out the power adapter, plug the power connector into the device, and press the ON/OFF button to power on the device. 2. Connect the optical Fiber cable to the PON port. 3. Connect one end of the Ethernet cable to the LAN port, and the other end to your personal computer. -
Page 9: Led Description
Micronet Union WPS method failure, utilize the SSID and wireless password to establish a WiFi connection. 3. Open a web browser and navigate to http://192.168.1.1. Enter the default User Name and Login Password, then click Login.After successfully logging in, you can configure the settings on the web page. -
Page 10: Button Description
Micronet Union 5GHz Wi-Fi is turned on. Blinking 5GHz Wi-Fi data are being transmitted. 5GHz Wi-Fi is turned off. External device is connected. Blinking Data are being transmitted. No external device is connected. The VOIP server has been registered. VOIP Blinking The voice service is in use. -
Page 11: Manufacture Information
Address: Room 502, Building 5, No. 528, Yuefei Road, Shibantan Street, Xindu District, Chengdu, Sichuan Micronet Union Technology (Chengdu) Co., Ltd.declares that the AC1200 Dual Band XPON Terminal is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: https://www.micronet-union.com... - Page 12 Micronet Union FCC Warning This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
