Summary of Contents for Titan Attachments 650POLYCART
- Page 1 650 LB ECONOMY POLY DUMP CART 191253 - 650POLYCART Operator’s Manual Read the Operator’s Manual entirely. When you see this symbol, the subsequent instructions and warnings are serious follow without exception. Your life and the lives of others depend on it!
-
Page 2: Safety Rules
SAFETY RULES Remember, any power equipment can cause injury if operated improperly or if the user does not understand how to operate the equipment. Exercise caution always when using power equipment. 1. Read this owner’s manual before attempting to assemble or operate the cart. 2. - Page 3 PARTS DIAGRAM / EXPLODED VIEW DESCRIPTION CLIP LOGO...
- Page 5 PART NAME POLY TRAY WHEEL AXEL SUPPORT LATCH STAND BRACKET HANDLE WHEEL AXLE FRONT LEG CLAMP PLATE FRONT TONGUE ASSEMBLY REAR TONGUE ASSEMBLY LATCH STAND PLATE WHEEL...
- Page 7 ASSEMBLY INSTRUCTIONS Step 1: Attach the Rear Tongue Lay the Rear Tongue (21) (open side facing up) onto the Wheel Support (17). Asemble the Axel (15) throught he Wheel Axle Support and the Tongue. Step 2: Attach the Hitch Bracket and Leg Stand Bracket Assemble the Front Leg (31) to the Front Tongue (34) using Hex Bolt M8*20 (32), Nylon Lock Nut M8 (16).
- Page 8 Step 3: Attach the Front Tongue 1. Place the Front Tongue inside the Rear Tongue. Fasten the tongues together using Hex Bolt M10*95 (25) and a Nylon Lock Nut (29). Tighten, leaving the nut just loose enough that the tongues can pivot freely. 2.
- Page 9 Step 5：Attach the Latch Stand Bracket Turn the Wheel Axle Support over to rest on the wheels. Place the Latch Stand Bracket (#14) onto the tongue, sliding it underneath the Foot Pedal (#22). Turn the Latch Stand Plate (#13). The tabs at the ends of the channels must face the rear.
- Page 10 Step 7：Attach the Latch Stand Plate 1. Insert Screw M6x16 (#3) down through the tray and the inside holes in the Latch Stand Plate. Secure the bolts with Big Flat Washer Ø6 (#11) and Nylon Lock Nut M6 (#12). Do not tighten yet.
- Page 11 Step 9：Attach the Front Tongue Assembly Assemble the Front Tongue Assembly to the Rear Tongue Assembly using Hex Bolt M10x20 (#28) and Lock Nut M10(#29), then Insert Clevis Pin Ø10x95 (#26), secure with R Pin Ø3 (#30). Lock the Hex Bolt M10x20 (#28) to the Front Tongue Assembly using the Lock Nut M10(#29).
- Page 12 OPERATIONS CAUTION: TO AVOID POSSIBLE INJURY, BEFORE RELEASING THE LATCH BE SURE THAT NO ONE IS NEAR THE CART. TOW CART 1. To convert the cart for towing, remove the plastic cap from the tongue. Remove the 10x95 clevis pin and R Pin which secure the front tongue in storage position underneath the rear tongue.
-
Page 13: Maintenance
PUSHCART Important: Always Leave the latch lock clevis pin in place while using the cart as a pushcart. 1. To convert cart for push operation, remove the Ø10x95 long clevis pin and R Pin Ø3 which secure the tongue in the towing position. (See step 9 on page 9.) Pivot the front tongue into the storage position underneath the rear tongue and secure it using the Ø10x95 long clevis pin and R Pin Ø3. - Page 14 ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY The use of any equipment, including this one, involves the potential risk of injury. Apart from any warranty claim that might be presented for a claimed defect in material or workmanship of the product, you accept and assume full responsibility for any and all injuries, damages (both economic and non- economic), and losses of any type, which may occur, and you fully and forever release and discharge Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims,...
- Page 15 NEED HELP? CONTACT US FIRST. 1-800-605-7595 info@palletworks.com www.palletforks.com © 2024 Titan Brands...
