grandin road
GR Product Name: NOVA KING BED / NOVA QUEEN BED
GR Product Number: 180601A HAR KIN / 180601B HAR KIN / 180601A HAR QUE / 180601B HAR QUE
Assembled Dimensions: 56.5"H x 86"W x 80.75"D / 56.5"H x 86"W x 65"D
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 14/03/2024
Prevent accidentally discarding small parts or
hardware. Retain all carton contents until assembly
and installation are complete.
Product Specialist: 800-491-4958
Online: www.grandinroad.com
MADE IN VIETNAM
Page 1 of 7
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Grandinroad NOVA 180601A HAR KIN
Summary of Contents for Grandinroad NOVA 180601A HAR KIN
- Page 1 Product Specialist: 800-491-4958 GR Product Name: NOVA KING BED / NOVA QUEEN BED Online: www.grandinroad.com GR Product Number: 180601A HAR KIN / 180601B HAR KIN / 180601A HAR QUE / 180601B HAR QUE Assembled Dimensions: 56.5”H x 86”W x 80.75”D / 56.5”H x 86”W x 65”D Prevent accidentally discarding small parts or hardware.
-
Page 2: Required Tools
M5x68mm level, padded surface. Flat Head Screw M5x30mm ASSEMBLY TIME: Twenty minutes for assembly not including unpackaging. Ltr. Qty. Components Headboard Side Rail FootBoard Slat Support Slat Support Leg Product Specialist: 800-491-4958 Online: www.grandinroad.com Page 2 of 7... - Page 3 STEP 1: Attach the bolts (A) into headboard leg (F) Do not fully tighten the bolts STEP 2: Attach the bolts (A) into footboard (H) Do not fully tighten the bolts Product Specialist: 800-491-4958 Online: www.grandinroad.com Page 3 of 7...
- Page 4 STEP 3: Connect side rail bracket (G) into headboard bolt (A) Fully tighten STEP 4: Connect side rail (G) with the footboard (H) Fully tighten Product Specialist: 800-491-4958 Online: www.grandinroad.com Page 4 of 7...
- Page 5 STEP 5: Affix slat roll (I) on side rail supported by screws STEP 6: Attach support leg (L) on the midle support slat (K) Product Specialist: 800-491-4958 Online: www.grandinroad.com Page 5 of 7...
- Page 6 STEP 7: Affix slat roll (I) in middle support slat by screws (I) Product Specialist: 800-491-4958 Online: www.grandinroad.com Page 6 of 7...
- Page 7 CLEAN WITH SOFT CLOTH ONLY. Please contact one of our Product Specialists for assembly assistance or questions at 1-800-491-4958 or email ps@grandinroad.com. Specialists are available weekdays 8:00am to 8:00pm EST or Saturday 9:30am to 6:00pm. Page 7 of 7...
