PULL-DOWN KITCHEN FAUCET
Model 67070-0101
GRIFO EXTENSIBLE PARA COCINA
Modelos 67070-0101
ROBINET DE CUISINE À DOUCHETTE RÉTRACTABLE
Modèles 67070-0101
English
HELP LINE
If you need installation assistance,
replacement parts, or have questions
regarding our warranty, please call our
Product Consultants at:
1-877-580-5682
CAUTION-TIPS FOR REMOVAL OF OLD
FAUCET:
Always turn off water supply before
removing existing faucet or replacing
any part of the faucet. Open the faucet
handle to relieve water pressure and
ensure that water is completely shut off.
CARE INSTRUCTIONS:
To preserve the finish of your faucet,
apply non-abrasive wax. Any cleaners
should be rinsed off immediately. Do not
use abrasive cleaners on the faucet.
Goggles
Anteojos Protectores
Lunettes de sécurité
Español
LÍNEA DE AYUDA
Si necesita ayuda para la instalación,
piezas de repuesto o tiene alguna
pregunta relacionada con nuestra
garatía, por favor llame a nuestros
asesores de producto al:
1-877-580-5682
CONSEJOS PREVENTIVOS PARA
QUITAR EL GRIFO VIEJO:
Siempre corte el suministro de agua antes
de retirar el grifo actual o remplazar
cualquier pieza del mismo. Abra la llave
del grifo para liberar la presión de agua y
asegurar que ya no corre agua.
INSTRUCCIONES DE CUIDADO:
Para preservar el acabado de su grifo,
aplique cera no abrasiva. Se debe enjuagar
completamente todo producto de
limpieza. No use limpiadores abrasivos en
el grifo.
You may need/
Aticles dont vous pouvez avoir besion
Wrench
(2) Supply Lines
Llave
2 Líneas de Suministro
Clé ajustable
(2) Tuyaux d'alimentation
Usted puede necesitar/
Basin Wrench
Llave para Instalar Grifos
Clé pour lavabo
1 1
Français
SERVICE À LA CLIENTÈLE
Pour obtenir de l'aide pour l'installation,
le replacement de pièces ou pour toute
question concemant notre garantie,
appeler un de nos spécialistes
des produits:
1-877-580-5682
MISE EN GARDE – CONSEILS POUR
LE RETRAIT DE L'ANCIEN ROBINET:
Fermez toujours l'alimentation en eau avant
de retirer un robinet ou d'en remplacer
des pièces. Tournez la poignée du robinet
pour libérer la pression et vous assurer
que l'alimentation en eau est coupée.
DIRECTIVES D'ENTRETINE:
Pour préserver le fini de votre robinet,
appliquez-y de la cire non abrasive.
Rincez immédiatement tout produit net-
toyant utilisé. N'utilisez pas de nettoy-
ants abrasifs.
Sealant
Tape
Masilla para Tuberías
Cinta Selladora
Mastic de plombier
Ruban d'étanchéité
Plumber's
Putty

Advertisement

loading
Need help?

Need help?

Do you have a question about the 67070-0101 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Glacier bay 67070-0101

  • Page 1 PULL-DOWN KITCHEN FAUCET Model 67070-0101 GRIFO EXTENSIBLE PARA COCINA Modelos 67070-0101 ROBINET DE CUISINE À DOUCHETTE RÉTRACTABLE Modèles 67070-0101 English Español Français HELP LINE LÍNEA DE AYUDA SERVICE À LA CLIENTÈLE If you need installation assistance, Si necesita ayuda para la instalación,...
  • Page 2 This faucet can be installed as 4 hole installation with the escutcheon or as 2 hole Optional Flange Installation installation with flange. If using flange, begin with step 2a. If using escutcheon, Shut off water supplies. Remove old faucet. Place flange on the sink. Proceed to begin with step 2b.
  • Page 3 Optional Escutcheon Installation Install rubber washer (4A), metal washer (4B) onto the threaded mounting shank. Thread nut (4C) onto mounting shank. Do not overtighten. Retract pull-out hose (3A) up through faucet body, until the pull-out hose fitting is flush with the bottom of shank (3B). Do not pull hose fitting past the shank. Insert faucet body through the hole in escutcheon.
  • Page 4 To install Soap Dispenser: Insert body assembly (7A) through selected hole in Make connections to water lines. Use 1/2" I.P.S. faucet connections (8A) or use sink. Secure body assembly to sink with nut (7B). From under the sink screw the supplied coupling nuts (8C) with 3/8"...
  • Page 5 * Specify Finish Especifíque el Acabado Précisez le Fini RP70090 Inverter RP60075 O-Ring RP60075 Junta en Forma de Aro Tórico RP70090 Inversor RP60075 Joint torique RP70090 Inverseur RP60076 Ring RP60076 Anillos RP60076 Rondelle d’usure RP60075 O-Ring RP60075 Junta en Forma de Aro Tórico RP60075 Joint torique RP20031 Cartridge RP20031 Cartucho...
  • Page 6 à État, de province à province et de nation à nation. La société Glacier Bay Faucets & Sanitaryware vous informera des étapes à suivre pour faire une demande au titre de la garantie. Il vous suffit d’écrire à la société Glacier Bay Faucets &...
