- Page 1 McGrey P212 / McGrey P215 active/passive speaker 00079143 / 00079144 / 00079147 / 00079145 MIDI Operating instructions Version 08/2021...
-
Page 2: Table Of Contents
© 2020 These operating instructions are protected by copyright. Reproduction of these operating instructions, even in part, is only permitted with the permission of Musikhaus Kirstein GmbH. The same applies to the reproduction or copying of images, even in modified form. Content Safety precautions and precautionary measures Important information... - Page 3 Thank you for choosing this product. To ensure that you are completely satisfied with this product, please read these operating instructions carefully before using our product. Keep these operating instructions in a safe place. The operating instructions must be passed on to all subsequent users.
-
Page 4: Safety Precautions And Precautionary Measures
Safety precautions and precautionary measures Always place the appliance securely on a level surface to avoid injury from the appliance falling over. Do not place any devices that can heat up (e.g. lighting equipment or fog machines) on the unit. Never touch the mains cable or the unit when it is wet, as this may cause an electronic shock. -
Page 5: Important Information
Important information Power supply Do not plug the appliance into the same sockets as other electrical appliances controlled by an inverter (e.g. a freezer, washing machine, microwave oven or air conditioner) or containing a motor. Depending on how the electrical appliance is used, disturbances in the power supply may cause malfunctions or produce audible noises. - Page 6 Maintenance For daily cleaning, wipe the unit with a soft, dry cloth or a cloth slightly moistened with water. To remove stubborn dirt, use a cloth soaked in a mild, non-abrasive detergent. Then wipe the unit thoroughly with a soft, dry cloth. Further information Please be careful when using the keys or other operating elements of the unit as well as the sockets and connections.
-
Page 7: Operation
Operation Operation of the USB / SD - Player 1. Display 2. SD card slot 3. USB interface 4. Mode selector switch - On/Off 5. Play/Pause/Stop button 6. Play mode button 7. Last title 8. Next title 9. TWS True wireless stereo 10. -
Page 8: Operating Elements
Operating elements... - Page 9 Operating elements - 1 | Media player For playing music via SD card, Bluetooth or USB - 2 & 5 | Microphone volume control Controls the input level for the XLR and jack sockets 3, 4, 6 and 7 - 3, 4, 6 & 7 | XLR and jack connectors (6.3mm) For connecting microphone or line devices (mixer, guitar, keyboard, etc.) - 8 | MP3/Line volume control Controls the input level for the LINE IN sockets and the MP3 signal...
-
Page 10: Technical Specifications (Active Speakers)
Technical specifications (active speakers) P212 MA P215 MA Amplifier Max. output power (PEAK) 600 W 800 W Max. output power (RMS) 120 W Type Class - AB Loudspeaker system data Woofer 12" (312 mm) LF driver 15" (386 mm) LF driver Tweeter 1"... -
Page 11: Technical Specifications (Passive Boxes)
Technical specifications (passive boxes) P212 MP P215 MP Max. output power (PEAK) 600 W 800 W Max. output power (RMS) 180W 8 Ω Resistance Type 2-way Frequency range 75 Hz to 35 kHz (±3 dB) Frequency response 55 Hz-18 KHz (-10dB) 50 Hz-18 KHz (-10dB) -
Page 12: Tws (True Wireless Stereo) Function
5. Press the PAIR button again if you want to separate the two units. Bluetooth connection 1. The first time you connect a device to the McGrey Columns system, press the MODE button on the MP3 player to activate Bluetooth mode. -
Page 13: Weee Declaration
SIMPLIFIED EU DECLARATION OF CONFORMITY Herewith Musikhaus Kirstein GmbH declares that the radio unit of Model [McGrey P212 MA, 12" Aktivbox and McGrey P215 MA, 15" Aktivbox] is in compliance with the EU directive 2014/53/EU. You can download the full EU declaration of conformity for this item under download link: http://www.kirstein.de/docs/Konformitaetserklaerung/CE_Konformitaetserklaerung_0... - Page 14 Musikhaus Kirstein GmbH Bernbeurener Straße 11 86956 Schongau - Germany Phone: 0049-8861/909494-0 Fax: 0049-8861/909494-19...
