- Page 1 VT-TPC101-RK99 User Manual VT-TPC101-RK99 Hardware User Manual Product Version: 1.0 Date: 2024-02-07 For any question, please contact Vantron Technology, Ltd. Copyright © Vantron Technology, Ltd. All rights reserved.
-
Page 2: Change History
Change History This table describes the version and release date. Rev. Date Description Author 2024-02-07 First release. Lili Zhang... -
Page 3: Symbol Conventions
Please contact our technical department for relevant operation solutions if there is any problem that cannot be solved according to this manual. Vantron reserves all rights of this manual, including the right to change the content, form, product features, and specifications contained herein at any time without prior written notice. -
Page 4: Limitation Of Liability/Non-Warranty
Limitation of Liability/Non-warranty For direct or indirect damage to this device or other devices of Vantron caused by failure of conforming to this manual or the safety instructions on device label, Vantron assumes neither warranty nor legal liability even if the device is still under warranty. -
Page 5: Safety Instructions For Power Cables And Accessories
Use Proper power source only. Start only with power source that satisfies voltage label and the voltage necessary according to this manual. Please contact technical support personnel of Vantron for any uncertainty about the requirements of necessary power source. Use tested power source. This product still contains a button lithium battery as a real-time clock after its external power source is removed and therefore should not be short-circuited during transportation or placed under high temperature. -
Page 6: Table Of Contents
Contents 1 INTRODUCTION ..............................1 1.1 P .................................1 RODUCT ESCRIPTION 1.2 C ..............................1 ONNECTOR ESCRIPTION 2 OVERVIEW .................................3 2.1 I ..................................3 NTRODUCTION 2.2 F ....................................3 EATURE 2.3 O ................................5 RDER NFORMATION 3 PRODUCT DESCRIPTION ............................6 3.1 P .................................6 RODUCT PPEARANCE 3.2 D... - Page 7 5.2 P ..................................19 OWER NPUT 5.3 W ....................................19 IRELESS 6 SOFTWARE DESCRIPTION ..........................21 7 TIPS ...................................22 APPENDIX A: HOW TO CONTACT US ......................... 25...
-
Page 8: Introduction
So it is easy to be used by adding your application software only. It can speed Time to Market of your products, and save more cost. Connector Description This table respectively describes the valid signal of connectors on the Vantron board. Not connect... - Page 9 3.3V 3.3 V signal level 5 V signal level 5 V tolerant signal PCIe PCI Express signal, not 3.3 V tolerant No Connection...
-
Page 10: Overview
2 Overview Introduction Thank you for choosing Vantron. It is our commitment to provide our valued customers with the embedded devices equipped with the state-of-the-art technology and the best product services. Tablet enables the interaction between operators/users and applications, connects industrial control products such as wireless, transducer, battery inside, storage, etc. - Page 11 NA default Atmel™ TPM optional Display 10.1’ 1920*1200 6bit+FRC 16.7M colors 300nit LCD Touch 10.1’ high resolution capacity touch screen HDMI 1x HDMI 2.0 type-A output Media Interface Camera 1x 5MP front camera 1x front analog MIC input 1x 3.5mm headphone jack(4-POLE with MIC, without Audio key.
-
Page 12: Order Information
Order Information Part Order Example ARM tablet,V4,RK3399,4GB LPDDR4/32GB EMMC5.1/10.1 inch 1920*1200 touch screen. WIFI/BT/NFC/POE/HDMI.White. VT-TPC101-RK99 ARM tablet,V4,RK3399,2GB LPDDR4/16GB EMMC5.1/10.1 inch 1920*1200 touch screen. WIFI/BT/NFC/POE/HDMI.Black. Note: Please contact Vantron for more details. Vantron provides customization. -
Page 13: Product Description
3 Product Description Product Appearance... -
Page 15: Device Interface
HDMI 2.0 type-A output. USB 2.0 type-A. Host only. USB3.0 type-C. OTG. EtherNet 10/100/1000base RJ45. Support 802.11-AT PoE power input. Recovery Key. 12V~2.5A DC input. 2mm/6mm jack. Structure Download the structure document from Vantron technology or Vantron net site: www.vantrontech.com.cn... -
Page 16: Hardware Description
& touch, speaker, WIFI & BT, LTE, Ethernet, USB, light & TOF Sensor, button and POS. Power Input VT-TPC101-RK99 tablet support DC jack power input as well as 802.11-AT PoE power delivery. When both power input are provided, DC jack power input will work while PoE will not work. -
Page 17: Display & Touch
The power input PoE connector is shown as “⑤” Fig 4-1-1 Power input connector Display & Touch VT-TPC101-RK99 tablet support a 10.1” LCD touch screen. This screen consists of two parts including a LCM panel and a touch panel. The touch panel is frame fit structurally. -
Page 18: Camera
VT-TPC101-RK99 tablet provides a standard HDMI 2.0 output. The connector is HDMI type-A. This port can drive up to 4K@60Hz in 8-bit video output. NOTE: The main image output is MIPI TX which is linked to the internal LCM. When this HDMI output is linked to an external display the image of these two display will be the same. -
Page 19: Speaker & Mic
Fig 4-4-1 Location of the front camera Speaker & MIC VT-TPC101-RK99 tablet integrates a dual channel audio speaker on the standard model. Two extra bass can be customized for better audio performance. The technical parameter of the standard speakers is shown as Tab 4-5-1. - Page 20 ＜10% (at 1K Hz, input 1.0W, IN 1CC BOX) VT-TPC101-RK99 tablet integrates an analog MIC on the front cover. The technical parameter of the analog MIC is shown as Tab 4-5-2. Tab 4-5-2 technical parameter of the analog MIC Item...
-
Page 21: Mm Audio Jack
Fig 4-5-1 Location of the speakers and MIC 3.5mm Audio Jack VT-TPC101-RK99 tablet integrates one 3.5mm Audio jack. This 3.5mm jack is an output only jack and can drive high impedance headphones up to 120 Ω. The MIC on 3.5mm headphone is supported, while keys on 3.5mm headphone are not supported. -
Page 22: Usb 2.0 Type-A Host
The USB 3.0 type-C port is shown as “④” Fig 4-7-1 USB type-C port USB 2.0 type-A Host VT-TPC101-RK99 tablet integrates one standard USB 2.0 type-A port which can only be used as HOST. This port can delivery current up to 0.5A(5V~0.5A) with DCP. -
Page 23: Wifi & Bluetooth
The RJ45 port is shown as “⑤” Fig 4-9-1 RJ45 port 4.10 WIFI & Bluetooth VT-TPC101-RK99 tablet integrates one on-board WIFI & BT module and matched FPC antenna as default. The technical parameter of the WIFI is shown as Tab 4-10-1. -
Page 24: Nfc
NOT embedded this tablet in the wall or wireless performance will degrade seriously. 4.11 NFC VT-TPC101-RK99 tablet integrates one on-board NFC module and matched FPC antenna as default. This NFC can used be HOST only instead of label. The technical parameter of the NFC is shown as Tab 4-11-1. -
Page 25: A/Gsensor
Fig 4-11-1 Location of NFC antenna 4.12 A/G sensor VT-TPC101-RK99 tablet integrates one A/G sensor so this tablet supports auto rotation. To be mentioned, the default display direction is vertical with the camera on the top of the tablet. You can change the direction or disable auto rotation in android system. -
Page 26: Hardware Operation Note
5 Hardware Operation Note This chapter provides a guide to set up the tablet. For more details, see hardware description. Environment Before the tablet is powered on, please confirm whether the environmental conditions meet the requirements. Environmental requires are as follows: ●... - Page 27 Fig 5-3-1 Location of antenna...
-
Page 28: Software Description
6 Software Description The software loading system is pre-installed in VT-TPC101-RK99. Please refer to the software manual for more software information. -
Page 29: Tips
In the aim of avoiding accidents as far as possible, it is not allowed to replace the system or change components unless with permission and certification. Please contact the technical department of Vantron or local branches for help. Pay attention to caution signs. - Page 30 Vantron assumes no responsibility of possible missing contents and information, errors in contents, citations, examples, and source programs. Vantron reserves the right to make necessary changes to this manual without prior notice. No part of this manual may be reprinted or publicly released in forms of photocopy, tape, broadcast, e-document, etc.
- Page 31 —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help.
-
Page 32: Appendix A: How To Contact Us
Appendix A: How to Contact Us If you have any problem or want to know more about our products, visit www.vantrontech.com or contact us. US Office: Vantron Technology, Inc. Address: 440 Boulder Court, Suite 300, Pleasanton, CA 94566, USA Tel: 925-621-8758 Email: sales@vantrontech.com...
