Wave Spirit W1 Manual

Hide thumbs

Advertisement

Table of Contents

Spirit W1 is stabilisation system for R/C aircrafts such as helicopters and planes featuring control unit and receiver
in one extraordinary packageǃ
It combines the best available technologies from both worlds to offer cutting edge experience.
In other words, Spirit W1 consists from Spirit GT hardware and Spirit Wave receiver.
Control part
Top-notch 20-bit IMU Sensor
Performance-line ARM F7 processor
Precise pressure sensor for Altitude measurement
Dedicated Memory Chip for detailed logging
Receiver part
Spirit Wave 2.4Ghz full-range telemetry receiver
Full featured 30+ channels available
Blazing fast 300 Hz transmission
High interference immunity
BEC Voltage measurement
Spirit W1 can be easily bound with all Spirit Wave radios. It can be used also with all third party external
receivers known to work with Spirit units.
This will allow easy transition from previous systems, while Wave radio can be linked anytime later.
Following pages are covering setup of your Spirit Wave radio and W1 unit to prepare everything for the first
flight.
When W1 unit is used with a non-Wave radio you can proceed according standard Spirit manual
(https://manual.spirit-system.com/index.php?title=Manual).

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spirit W1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Wave Spirit W1

  • Page 1 High interference immunity BEC Voltage measurement Spirit W1 can be easily bound with all Spirit Wave radios. It can be used also with all third party external receivers known to work with Spirit units. This will allow easy transition from previous systems, while Wave radio can be linked anytime later.
  • Page 3 CONTENTS Preparation Safety notes Radio Preparation Mounting Mounting at the model Wiring Servo wiring and Power Supply Telemetry sensors ESC Telemetry Spirit Governor Binding Binding with Radio Setup Configuring Spirit from Radio Configuring Spirit from Computer Certification FCC Declaration of Conformity...
  • Page 4 Find the source of the vibrations and fix the problem. Spirit W1 unit is not an autopilot, it is necessary to have knowledge of flying R/C models. The system is only designed to improve flight experience. We recommend using R/C simulators designed for training before the first flight.
  • Page 5 Preparation To use Spirit W1 with Spirit Wave radio it is enough to create fresh Model in the Model list. Spirit W1 unit can be used for Helicopters and Airplanes. Depending on this create according model. Model Creation 1. Go to Main Screen by tapping at the Home icon from where you can enter Model Selection menu.
  • Page 6 3. Then select Helicopter or Plane and enter Model Name if using Spirit W1. By default Spirit W1 units are preloaded with Helicopter firmware. You can flash Spirit Aero firmware for free at any moment if you plan to use a plane.

  • Page 7: Model Configuration

    Model menu pages After binding with Spirit W1 you can find three menu pages in the Model Menu. If Spirit unit is not detected only two menu pages are visible. Spirit - Full integration and configuration of the Spirit Flybarless unit.
  • Page 8 2 Mounting Correct mounting of the Spirit W1 unit plays an important role for the operation of your model. Find a suitable location where vibrations are as low as possible - this is usually the same location shown by the manufacturer for mounting a gyro.
  • Page 9 We recommend to use supplied double sided tape. Antenna Spirit W1 is equipped with 2 full-range antennas. For the best signal reception it is necessary to mount them properly at the model. Ends of the antennas should be perpendicular to each other in all directions for optimal signal radiation.
  • Page 10 3 Wiring Spirit W1 has support for 4x swashplate, 1x tail and 1x throttle servos. It has also 2x independent telemetry ports which mean you can attach directly two Spirit Wave sensors. Moreover you can optionally connect a backup receiver.
  • Page 11 Servo Wiring According following diagrams you can connect servos to the Spirit W1. If some of your servos are not 1520μs center pulse, please connect the servo later during Setup Wizard process. CH1 and CH3 - Aileron/Pitch servo CH2 - Elevator Servo...

  • Page 12: Power Supply

    Power Supply Power Supply is critical part of the model. For this reason it is highly recommended to use suitable BEC or battery that can handle used servos. Once wiring and setup is completed it is highly advised to perform the BEC test.
  • Page 13 Telemetry Spirit W1 is equipped with 2 separate inputs for Spirit Telemetry sensors. These sensors are compatible also with external Spirit RX receivers. Available telemetry ports: Please note these ports are not used for ESC telemetry or GeoLink module. Spirit W1 is equipped also with X pin at T2/RPM/X port. This pin is used internally for communication with built-in receiver.
  • Page 14 Telemetry Sensor Data You can set display Sensor Data at the Main screen by opening adding Widgets. Spirit Telemetry Besides Spirit Telemetry sensors you can also utilize the ESC Telemetry, GeoLink module and Spirit telemetry variables. This mean you can interface your ESC and display telemetry data such as Battery Voltage, Current, Consumed Capacity, Temperature, RPM.
  • Page 15 For more details about ESC telemetry please visit linked guide. Similarly you can install GeoLink for measuring GPS position, Speed and other variables.

  • Page 16: Binding Procedure

    In order to Bind Spirit W1 with your Wave radio use supplied Bind plug. 1. Insert Bind plug at the SYS port and connect Power supply to the Spirit W1 unit. You can connect BEC or 1-3S Battery at the THR, AUX, T1 ports.
  • Page 17 You can easily change any parameter and changes are applied immediately. But to store any changes do not forget to Save the settings. Click at the Save Settings in the Spirit menu to save all changes you have made in the Spirit W1 settings. Otherwise after re-power changes are returned to the previous values.
  • Page 18 Spirit setup To prepare Spirit unit for flight it is necessary to go through Setup Wizard first. This process is required only once, always for a new model. You can find the Setup Wizard in the Model/Base/Setup Wizard.
  • Page 19 PC Configuration Spirit W1 units can be configured through any modern computer. This will allow the best comfort and guidance through the entire setup process. Spirit W1 is compatible with Spirit USB interface and can be connected and configured at any given moment.

  • Page 20: Fcc Compliance Statement

    6 FCC Compliance Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. CAUTION: The grantee is not responsible for any changes or modifications not expressly approved by the party responsible for compliance.
