Summary of Contents for Moes ZSS-X-PIR-C
- Page 1 HOME, SMART MOES HOME Instruction Manual PIR Motion Sensor Zigbee Please read the instruction manual carefully before using the product.
-
Page 2: Product Specification
Product specification Product name Smart PIR Motion Sensor Product Model ZSS-X-PIR-C Battery Specifications CR2450 (Included) Detection Distance 7 Metres Detection Angle 170° Operating Temperature -10°C- 50℃ Operating Humidity 10%-90% RH (No Condensation) Wireless Connection ZigBee (Smart Gateway Required) Alexa Third Party Control... - Page 3 Notes for using the Double-Sided Tape For a better bonding effect, apply The bonding surface must be clean, dry and smooth without force to the adhesive and rust,stain or dust. bonding surface to secure the bond. The VHB double-sided tape The tape requires a minimum application temperature of 10℃.
- Page 4 lnstallation lnstructions Attach the main body to the base using theadhesive protective film. Bottom Silicon Pad Remove the adhesive protective film and attach the main body to the base. Attach the base to wall or ceiling Remove the adhesive protective film from the base and attach to wall or ceiling...
-
Page 5: Preparation For Use
Preparation for use ① Download MOES App on App store or scan the QR code. Moes application is much more compatible than Tuya smart / smart life application. It also provides a new customized service for controlling scenes through Siri, widgets and scene recommendation. (Note: Tuya smart / Smart Life app is still working, but moes app is highly recommended) ②... - Page 6 Steps for connecting the APP to the device Ensure that the product is within effective coverage of the smart host (Gateway) ZigBee network to ensure that the product is effectively connected to the smart host (Gateway) ZigBee network. Method One： Scan the QR code to configure the network guide.
- Page 7 ZCSmart PIR MotionSensor ③ Scan this QR code Method Two： 1. Make sure your Smart Life/Tuya Smart APP has successfully connected to a Zigbee gateway.
- Page 8 2.Using the reset needle, press and hold reset button for more than 6s until the network indicator flashes,the device is under the APP confifiguration state. 3.Enter the gateway.Please follow the picture below to finish as “Add subdevice→LED already blink,and the connecting will take about 10-120 secondsto complete depending on your network condition.
- Page 9 4.Add the device successfully, you can edit the name of the device to enter the device page by click “Done”. ZSmart PIR MotionSensor ZSmart PIR Motion Sensor...
- Page 10 5.Click“Done”to enter the device page to enjoy your smart life with home automation. Smart PIR MotionSensor...
-
Page 11: Recycling Information
How to Reset/Re-pair ZigBee code Using the reset needle, press and hold reset button for more than 6s until the network indicator flashes, the device is under the APP confifiguration state. RECYCLING INFORMATION ① Storage: Products should be put in the warehouse where the temperature is between the range -10℃... - Page 12 2. The battery of the product should be recycled, and it must be recycled or disposed of separately from household waste. Dispose of batteries in accordance with local environmental regulations. ③ Troubleshooting measures 1. Why does the device fail to link to the APP? a.
- Page 13 2. Why doesn’t the indicator flash after the device is power-on? a.The indicator will flash after the product is powered on.If not, please check whether the battery power is sufficient b.Check whether the device is in good contact and in normal APP configuration state before checking its indicator status. If the indicator does not blink yet, you may please contact our after-sales service. 3. What to do if the smart linkage can not work between devices? a.Please confirm the device has been connected to the network which is under normal connection state. b.Please confirm whether you have updated your APP to newest version. c.Please confirm whether the smart scene set in the APP works with no conflict to other scenes. 4. What if my device breaks down and doesn't respond for a long time? a. Hello,you may please try to reset the device by removing from he APP for new APP configuration.
- Page 14 SERVICE Thank you for your trust and support to our products, we will provide you with a two-year worry-free after-sales service (freight is not included), please do not alter this warranty service card, to safeguard your legitimate rights and interests. If you need service or have any questions, please consult the distributor or contact us.
- Page 15 RECYCLING INFORMATION All products marked with the symbol for separate collection of waste electrical and electronic equip ment (WEEE Directive 2012/19 / EU) must be disposed of separately from unsorted municipal waste. To protect your health and the environment, this equipment must be disposed of at designated collection points for electrical and electronic equipment designated by the government or local authorities.
- Page 16 WARRANTY CARD Product Information Product Name_____________________________________ Product Type______________________________________ Purchase date_____________________________________ Warranty Period___________________________________ Dealer Information_________________________________ Customer's Name__________________________________ Customer Phone___________________________________ Customer Address_________________________________ __________________________________________________...
- Page 17 Maintenance Records Failure date Cause Of Issue Fault Content Principal Thank you for your support and purchase at we Moes, we are always here for your complete satisfaction, just feel free to share your great shopping experience with If you have any other need, please do not hesitate to...
- Page 18 MOES.Official @moessmart @moes_smart @moes_smart @moes_smart www.moes.net EVATOST CONSULTING LTD Address: Suite 11, First Floor, Moy Road Business Centre, Taffs Well, Cardiff, Wales, CF15 7QR Tel: +44-292-1680945 Email: contact@evatmaster.com AMZLAB GmbH Laubenhof 23, 45326 Essen Made In China...
- Page 19 Manufacturer: WENZHOU NOVA NEW ENERGY CO.,LTD Address: Power Science and Technology Innovation Center, NO.238, Wei 11 Road, Yueqing Economic Development Zone, Yueqing, Zhejiang, China Tel: +86-577-57186815 After Service Email: service@moeshouse.com...
