Damp2Dry 2PACD250 Owner's Manual

250 pint commercial dehumidifier

Advertisement

Quick Links

OWNER'S MANUAL
250 PINT COMMERCIAL DEHUMIDIFIER
MODEL 2PACD250

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2PACD250 and is the answer not in the manual?

Questions and answers

Summary of Contents for Damp2Dry 2PACD250

  • Page 1 OWNER’S MANUAL 250 PINT COMMERCIAL DEHUMIDIFIER MODEL 2PACD250...
  • Page 2 PRODUCT PARAMETER TABLE Model 2PACD250 Power Supply 115V/60Hz/1Ph Rated Input Current 5.3 amps at 65°F 60%RH Rated Input Power 578 watt at 65°F 60%RH The Air Volume 235CFM Dehumidification Capacity (80°F / 60% RH) 140PPD Dehumidification Capacity (90°F / 90% RH)
  • Page 3: Table Of Contents

    TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTION ..................... 4 SAFETY TIPS ....................................4 NOTICE OF OPERATION ................................4 IDENTIFICATION OF PARTS ......................5 PRODUCT DESCRIPTION ................................5 INSTALLATION GUIDE................................. 6 OPERATING INSTRUCTIONS ......................7 CONTROL PANEL ..................................7 CONTROL PANEL FEATURES ..............................8 BUTTONS ..............................................8 ICONS ..............................................9 POWER-ON AUTOMATIC DETECTION ..........................11...
  • Page 4: Important Safety Instruction

    IMPORTANT SAFETY INSTRUCTION BEFORE INSTALLING AND USING YOUR DEHUMIDIFIER, PLEASE READ THIS OWNER'S MANUAL CAREFULLY. STORE THIS MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE. The use of electrical products may create hazards that include, but are not limited to injury, fire, electric shock.
  • Page 5: Identification Of Parts

    IDENTIFICATION OF PARTS PRODUCT DESCRIPTION Handle Air Intake Wheel Control Panel Air Outlet Drain Coupler...
  • Page 6: Installation Guide

    IDENTIFICATION OF PARTS (Continued) INSTALLATION GUIDE • Connect the drain hose to the machine's drain, making sure the two fittings are securely connected • The machine's drain outlet is located as shown above • Use a separate container to collect drain and periodically check for fullness, or run the drain directly to a floor drain or sink.
  • Page 7: Operating Instructions

    OPERATING INSTRUCTIONS CONTROL PANEL Draining Timer Running Bluetooth Screen WIFI Defrost /Child Lock AUTO (Fan) Inlet Humidity Fan Speed ( Low/High ) Outlet Humidity Relative Accumulated Humidity Temperature Running Time Manual Drain Cancel Timer (in timer mode) Screen Lock ON/OFF ON/OFF System Function...
  • Page 8: Control Panel Features

    OPERATING INSTRUCTIONS (Continued) CONTROL PANEL FEATURES NOTE: The following control panels are for explanation purpose only. The control panel of the unit you purchased may be slightly different according to the models. Your machine may not contain some indicators or buttons. The actual shape shall prevail. BUTTONS ON/OFF power button.
  • Page 9: Icons

    OPERATING INSTRUCTIONS (Continued) ICONS After connecting the power, short press the "on-off key" to turn it on, the dehumidification function is turned on, and the icon is displayed; press the power off again, the dehumidification function is turned off, and the icon is not displayed. SET HUMIDITY LEVEL •...
  • Page 10 OPERATING INSTRUCTIONS (Continued) ICONS FLASHING: In WiFi pairing mode. NOT FLASHING: WiFi is connected or connection was successful. When this icon is displayed, the timing function has been set; when this icon is not displayed, the timing function has not been set. 1) Timing Setting After pressing the to enter the timing setting, press the to adjust the...
  • Page 11: Power-On Automatic Detection

    OPERATING INSTRUCTIONS (Continued) POWER-ON AUTOMATIC DETECTION After power-on, all displays, indications, and back-lights will light up for 2 seconds, and the buzzer will beep briefly. At the same time, the system will conduct self-checks on communications and sensors, and the system will enter the shutdown state when the detection is normal.
  • Page 12: Adjust The Height Handle

    OPERATING INSTRUCTIONS (Continued) ADJUST THE HEIGHT HANDLE CLEANING THE AIR FILTER 1. Turn out the handle stopper. NOTE: Ensure that the air filter is not worn or 2. Adjust the handle to the appropriate damaged. The corners and edges of the air height gear.
  • Page 13: Troubleshooting

    TROUBLESHOOTING WIRING DIAGRAM ERROR CODES Code Description Solution Check the connection between the power board and Communication Fault display panel and reconnect them Humidity Sensor A Failure Check the connection of the humidity sensor or replace it Temperature Sensor A Failure Check the connection of the temp.
  • Page 14: Bom

    TROUBLESHOOTING (Continued)
  • Page 15: Parts List

    TROUBLESHOOTING (Continued) PARTS LIST DESCRIPTION DESCRIPTION Dust Cover Wind guide M16 Flat Pad 303001369 - Fan M16 Lock Nut Blocking plate Axle Fixings 302001693 - Middle support plate 301001025 - Heat exchanger 302001686 - Axle components Power cord fixing plate 399001063 - Filter Velcro Cover 302001676 - Air intake grille...
  • Page 16 5401 Dansher Road Countryside, IL 60525 844-4PA-AIRE 844-472-2473 support@perfectaire.us 877-997-2473 supportcanada@perfectaire.us CANADA SUPPORT www.perfectaire.us Printed in China 0923_M064...
