Xega XG-01 User Manual

3g / 4g lte camera
Hide thumbs

Advertisement

Table of Contents

3G / 4G LTE CAMERA USER MANUAL
(EN/DE/FR/IT/ES)
SCSMS-20220905

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XG-01 and is the answer not in the manual?

Questions and answers

Related Manuals for Xega XG-01

Summary of Contents for Xega XG-01

  • Page 1 3G / 4G LTE CAMERA USER MANUAL (EN/DE/FR/IT/ES) SCSMS-20220905...
  • Page 2 Italiano ------------------------------------- (57~70) Español Claim Your Lifetime Warranty Thank you for choosing XEGA products. We are commi�ed to providing the best service to all our customer. If anything has happened to your product, please contact us for a life�me warranty.

  • Page 3: Table Of Contents

    Table of Contents ---------------------------- (01) I. Product introduction (01) 2. Download and registration of APP on mobile phone --------------------------- (03~04) 3. Camera connection -------------------------------------- (05~10) 4. Buttons ------------------------------- (11) 5. Setting interface --------------------------- (12) 6. Cloud video interface ----------------------------- (13~14) 7.

  • Page 4: Product Introduction

    I. Product introduction Solar panel Screw Solar power Universal bracket cable Lens Microphone USB charge port Power switch 10M（32ft） Recommended installation method It is suggested to install the camera at a height of about 2.6m and with an inclination angle of 15°to 30°(manually adjustable according to the real-time view in the APP on your mobile phone to focus on the motion detection areas to capture the trigger monitions more accurately).
  • Page 5 http://app.ubianet.com/app/ubox/ 2.Account registration (1) Open the APP, choose the region where you are and register an account with a mobile phone number or e-mail address. It is suggested to verify the account through an e-mail address for purpose of password retrieving (Fig. 1). (2) Set and note down a password consisting of 8 to 32 digits or letters for the account (Fig.

  • Page 6: Camera Connection

    III. Camera connection Please realize access to videos by scanning the following QR code with your mobile phone or through the following link. https://youtu.be/53BXVysvf5M 1.Step 1: Prepare. ①The battery level of the camera may be low after long-time transportation. Before use, please charge the camera with a 5V charger or the USB charge port of a computer.
  • Page 7 ④After successful connection, you can modify the camera’s name and location manually and then click “Next” to add the camera (Fig. 7). (Fig. 3) (Fig. 4) (Fig. 5) (Fig. 6) (Fig. 7) -04-...

  • Page 8: Buttons

    Note: If camera connection fails, please try it again as below: 1.Check and make sure the camera’s battery level is high, power on the camera for 1 minute, press and hold the camera’s reset button for 10s, and release the reset button to connect the camera again. 2.Check and make sure the 4G traffic of the SIM card is sufficient, power off the camera, insert the SIM card and the TF card into it, and power on the camera again.
  • Page 9 (Fig. 9) (Fig. 11) (Fig. 10) Cloud service: For viewing the cloud service package information of the current device or subscribing the cloud storage service for the current device 4G traffic service: For viewing expiry date of the current traffic, and the remaining traffic, or scanning the QR code to top up the traffic package View UID: For viewing the current UID number of the camera Delete device: For deleting the device information currently on the APP...
  • Page 10 ③Add smart device: For adding a camera to be connected. ④Operating state of device:For displaying the device’s online or offline operating state 2. Real-time interface of device ① ⑩ ② ③ ⑭ ④ ⑬ ⑤ ⑪ ⑥ ⑦ ⑫ ⑧ ⑨...
  • Page 11 ⑯ ⑱ ⑰ ⑲ ⑳ (Fig. 13) (Fig. 13) 1. Setting interface For setting parameters of the camera For displaying number of the persons viewing 2. Number of viewers real-time images at the same time -08-...
  • Page 12 For displaying the current battery level (during 3. Battery icon charge, this icon is green and has a lightning symbol) For viewing the 4G network signal of the current camera 4. 4G signal For switching between the full-color night vision mode 5.
  • Page 13 For taking photos of real-time interfaces and saving them 13. Manual to the photo album of the APP photographing For enabling the sounds of talks to come out of 14. Intercom the camera button For downloading videos from the TF card and saving 15.Video them to the photo album download from...

  • Page 14: Setting Interface

    For zooming out real-time images (digital zooming 24. Video zoom function) 25. Video zoom For zooming in real-time images (digital zooming function) V. Setting interface 1.Storage management It is for enabling or disabling video storage to the cloud and the TF card, checking total capacity and available capacity of the TF card, or judging whether the camera has read the TF card.

  • Page 15: Cloud Video Interface

    6.Alarm sound If this function is enabled, the camera will alarm audibly automatically after detecting any moving object. 7.Synchronize time If the time on the camera is not synchronous with the time on your mobile phone, you can click this button to make the APP synchronize them automatically.

  • Page 16: Common Problems

    VII.Common problems 1.Why does the camera power off automatically after the red LED has flashed for several times following Power ON/OFF button pressing? The battery is low because of a short charge time. Please charge the camera with a 5V charger. The charge time should be 8h at least for a 5v/2a camera, or 16h at least for a 5v/1a camera.
  • Page 17 5.Why cannot my mobile phone receive alarms while the camera can detect persons and record videos? Check and make sure the symbol on the device list page of the APP, and all the background permissions of the APP have all been enabled; keep the APP run on background of the mobile phone.
