- Page 1 Micro Reader MR-1 User Manual Document Number : 090-01-001-DOC Rev C2 Last Changed : 18 January 2022 Author : Tai Wai Pong Copyright SATO Vicinity 2022 Commercial in Confidence...
-
Page 2: Table Of Contents
Overview ........................1 Features and Benefits ....................2 Specifications ....................... 2 Dimensions ........................3 Connections ........................4 J1 - Host Connector ....................4 J2 - Antenna Connector ..................4 Antenna ........................5 Micro Reader MR-1 User Manual 090-01-001-DOC C2 18-Jan-22021... - Page 3 ISO/IEC 18000 – 3 Mode 2 (Air Interface at 13.56 MHz) Compliance MR-1 module fully comply with the ISO/IEC18000 Part 3 Mode 2(Information technology – Radio frequency identification for item management. Part 3: Parameters for air interface communications at 13.56MHz) published in August, 2004.
-
Page 4: Overview
1. Overview The MR-1 is the smallest and simplest of Magellan’s reader modules. It is intended for Original Equipment Manufacturer (OEM) applications where it is typically embedded in an RFID enabled product. Examples include printers, hand held readers, data capture terminals, low cost desktop readers, identification and access controls. -
Page 5: Features And Benefits
0°C to +70°C ambient 10% to 80% (non- Humidity condensing) Mechanical External Dimensions: (L x W 60 x 40 x 12.5 mm x H) Other Features No manual calibration or Calibration and Tuning tuning required Micro Reader MR-1 User Manual 090-01-001-DOC 18-Jan-22... -
Page 6: Dimensions
4. Dimensions 56.0 60.0 60.0 Figure 3 : Major Module Dimensions (mm) Mounting Holes 4x 3.2 mm diameter Micro Reader MR-1 User Manual 090-01-001-DOC 18-Jan-22... -
Page 7: Connections
TxD UART Transmit Signal (+5V CMOS) Output from module. Not Connected Not Connected Not Connected Not Connected 5.2 J2 - Antenna Connector Connector Type 2 pin (JST Model S2B-PH-K-S) Reference: http://www.jst-mfg.com/product/pdf/eng/ePH.pdf Pin Number Function Ground Micro Reader MR-1 User Manual 090-01-001-DOC 18-Jan-22... -
Page 8: Antenna
Antenna Cable Length 50 cm maximum Antenna Cable Types Twisted Pair or 50 Ohm co-ax. Figure 4 : Dimensions of 090-10-010-ASY Ver: A 6-Turn Antenna (mm) (Equivalent for unit in SATO CG208 Printer). Micro Reader MR-1 User Manual 090-01-001-DOC 18-Jan-22... - Page 9 ©2015 SATO Vicinity. All rights reserved. Specifications subject to change without notice. Any unauthorized reproduction of the contents of this presentation, in part or whole, is strictly prohibited. SATO is a registered trademark of SATO Holdings Corporation and its subsidiaries in Japan, the U.S. and other countries. All other trademarks are the property of their respective owners.
