Copeland WHITE-RODGERS 50M56X-843 Installation Instructions Manual

Universal integrated single stage 120v hot surface ignition control kit

Advertisement

Quick Links

FAILURE TO READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY BEFORE
INSTALLING OR OPERATING THIS CONTROL COULD CAUSE PERSONAL
INJURY AND/OR PROPERTY DAMAGE.

DESCRIPTION

50M56X-843 is an aftermarket universal replacement control
kit for single stage furnace applications with PSC or ECMx
(constant torque) blower motors. A HotRod
is included to replace ignitors in most furnaces as well as
upgrade 80V systems to 120V.
With 50M56X-843 no complex adapter harnesses are
required, instead all connectors and terminals used in the
major OEM brands are included on the control itself. This
allows for OEM wiring to be connected directly to the control
for a faster and easier installation.
ELECTRICAL SPECIFICATIONS
Specification
Input Voltage
Input Current
Line Frequency
Inducer Relay at 120V
Gas Valve Relay @ 30V
Ignitor Relay @ 120V
PSC Circulator Relay
OPERATING TEMPERATURE RANGE:
-40° to 176°F (-40° to 80°C)
HUMIDITY RANGE:
5 to 95% relative humidity (non-condensing)
GASES APPROVED:
Natural, Manufactured, Mixed, Liquid Petroleum,
and LP Gas Air Mixtures
CONTENTS
Description...................................................................... 1
Precautions..................................................................... 1
Configuration .................................................................. 2
Installation ...................................................................... 3
Application & Operation Notes........................................ 5
Wiring Diagram ............................................................... 7
Troubleshooting..............................................................11
INSTALLER MUST READ
APPLICATION AND OPERATION NOTES ON
PAGES 5, 6, & 7
120V ignitor
Value
Unit
18-30
VAC
Max 800
mA
60
Hz
2.8A
FLA
1.5
Amperes
1.2
Amperes
10
FLA
copeland.com/white-rodgers
50M56X-843
Universal Integrated Single Stage
120V Hot Surface Ignition Control Kit
INSTALLATION INSTRUCTIONS
Included in the box:
1 - 50M56X-843 Ignition Control
1 - HotRod
Ignitor
1 - Installation Instructions
4 - 1/2" Sheet Metal Mounting
Screws
6 - 3/16" QC crimp on terminals
6 - 1/4" Female Spade Terminals
5 - Mounting Standoffs
WARNING
!
Failure to comply with the following warnings could result
in personal injury or pro perty damage.
Installation should be done by a qualified heating and
air conditioning contractor or licensed electrician.
All wiring must conform to local and national
electrical codes and ordinances.
Following installation or replacement, follow
manufacturer's recommended installation/service
instructions to ensure proper operation.
FIRE HAZARD
Do not exceed the specified voltage.
Protect module from direct contact with water
(dripping, spraying, rain, etc.).
If the module has been in direct contact with water,
replace the module.
Label all wires before disconnection when servicing
modules. Wiring errors can cause improper and
dangerous operation.
Route and secure wiring away from flame.
SHOCK HAZARD
Disconnect electric power before servicing.
Ensure proper earth grounding of appliance.
Ensure proper connection of line neutral and line
hot wires.
Ensure module has ¼" clearance between all sides
of module and grounded metal.
EXPLOSION HAZARD
Shut off main gas to appliance until installation
is complete.
View Installation
Resources
PART NO. 37-78270012
2233

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WHITE-RODGERS 50M56X-843 and is the answer not in the manual?

Questions and answers

Summary of Contents for Copeland WHITE-RODGERS 50M56X-843

  • Page 1: Table Of Contents

    Ensure module has ¼” clearance between all sides INSTALLER MUST READ of module and grounded metal. EXPLOSION HAZARD APPLICATION AND OPERATION NOTES ON • Shut off main gas to appliance until installation PAGES 5, 6, & 7 is complete. PART NO. 37-78270012 copeland.com/white-rodgers 2233...
  • Page 2: Configuration

    MOBILE APP CONFIGURATION (PREFERRED) For fastest setup, use White-Rodgers Connect App: Download from iOS App Store or Google Play Store Open White-Rodgers Connect App Touch “Connect to Control” on the home page Place Device above NFC Logo on Module, wait for check mark (iPhone NFC located at top of phone, Android NFC located in middle of phone) Configure all settings in App Touch “Update Control”...
  • Page 3: Installation

    INSTALLATION Table 1: Configuration Menu Options *Factory Default Setting No. Option Menu Item Option Display Selections Menu Description / Notes Cycles through up to 4 active errors. XX=2 digit Active Fault Menu “Exx” Fault Code ex. E01 Firmware Version “rXX” Displays Firmware Version Number Display Selected Displays Harness / Connector (Auto)
  • Page 4 INSTALLATION NOTE: All wiring should be installed according to local and national electrical codes and ordinances Disconnect electrical power and shut off gas supply to Connect all the remaining individual wires to the new unit, then remove unit access panels. 50M56X-843 control board referencing the Wiring Mark and disconnect all wires from the existing control, Diagrams section as needed.
  • Page 5: Application & Operation Notes

    APPLICATION & OPERATION NOTES Ignitor Replacement The following cross reference control numbers are for 80V ignition systems that must be upgraded to 120V by replacing the OEM ignitor with the included HotRod ignitor. However, it is recommended to replace original 120V ignitors as well. ™...
  • Page 6 APPLICATION & OPERATION NOTES During the automatic configuration process the control is OEM Wiring Terminal Spacing Connector able to configure for specific OEM applications and harness Some OEM furnaces, for example Trane and American pinouts by detecting differences in OEM wiring and which Standard, have a plastic connector housing that groups loads are present on specific connector terminals.
  • Page 7: Wiring Diagram

    WIRING DIAGRAM INDUCER IGNITOR IND‐N IGN‐N NEUTRAL HEAT 120VAC HUMIDIFIER COOL BLOWER TRANSFORMER HEAT LO‐COOL HI‐COOL LINE‐N XFMR‐N NEUTRAL‐1 COM (TRANE) ECMx NEUTRAL‐2 BLOWER NEUTRAL‐3 1/4” TR or NEUTRAL‐4 3/16" TR NEUTRAL‐5 1/4” TH or 3/16" TH NEUTRAL‐6 FLAME  CARRIER BLW‐N CURRENT SENSE TWIN TERMINAL...
  • Page 8 WIRING DIAGRAM 6‐Socket: Nordyne/Nortek Configuration 6‐Socket: Rheem/Ruud Configuration # DESCRIPTION # DESCRIPTION IGNITOR HOT INDUCER HOT (OPEN) (OPEN) IGNITOR IGNITOR NEUTRAL IGNITOR HOT INDUCER HOT INDUCER IGNITOR INDUCER NEUTRAL (OPEN) (OPEN) 6‐SOCKET 6‐SOCKET INDUCER NEUTRAL IGNITOR NEUTRAL INDUCER 4‐Pin: Goodman/Amana/Trane/American Standard/Lennox/ 4‐Pin: Trane/American Standard Alt. Configuration Allied Air/York/Coleman/Luxaire Configuration # DESCRIPTION # DESCRIPTION INDUCER HOT...
  • Page 9 WIRING DIAGRAM 9‐Socket: Goodman/Amana Configuration 9‐Socket: Goodman/Amana Alt. Configuration # DESCRIPTION # DESCRIPTION (OPEN) (JUMPER TO PIN 4) PRESSURE SWITCH OUT PRESSURE SWITCH OUT TRANSFORMER HIGH XFMR TRANSFORMER HIGH XFMR (OPEN) (JUMPER TO PIN 1) HIGH LIMIT IN HIGH LIMIT IN TRANSFORMER RETURN TRANSFORMER RETURN MAIN VALVE OUT MAIN VALVE OUT * SEE NOTE PRESSURE SWITCH IN PRESSURE SWITCH IN 9‐SOCKET 9‐SOCKET HIGH LIMIT OUT GAS VALVE GAS VALVE HIGH LIMIT OUT Note *: ‐ Only present on high ...
  • Page 10 WIRING DIAGRAM 10‐Pin Inline: Trane/American Standard 10‐Pin Inline: Trane/American Standard Alt. Configuration # DESCRIPTION # DESCRIPTION FLAME SENSOR FLAME SENSOR INDUCER LIMIT IN (OPEN) TRANSFORMER RETURN TRANSFORMER RETURN PRESSURE SWITCH IN PRESSURE SWITCH IN HIGH LIMIT OUT HIGH LIMIT OUT MAIN VALVE COMMON MAIN VALVE COMMON VALVE VALVE TRANSFORMER HIGH TRANSFORMER HIGH CHASSIS GROUND CHASSIS GROUND MAIN VALVE OUT MAIN VALVE OUT HIGH LIMIT IN HIGH LIMIT IN 10‐PIN 10‐PIN XFMR...
  • Page 11: Troubleshooting

    TROUBLESHOOTING Table 2: 7-Segment Display Codes Condition LED 1 LED 2 LED 3 Comment/Troubleshoot Step Line Frequency Error / Internal Fault Verify 60 Hz line frequency, Replace control Pressure Switch Open Check pressure switch, inducer, and flue Flame Detected When no Flame Check gas valve for proper operation, check gas Should be Present valve and safety limit wiring...
  • Page 12: Control Reset

    TROUBLESHOOTING Module Duration Operation Action LED Display Extra Notes Status of Action • A maximum of 5 error codes are stored in the sequence they occur • Press OPTION button < 1 second to advance to Hold OPTION F L T next fault code Fault Code Standby...
  • Page 13 TROUBLESHOOTING See other error  codes,  Start E41 ERROR? troubleshooting  steps, or contact  customer service Replace ignitor  Turn on power to  Turn off power to  Is ignitor resistance  (Included Hot Rod  E41 still  furnace and retry  furnace above 100 ohms? Ignitor works in  present? auto configuration most systems) Turn off power  to furnace  Individually check  all Rollout and Limit  Turn on power to  Are any Rollout or  Reset or Replace  E41 still  switches with meter  furnace and retry  Limit switches open? faulty switch present? (safeties may not be  auto configuration in series) Turn off power  to furnace  Individually check  Turn on power to ...
  • Page 14 [ This page intentionally left blank ]...
  • Page 15 [ This page intentionally left blank ]...
  • Page 16 TECHNICAL SUPPORT: 1-888-725-9797 To learn more, visit copeland.com/white-rodgers R-6027 ©2024 Copeland LP.
