Washing Machine
OWNER'S MANUAL
Read This Manual
Use all instructions and explanations of the installation
before use.
Follow the instructions carefully.
Keep the operation instructions handy for later use.
If the application is sold or passed on then ensure
that the new owner always receives those operation
instructions.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Midea MAV160-2016PS/01FM-ZA
Summary of Contents for Midea MAV160-2016PS/01FM-ZA
- Page 1 Washing Machine OWNER’S MANUAL Read This Manual Use all instructions and explanations of the installation before use. Follow the instructions carefully. Keep the operation instructions handy for later use. If the application is sold or passed on then ensure that the new owner always receives those operation instructions.
-
Page 2: Table Of Contents
CONTENTS SAFETY INSTRUCTIONS Safety nstructions ............INSTALLATION Product description ............Packing the washing machine ......... Unpacking the washing machine ........Installation area ............... Installation of drain hose ..........Levelling the washing machine ......... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS Safety instructions For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric shock, or to prevent property damage, personal injury or loss of life. • This appliance is not intended for use by persons(including children) with reduced physical, sensory or mental capabilities or lack of experience and knowledge unless they have been given supervision or instruction concerning use of... -
Page 4: Safety Nstructions
SAFETY INSTRUCTIONS Model Washing Capacity Standard Water Pressure 16.0kg MAV160-2016PS/01FM-ZA 0.03MPa~0.8MPa Explanation of the symbols: Warning! This combination of symbol and signal word indicates a potentially dangerous situation which may result in death or serious injuries unless it’s avoided. Caution! - Page 5 SAFETY INSTRUCTIONS Warning! The electric shock! • This appliance is for indoor use only. • Do not put washing machine at humid place. • Hands shall not be inserted into running spin-dry tub . • If the spin-dry tub does not stop within 15 seconds after opening the cover, please stop using the machine and have it repaired.
- Page 6 SAFETY INSTRUCTIONS Risk to children! • EN countries: the appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 7 SAFETY INSTRUCTIONS Caution Installing the product! • This washing machine is for indoor use only. • It isn't intended to be built-in using. • The openings must not be obstructed by a carpet. • Washing machine shall not be installed in bath room or very wet rooms as well as in the rooms with explosive or caustic gases.
- Page 8 SAFETY INSTRUCTIONS • Please do not close the door with excessive forces. • It is forbidden to wash carpets. Operating the appliance! • Before washing the clothes at first time, the product shall be operated in one round of the whole procedures without the clothes inside.
-
Page 9: Installation
INSTALLATION Product description Handle Control panel Powder and liquid Top lid detergent box Water inlet valve Wash·Spin barrel Power Cord Filter Holder Cabinet handle Impeller Cabinet Drain hose Adjustable foot knob Note! • The product line chart is for reference only, please refer to real product as standard. -
Page 10: Packing The Washing Machine
INSTALLATION Packing the washing machine Unpacking the washing machine Warning! • Packaging material (e.g. Films, Styrofoam) can be dangerous for children. • There is a risk of suffocation ! Keep all packaging well away from children. 1. Remove the cardboard box and styrofoam packing. 2. -
Page 11: Installation Of Drain Hose
INSTALLATION Installation of drain hose 1.Completely sleeve the drain hose over the sewer. 2.Fix and tighten it with a hoop.( As shown in the figure ) Note! • Note: The drain hose of the machine with upper drain system has already been assembled before leaving the factory. -
Page 12: Selection Of Tap
INSTALLATION Selection of tap Please select appropriate tap. Screw tap Special washing Ordinary faucet machine tap Connection of inlet hose, tap and washing machine 1:Connection between ordinary tap and inlet hose. Wall Clamp nut 1.Loosen clamp nut to 2.Loosen four bolts 3.Set connecting base 4.Tighten clamp nut on tap and tighten... -
Page 13: Operations
Note! • Midea's unique water inlet logic: In order to achieve the best detergent dissolution effect, at the 2/3/4 water levels, when the water reaches a certain stage, it will stop the water inlet and start washing for 20 seconds. Then it will continue to add water for 15 seconds, repeating this process three times until the water inlet is finished. -
Page 14: Washing Matters Needing Attention
OPERATIONS Washing matters needing attention • The working condition of the washer should be(0-40)℃.If used under 0℃,the inlet valve and draining system may be damaged. If the machine is placed under condition of 0℃or less, then it should be transferred to normal ambient temperature to ensure the water supply hose and drain hose are not frozen before use. -
Page 15: Control Panel
OPERATIONS Control anel Note! • The chart is for reference only, Please refer to real product as standard. Start/Pause Turn to select Off to turn off your washer. Press the button to start or pause the washing cycle. Program Option Available according to the laundry type. - Page 16 OPERATIONS Option Option Water level Select water level according to clothing categories, degree of soiling and washing habits of customers. Stage selection Combination of soaking, washing, rinsing and spinning light is available. Turbo After choosing a program, the user can press Turbo buttonto start the function, making the program shorter and good washing performance.
-
Page 17: Personalized Setting Of Washing Program
OPERATIONS Child Lock If you want to lock all the buttons to prevent settings from being changed by children, you can activate the Child Lock function. How to Lock 1. Press the Power button to turn power on. 2. Press the Start/Pause button to start washing. 3.Press the rinse+ and the spin+ buttons 3sec. -
Page 18: Washing Program Table
OPERATIONS Washing program table Program are available according to the laundry type. Program To wash white clothes. WHITES COLOURS Suitable to wash the colorful clothes. To wash light dirty cloths with only one rinsing cycle. QUICK 20 COTTON Suitable to wash clothes made of cotton. SYNTHETIC To wash synthetic articles, for example: shirts, coats, blending. -
Page 19: Maintenance
MAINTENANCE Cleaning and care Warning! • Before your maintenance starts, please unplug the machine and close the tap. Cleaning the cabinet Proper maintenance on the washing machine can extend its working life. The surface can be cleaned with diluted non-abrasive neutral detergents when necessary. If there is any water overflow, use the wet cloth to wipe it off immediately. -
Page 20: Cleaning Drain Detergent Box
MAINTENANCE Cleaning drain detergent box 45 degrees up, remove Clean the dispenser Clean the recess with Insert the dispenser drawer and the softener the dispenser drawer. an soft brush. drawer from 45 degree cover under water. above Cleaning drain pump filter Warning! •... -
Page 21: Trouble Shooting
MAINTENANCE Trouble shooting The start of the appliance does not work or it stops during operation. First try to find a solution to the problem, If not, contact the service centre. Inspection Items Description If the power is off or the fuse is burned out. If the power supply voltage is too low. -
Page 22: Transport And Handling Method
MAINTENANCE Transport and handling method... -
Page 23: Technical Specifications
MAINTENANCE Technical Specifications Grade of waterproof Standard Water Pressure 0.03MPa~0.8MPa IPX4 Power Dimension Rated Washing Including drain hose Model Supply (W*D*H Weight Capacity input power (W*D*Hmm) 220-240V 16.0kg 47kg MAV160-2016PS/01FM-ZA 601x685x1050 850W 601*615*1050 ~,50Hz... - Page 24 Hefei Midea Laundry Appliance Co .,Ltd . V1.0 No.88 Yulan Road, Baiyan Science Park, High-TechZone, Hefei City, Anhui Province, P.R.China 注: 1.说 明书版本 号 从V1.0开 始计， 每 变 更一次自 动+ 1 2 .虚 线框内 印 刷 物料编码,由供应商按 照 订 单需求自 行 添 加,字 体: A r i a l, 大...
