- Page 1 PRL-1200 Wireless Pulse Link System Technical Manual Revision: A3 Date: 3/26/17 Solid State Instruments A division of Brayden Automation Corporation 6230 Aviation Circle Loveland, CO, USA 80538 (970)461-9600 (970)461-9605 e-mail: sales@brayden.com...
-
Page 2: Table Of Contents
PRL-1200 Wireless Pulse Link System Table of Contents Introduction .......... -
Page 3: Introduction
Introduction The PRL-1200 Pulse Radio Link is a Transmitter and Receiver system that wirelessly sends up to four channels of KYZ pulses between the transmitter and a receiver. The short-hop PRL-1200 has a range of up to 5,000 feet depending on site topography and solves the problem of getting pulses across parking lots, vacant lots, roads, railroad tracks or other obstacles. -
Page 4: Pulse Link System Design And Planning
PRL-1200 SYSTEM DESIGN AND PLANNING SYSTEM CONFIGURATION - The PRL-1200 can be used in one of two configurations: 4 Form A pulse channels or 2 Form C pulse channels. The entire system operates in either one mode or the other. They cannot be mixed. -
Page 5: Considerations For Asuccessful Installation
Radio/Antenna unit is mounted at least 6.1" away from the metal siding. Use the brackets supplied with the PRL-1200 to get this distance. You may have to rotate the board to insure that the antenna is not closer to the metal surface than 6.1", since the antenna is not exactly in the center of the board as well as the board being mounted in an off-set fashion. -
Page 6: Prnt-1200 Pulse Radio Transmitter
INSTRUCTION SHEET PRNT-1200 PULSE RADIO TRANSMITTER FCC ID: TIT-PRT-1200 Transmitter/ Antenna PCB PRNT-1200 PRNT-1200 Assembly (Tx) Transmitter/ Transmitter/ Antenna Antenna Spring-loaded 1 2 3 4 5 6 7 8 9 Lever (Press Unit Board down to open) Insert wire Ty-Rap holes here and for Cable release lever... - Page 7 INSTRUCTION SHEET PRT-1200 PULSE RADIO TRANSMITTER (con't) PRNT-1200 Transmitter/ PRT-12 Antenna Transmitter Unit Base Unit 8-Conductor 24AWG Control (Not to Scale) Cable with shield -100' max. POWER INPUT - The PRNT-1200 receives its power supply from the PRT-12 Transmitter Base unit. METER INPUTS - See the PRT-12 Base Unit Instruction Sheet for detailed information on connecting the K-Y pulse inputs to the Electric Meter's KYZ Pulse output.
- Page 8 Channel 6 is the highest channel that can be selected. The last three switch combinations all result in Channel #6 being selected. Setting the System Mode - The PRL-1200 operates in the 1- FIGURE 3 transmitter/1-receiver mode. Set Switch #4 to the DOWN TABLE 1 position.
-
Page 9: Prt-12 Transmitter Base Unit
INSTRUCTION SHEET PRT-12 PULSE TRANSMITTER BASE Wire Wire Function Color SHLD To PRNT-1200 NONE RSSI2 RSSI1 Transmitter Radio/ +Vcc Antenna Unit 24AWG (min)/8 conductor with shield 100' max. 2 Meters' 4 Meters' KYZ (3W ) KY (2W ) outputs outputs Z2in Input #4 Y2in... -
Page 10: Prnr-1200 Pulse Radio Receiver
INSTRUCTION SHEET PRNR-1200 PULSE RADIO RECEIVER PRNR-1200 Receiver/ Antenna PCB Assembly PRNR-1200 Receiver/ Dip Switch Antenna Spring-loaded 1 2 3 4 5 6 7 8 9 Unit Lever (Press down to open) Ty-Rap holes Insert wire for Cable here and Strain Relief release lever Ring Spacer... - Page 11 INSTRUCTION SHEET PRR-1200 PULSE RADIO RECEIVER (con't) PRNR-1200 PRR-12 Receiver/ Antenna Receiver Unit Base Unit 8 conductor #24AWG shielded Control Cable -100' (Not to Scale) max. POWER INPUT - The PRNR-1200 receives its power supply from the PRR-12 Receiver Base unit. PULSE OUTPUTS - See the PRR-12 Base Unit Instruction Sheet for detailed information on connecting the KYZ Outputs to the receiving device.
- Page 12 CHANNEL# SW#1 SW#2 SW#3 Setting the OUTPUT Mode - The PRL-1200 can operate in the Form C or Form A modes. The Form C mode, called 3-Wire mode, each input channel uses the K, Y and Z outputs, and two independent 3- Wire meter pulse channels are received and outputted.
-
Page 13: Prr-12 Receiver Base Unit
INSTRUCTION SHEET PRR-12 PULSE RECEIVER BASE UNIT SHLD NONE RSSI2 RSSI1 From PRNR-1200 +Vcc Receiver/Antenna Unit 24AWG (min)/8 conductor with shield 100' max. OUTPUT #2 OUTPUT #1 POWER SUPPLY INPUT 120V 277V GENERAL - The PRR-12 serves as a base unit, and termination point for the PRNR-1200 receiver/antenna unit. -
Page 14: Using The 2-Wire (Form A) Or 3-Wire (Form C) Modes
Transient voltage protection for the contacts of the solid state relays are provided by MOVs on board between the K and Y, as well as the K and Z outputs. Depending on user requirements the PRL-1200 can be operated in Form C mode and only two wires used on the output for the downstream device. This is perfectly acceptable, but remember to double the Form C pulse constant if your receiving device does not automatically adjust the pulse value. -
Page 15: Transmitter And Receiver Pairing Procedure
4 times per second. The fast flash means that the system has paired itself together. 5. Return Dip Switch #8 on both the transmitter and receiver units to the "DOWN" position to put the PRL-1200 system in the RUN mode. -
Page 16: System Diagram
PRL-1200 Wireless Pulse Link Application PRR-1200 PRNR-1200 Receiver Receiver/ Antenna Unit #24AWG 8- conductor shielded control PRT-1200 cable. Transmitter 900MHz* Radio 5000' Range Form C Form A Inputs Inputs PRR-12 Base Unit Mtr 1 Out 1 Mtr 1 PRNT-1200 Transmitter/... -
Page 17: Troubleshooting And Tech Support
NOTE: the PRL-1200 system does not change or modify the pulse values in any way. The pulse value is completely determined by the Ke value of the meter and the metering installation multiplier, which is based on Current Transformer (CT) and Potential Transformer (PT) ratios. -
Page 18: Troubleshooting Procedure
9. The Transmitter base unit is designed for mounting inside another control cabinet or enclosure appropriate and suitable for the particular application. If a NEMA 4X enclosure is required, order SSI P/N: 05000-47001A for the NEMA 4X Fiberglass 12” x 10” x 4” enclosure option. This option includes an interior mounting plate that the PRT-12 or PRR-12 mounts onto. -
Page 19: Fcc/Ic Notices
FCC / IC NOTICES This product contains FCC ID: Q7V-3F090009X / IC: 5589A-3F090009 This device complies with Part 15 of the FCC rules and Industry Canada license-exempt RSS standards. Operation of this device is subject to the following two conditions: 1. - Page 20 NOTES:...
