sks BLUEMELS 11846 Manual

Manual › BLUEMELS › CABLE LINE
EN . Scope of delivery
O 4x
F2 2x
F1 2x J 3x
A 1x B 1x
kurz
short
EN . Tools
EN
03
Place the damping rubbers (J)
on the clip in the wheel guard (B)
and audibly engage the strut (A).
B
2.
1.
J
EN
04
Screw the bracket of the wheel
guard (B) hand-tight to the bicycle
fork with the screw (K/L/M).
Optionally, use nut (P).
G 6x
Q 8x R 6x S 4x P 7x
H 6x
K 2x L 4x M 7x N 3x
C 1x
2x
D E 1x
lang
long
SW 8 4
Please note. The marking (TOP ↑ )
of the ESC adapter must point
towards the handlebar.
A
click
P optional
2.
B
EN . Front wheel mounting
EN
01
Insert the short strut (A) into
the ESC adapter (F).
T 8x
F
EN
02
Screw on the ESC adapter (F)
hand-tight with screw (G) and
nut (H).
F
G
2.
EN
05
Screw the ESC adapter (F) hand-
tight to the fork with the screw
(K/L/M) and the serrated lock
washer (O). Optionally, use spacer
(Q).
K/L/M
3.
EN
06
Adjust the distance between
the wheel guard and the tyre
to approx. 1.5 cm.
K/L/M
1.
GERMANY
Please note. The marking (TOP
of the ESC adapter must point
towards the handlebar.
A
Please note. On both sides, the
screws must be inserted into the
ESC adapters from the outside.
left
H
1.
Please note. In the case of forks
with a bore in the direction of tra-
vel, an accessory kit is required.
optional
F
O
Q
2.
1.
> 1,5 cm
ALLROAD MOUNTAIN
↑ )
right
< 1,5 cm
