ASSEMBLY INSTRUCTION
MODEL: KUBE4-1150w
1500 x 1500mm 4 Student Workbench
2 PCS
1
2
LEG ASSEMBLY
1150E
4 PCS
7
8
BUTTON HEAD SCREW
ADJUSTABLE FOOT
2
1
1150E
STEP 1
2 PCS
3
TOP RAIL
BOTTOM RAIL
1150T
1150B
10 PCS
9
FIXING SCREW T17 x 30
M10 x 100
FOR BENCHTOP
4
1150T
1150B
1150T
1150B
3
1150B
PARTS LIST
1 PCE
1 PCE
4
1150 x 1150 BENCH TOP
4 PCS
8 PCS
10
FIXING BRACKET SCREW
10G X 16 FOR BENCHTOP
1150E
7
x4
1
VERSION 022023-02
WOODWORK
10 PCS
5
6
M10 WASHER FOR
M10 CROSS PIN FOR
FRAME
4 PCS
11
12
BRACKET FOR BENCH
6MM HEX BIT FOR
TOP FIXING
FRAME ASSEMBLY
PARTS
1150E
SCREW THE ADJUSTABLE FEET (7) INTO
THE PRE-DRILLED HOLES IN THE BOTTOM
OF THE LEGS (1)
2 PEOPLE
RECOMMENDED
10 PCS
BENCH
1 PCE
1
7
