- Page 1 Owner’s Manual: Owner’s Manual: Autogyro Autogyro Auto Gyro Mixer 09025 Models www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015...
-
Page 2: Table Of Contents
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 Table of Contents Table of Contents 7. 7. Wiring Diagram Wiring Diagram 1. 1. Safety Information Safety Information 13 13 7.1 9025 1.1 Safety Precaution Labels 1.2 Safety Precaution Summary 8. -
Page 3: Safety Information
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 1. Safety Information 1. Safety Information Review this owner’s manual and read all warning labels on the machine prior to use. The three main safety notifications used in this manual and on the warning labels are WARNING, CAUTION and NOTICE. - Page 4 1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 Safety Information, Continued.. 1.1 Safety Precaution labels 1.1 Safety Precaution labels WARNING CUIDADO -This machine is not explosion proof rated. -Review product label, Material Safety Data Sheet, and HMIS rating of materials and exposures prior to mixing to determine potential hazards.
-
Page 5: Safety Precaution Summary
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 Safety Information, Continued.. 1.2 Safety Precaution Summary 1.2 Safety Precaution Summary CAUTION! WARNING! Review this owner's manuals before installing or operating. Keep the work area free of clutter and electrical cords. The machine must be properly grounded prior to use. -
Page 6: Introduction
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 2. Introduction 2. Introduction 2.1 Application 2.1 Application 2.2 Specifications 2.2 Specifications Model 09025 (Standard) Congratulations on your purchase of the 09025 Auto Gyro Mixer. This machine is designed to Model 09025A (Automation) accommodate standard five-gallon plastic or metal pails weighing up to 120 lb. -
Page 7: Installation
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 3. Installation 3. Installation MODEL 9025 MODEL 9025 15.5" - 20.5" Load Height www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015... -
Page 8: Prepare For Use
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 3.3 Verify the Machine is Level 3.3 Verify the Machine is Level 3.1 Prepare for Use 3.1 Prepare for Use IMPORTANT: Before attempting to operate the Adjust any feet under which a piece of paper can fit. machine: Loosen the upper jam nut (A) 1. -
Page 9: Operation
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 4. Operation 4. Operation 4.1 Control Panel 4.1 Control Panel • E-Stop Push Button (A): Immedately cuts power to the machine, and Cycles Power. • Display (B): View programming revison, Cycle count, and cycle time remaining. •... -
Page 10: Install A Pail
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 ..Operation, Continued NOTICE 4.2 Install and Remove Pail 4.2 Install and Remove Pail The door is locked during mixing. INSTALL: REMOVAL: Warning! WARNING Avoid serious personal injury! Do Avoid serious personal injury. Do not mix not attempt to override the door lock. -
Page 11: Care And Maintenance
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 5. Care and Maintenance 5. Care and Maintenance WARNING! Avoid serious personal injury. Always unplug the power cord before performing maintenance tasks. 5.1 Cleaning 5.1 Cleaning 5.2 Maintenance 5.2 Maintenance 1) Lubricate the clamp screw and Avoid serious personal injury. -
Page 12: Troubleshooting
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 6. Troubleshooting 6. Troubleshooting PROBLEM CAUSE REMEDY Not connected to power source Connect to power source Machine won't operate Turn switch knob 1/4-turn clockwise to Emergency E-STOP push button is activated disengage Machine door does not make contact... -
Page 13: Wiring Diagram
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 7.1 Wiring Diagram 9025 7.1 Wiring Diagram 9025 www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015... -
Page 14: Exploded Views
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 ...Exploded Views, Continued 8. Exploded Views 8. Exploded Views 8.1 Riser Legs 8.1 Riser Legs Exploded Views, Continued... www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015... -
Page 15: Base
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 ...Exploded Views, Continued 8.2 Base 8.2 Base BOM ID PART # DESCRIPTION BOM ID PART # DESCRIPTION 9788632 WELDMENT, BASE, AUTOCLAMP GYRO 9781620 SCREW, HEX HD 1/4-20X13/4 GR5 ZINC EXTRACTOR BOTTOM SEE 8.4 9782154 SCREW, HEX HD 1/2-13X11/2 GR8 ZINC RISER ASSEMBLY SEE 8.1... -
Page 16: Vertical Lock
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 ...Exploded Views, Continued 8.3 Vertical Lock 8.3 Vertical Lock PART NUMBERS LISTED MAY ONLY BE AVAILABLE IN KIT FORM OR AS AN ASSEMBLY Exploded Views, Continued... www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015... -
Page 17: Bottom Tray
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 ...Exploded Views, Continued 8.4 Bottom Tray 8.4 Bottom Tray PART NUMBERS LISTED MAY ONLY BE AVAILABLE IN KIT FORM OR AS AN ASSEMBLY Exploded Views, Continued... www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015... -
Page 18: Clamp Frame
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 ...Exploded Views, Continued 8.5 Clamp Frame 8.5 Clamp Frame BOM ID PART # DESCRIPTION 5788599 MOTOR, CLAMP, 200 RPM 9788656 GROMMET, .28ID, .12 TH PLATE 9788657 SPACER, #10, .25OD, .375 LG 9788645 SUPPORT, MOTOR, AUTOGYRO 9780749... -
Page 19: Clamp Frame, Top Clamp
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 ...Exploded Views, Continued 8.6 Clamp Frame, Top Clamp 8.6 Clamp Frame, Top Clamp BOM ID PART # DESCRIPTION BOM ID PART # DESCRIPTION 9787991 BEARING, DOUBLE ROW, 3203 9788087 SCREW HEX HD 5/16-18 X 0.50 -PATCH 9788095 WASHER, SELF ALIGNING, 3_4IN SCREW, FEMALE 9788088 SCREW HEX HD GR8 1/4-20 X 0.75 -PATCH... -
Page 20: Clamp Frame, Bottom Clamp
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 ...Exploded Views, Continued 8.7 Clamp Frame, Bottom Clamp 8.7 Clamp Frame, Bottom Clamp BOM ID PART # DESCRIPTION BOM ID PART # DESCRIPTION 5788653 SENSOR, INDUCTIVE, M12 BODY, M12 CONN, 4MM 9788652 SCREW, HEX HD 1/4-20 X 7 RANGE... -
Page 21: Clamp Frame, Auto. Bottom Clamp
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 ...Exploded Views, Continued 8.8 Clamp Frame, Automation Bottom Clamp 8.8 Clamp Frame, Automation Bottom Clamp BOM ID PART # DESCRIPTION BOM ID PART # DESCRIPTION 9788577 NUT HOLDER 6789221 KIT, FWD LOCK ASSY 9025 (See 8.10 for details) 9788630 SPACER, CUSTOM, 17MM 9788026... -
Page 22: Bottom Clamp, Extractor Assembly
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 ...Exploded Views, Continued 8.9 Bottom Clamp, Extractor Assembly 8.9 Bottom Clamp, Extractor Assembly Note: This assembly is not included in the Automation version Exploded Views, Continued... www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015... -
Page 23: Bottom Clamp, Motor Assembly
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 ...Exploded Views, Continued 8.10 Bottom Clamp, Motor Assembly 8.10 Bottom Clamp, Motor Assembly BOM ID PART # DESCRIPTION 5788494 MOTOR, SMALL FWD LOCK 9789764 NUT, HEX 1/4-20 DISTORTED THREAD 9788704 BEARING .25 ID, DUAL SEAL 9789679 BEARING, BRONZE, .25 ID X .25 LG... -
Page 24: Enclosure
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 ...Exploded Views, Continued 8.11 Enclosure 8.11 Enclosure PART NUMBERS LISTED MAY ONLY BE AVAILABLE IN KIT FORM OR AS AN ASSEMBLY Exploded Views, Continued... www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015... -
Page 25: Top Panel And Door Lock
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 ...Exploded Views, Continued 8.12 Top Panel and Door Lock 8.12 Top Panel and Door Lock Note: Automation version only uses items 1 & 2. PART NUMBERS LISTED MAY ONLY BE AVAILABLE IN KIT FORM OR AS AN ASSEMBLY Exploded Views, Continued... -
Page 26: Automation Enclosure
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 ...Exploded Views, Continued 8.13 Automation Enclosure 8.13 Automation Enclosure PART NUMBERS LISTED MAY ONLY BE AVAILABLE IN KIT FORM OR AS AN ASSEMBLY Exploded Views, Continued... www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015... -
Page 27: Control Panel
1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 ...Exploded Views, Continued 8.14 Control Panel 8.14 Control Panel PART NUMBERS LISTED MAY ONLY BE AVAILABLE IN KIT FORM OR AS AN ASSEMBLY Exploded Views, Continued... www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015... -
Page 28: Ordering
While your machine is under warranty, do not attempt on-site repair or parts replacement without first contacting RADIA to protect your warranty. After the warranty expires, replacement parts and recommendations for on-site servicing are available from RADIA. Please Customer Care for assistance. - Page 29 1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 Notes Notes www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015...
- Page 30 1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 Notes Notes www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015...
- Page 31 1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 Notes Notes www.radiaproducts.com (PHONE) 800-221-1083 | (INTL) +1-763-533-2969 | (FAX) 763-533-0015...
-
Page 32: Warranty
Radia. Subject to the limitations set forth above, Radia shall (i) repair or replace the equipment (or the defective part) or (ii) credit or refund the price of such equipment. Costs of labor and transportation for service of machines under this warranty will also be covered during the warranty period if Radia elects to repair or replace the equipment. - Page 33 1788824 Rev H Owner’s Manual: 09025 ECO 18-0060 December 2023 For sales or service, please contact For sales or service, please contact RADIA Attn: Customer Service Department 14900 21st Ave N Plymouth, Mn 55447 U.S. Telephone: 800.211.1083 International Telephone: 763.533.2969 Fax: 763.533.0015...
