- Page 1 LTN7E273E User Manual Washing Machine USER MANUAL...
- Page 2 17. ENVIRONMENTAL CONCERNS..............36 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.
- Page 3 ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.
- Page 4 This appliance is intended to be used in household • and similar applications such as: staff kitchen areas in shops, offices and other – working environments; by clients in hotels, motels, bed & breakfast and – other residential type environments;...
- Page 5 ENGLISH future they must be reattached to lock • Make sure not to cause damage to the drum to prevent an internal the mains plug and to the mains damage. cable. Should the mains cable need to • Always take care when moving the be replaced, this must be carried out appliance as it is heavy.
- Page 6 • Do not put flammable products or hinge and seals, other seals, door items that are wet with flammable locking assembly, plastic peripherals products in, near or on the appliance. such as detergent dispensers. Please • Do not wash fabrics which are heavily...
- Page 7 ENGLISH 3.2 Appliance overview 10 11 Control panel Drain hose Mains cable Lid push handle Transit bolts Drain pump filter Hose support Lever to move the appliance Rating plate Feet for levelling the appliance Inlet hose Information for register product. The rating plate reports the model name The info label reports the model name (A), (A) , product number (B), electrical...
- Page 8 4. TECHNICAL DATA Dimension Width/ Height/ Total depth 39,7 cm /90,3 cm /59,9 cm Electrical connection Voltage 230 V Overall power 2200 W Fuse 10 A Frequency 50 Hz Level of protection against ingress of solid particles and IPX4 moisture ensured by the protective cover, except where the low voltage equipment has no protection against mois‐...
- Page 9 ENGLISH We recommend that you keep the packaging and the transit bolts for any transport of the appliance. Adjust the appliance correctly to prevent vibration, noise and movement of the appliance when it operates. WARNING! Do not put cardboard, wood or equivalent materials below the appliance feet to adjust the level.
- Page 10 5.3 Water drainage min.600 mm max.1000 mm The drain hose should stay at a height of no less than 600 mm and not more than 1000 mm. You can extend the drain hose to maximum 4000 mm. Contact the authorised service centre for the other drain hose and the extension.
- Page 11 ENGLISH 6. CONTROL PANEL 6.1 Control panel description 12 11 On/Off push button Stain/Prewash touch button Programme dial • Stain option Display • Prewash option Delay Start touch button Anti-Allergy touch button Time Save touch button Steam Finish touch button Rinse touch button Spin touch button •...
- Page 12 The indicator flashes during the laundry load estimation. Maximum laundry indicator. It flashes when the laundry load exceeds the maximum declared load of the selected programme. Lid locked indicator. Delay start indicator. The digital indicator can show: • Programme duration (e. g.
- Page 13 ENGLISH 7. PROGRAMME CHART Washing programmes Programme Programme description White cotton and fast-coloured cotton. Normally soiled items. The energy consumption decreases and the time of the Eco 40-60 washing programme is extended, ensuring good washing re‐ sults. White cotton and coloured cotton. Normally, heavily and lightly soiled items.
- Page 14 Programme Programme description Do not us fabric softener and make sure there is no softener residue in the detergent dispens‐ Outdoor clothing, technical, sport fabrics, waterproof and breathable jackets, shell jackets with a removable fleece or inner insulation.The recommended laundry load is 2 kg. This programme can also be used as water-repellent restoring cycle, specifically tailored for treating clothes with a hydrophobic coat‐...
- Page 15 ENGLISH Programme Default tempera‐ Reference spin Maximum load ture speed Temperature range Spin speed range 40 °C 1200 rpm 1.5 kg 40 °C - Cold 1200- 400 rpm Wool/Silk 1 kg Steam 30 °C 1200 rpm 3 kg 40 °C - 30 °C 1200 - 400 rpm 20 min.
- Page 16 OPTIONS ■ ■ ■ ■ ■ ■ ■ ■ ■ Only Drain ■ ■ ■ ■ ■ ■ ■ ■ ■ Only Spin ■ ■ ■ ■ Stain ■ ■ ■ ■ Prewash ■ ■ ■ ■ ■ ■...
- Page 17 ENGLISH Universal Liquid Uni‐ Liquid for Delicates Programme Special versal coloureds woollens powder 20 min. - 3 kg ▲ ▲ ▲ ▲ Outdoor ▲ ▲ Duvet ▲ ▲ Jeans 1) At temperature higher than 60 °C the use of powder detergent is recommended. ▲...
- Page 18 • Activate the Rinse Hold option . can be changed. Option Time Save The water of the last rinse is not and Extra silent are not available. drained out to prevent the fabrics from creasing. The washing programme The corresponding indicator above the ends with water in the drum and the touch button illuminates.
- Page 19 ENGLISH • Skipping wash phase - Only Rinse If it is necessary to reduce the spin speed, option select a programme with The appliance performs only the a lower spin speed as rinsing phase, the spinning and the default. draining phases of the selected programme.
- Page 20 8.11 Start/Pause After touching the Start/Pause button, the display shows the indicator Touch the Start/Pause button to and the selected delay time and the start, pause the appliance or interrupt a appliance begins the countdown. running programme. 9. SETTINGS 9.1 Acoustic signals...
- Page 21 ENGLISH 11. DAILY USE 11.3 Detergent WARNING! compartments. Using Refer to Safety chapters. detergent and additives 11.1 Activating the appliance 1. Measure out specified detergents and the fabric conditioner. 1. Connect the mains plug to the mains socket. 2. Put the detergent and the fabric 2.
- Page 22 Detergent compartment for prewash phase. The marks MAX are the maximum levels of the quantity of detergent (powder or liquid). When you set a programme with a stain, add detergent (powder or liquid). Detergent compartment for washing phase. The marks MAX are the maximum levels of the quantity of detergent (powder or liquid).
- Page 23 ENGLISH The relevant indicator stops to flash and 2. Press button Delay Start stays on. repeatedly until the display shows . On the display the indicator of the phase is operation starts to flash. 3. Press button Start/Pause again The programme starts, the lid is locked. to start the programme immediately.
- Page 24 11.13 Opening the Lid when 1. The appliance detects the load in the the programme operates first 30 seconds: the indicator the time dots flash, the drum rotates CAUTION! shortly. If the temperature and level 2. At the end of the load detection, the...
- Page 25 ENGLISH When you activate the The appliance drains and appliance again, the display spins automatically after show the end of the last set approximately18 hours. programme. Turn the programme knob to set a 11.17 AUTO Stand-by option new cycle. The AUTO Stand-by function 2.
- Page 26 • Use only detergents and other open the door (refer to "Daily treatments specially made for Use" chapter); washing machines. First, follow these b. manually redistribute the load so generic rules: that the items are spaced evenly –...
- Page 27 ENGLISH • Loading the appliance to the laundry in a tumble dryer. This will maximum capacity indicated for save energy during drying! each programmes helps to reduce 12.5 Water hardness energy and water consumption. • With adequate pre-treatment, stains If the water hardness in your area is high and limited soiling can be removed;...
- Page 28 13.6 Lid seal CAUTION! Do not clean the metal Regularly examine the seal and remove surfaces with chlorine-based all objects from the inner part. Clean it detergent. when needed, using ammonia cream cleanser agent without scratching the 13.4 Descaling seal surface.
- Page 29 ENGLISH Always keep a rag nearby to dry up any WARNING! water spillages when removing the filter. • Disconnect the mains plug from the mains socket. • Do not remove the filter while the appliance operates. • Do not clean the pump if the water in the appliance is hot.
- Page 30 13.11 Emergency drain 1. Disconnect the mains plug from the mains socket. If the appliance cannot drain the water, 2. Close the water tap. carry out the same procedure, described 3. Put the two ends of the inlet hose in in 'Cleaning the drain pump' paragraph.
- Page 31 ENGLISH • Make sure that the sink spigot is not clogged. • Make sure that the drain hose has no kinks or bends. The appliance does • Make sure that the drain filter is not clogged. Clean the filter, if not drain the water.
- Page 32 Problem Possible solution • Make sure that the couplings of the water hoses are tight and there is not water leakages. There is water on the • Make sure that the water inlet hose and the drain hose have floor.
- Page 33 ENGLISH 15. CONSUMPTION VALUES 15.1 Introduction See the web link www.theenergylabel.eu for detailed information about Energy Label. The QR code on the energy label supplied with the appliance provides a web link to the information related to the performance of the appliance in the EU EPREL database.
- Page 34 Eco 40-60 pro‐ Litres h:mm °C gramme Quarter load 0.185 2:40 1151 1) Maximum spin speed. Power consumption in different modes Off (W) Stand-by (W) Delay start (W) 0.50 0.50 4.00 Time to Off/Standby mode is 15 minutes maximum.
- Page 35 ENGLISH 16. QUICK GUIDE 16.1 Daily use Connect the mains plug to the mains 2. Set the desired options (1) by means socket. of the corresponding touch buttons. To start the programme, touch the Open the water tap. Start/Pause (2) button. Load the laundry.
- Page 36 Programmes Load Product description Synthetics 3 kg Synthetic items or mixed fabric items. Delicates Delicate fabrics such as acrylics, viscose, pol‐ 2 kg yester items. Wool/Silk Machine washable wool, hand washable wool 1.5 kg and delicates. Steam Steam programme for cotton, synthetic and 1 kg delicate garments.
- Page 40 www.aeg.com/shop...
