RELION
PROTECTION AND CONTROL
GRID AUTOMATION REC615
Installation Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the RELION GRID AUTOMATION REC615 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ABB RELION GRID AUTOMATION REC615

Summary of Contents for ABB RELION GRID AUTOMATION REC615

  • Page 1 — ® RELION PROTECTION AND CONTROL GRID AUTOMATION REC615 Installation Manual...
  • Page 3 Document ID: 2NGA002471 Issued: 2025-05-09 Revision: A © Copyright 2025 ABB. All rights reserved...
  • Page 4 Copyright ABB is the owner of the copyright in this document. This document or any parts thereof must not be reproduced or copied without the written permission from ABB and the contents thereof must not be used to any unauthorized purpose.
  • Page 5 Other than under explicit contractual commitments, in no event shall ABB be responsible or liable for any loss or damage resulting from the use of this manual or the application of the equipment.
  • Page 6 Conformity This product complies with following directive and regulations. Directives of the European parliament and of the council: • Electromagnetic compatibility (EMC) Directive 2014/30/EU • Low-voltage Directive 2014/35/EU • RoHS Directive 2011/65/EU • RoHS Directive (EU) 2015/863 amending Annex II UK legislations: •...
  • Page 7 Safety information Dangerous voltages can occur on the connectors, even though the auxiliary voltage has been disconnected. Non-observance can result in death, personal injury or substantial property damage. Only a competent electrician is allowed to carry out the electrical installation. National and local electrical safety regulations must always be followed.
  • Page 8 Contents Contents Introduction..................... 10 This manual.............................10 Intended audience..........................10 Product documentation........................11 1.3.1 Product documentation set....................11 1.3.2 Document revision history....................11 1.3.3 Related documentation......................11 Symbols and conventions........................11 1.4.1 Symbols............................11 1.4.2 Document conventions......................12 Environmental aspects................14 Sustainable development........................14 Disposal of a device ..........................14 Unpacking, inspecting and storing............
  • Page 9 Contents 4.4.5 Rack mounting protection relay ..................37 4.4.6 Wall mounting protection relay...................41 4.4.7 Rack mounting protection relay and test switch RTXP into 19” equipment frame ..........................48 4.4.8 Rack mounting protection relay into combiflex 19" equipment frame (Type RHGT 19" 4U variant C) ....................50 4.4.9 Flush mounting the standard size relay with protection cover........
  • Page 10 Introduction 2NGA002471 A Introduction This manual The installation manual contains instructions on how to install the protection relay. The manual provides procedures for mechanical and electrical installation. The chapters are organized in the chronological order in which the relay should be installed.
  • Page 11 Figure 1: The intended use of documents during the product life cycle 1.3.2 Document revision history Document revision/date Product connectivity level History A/2025-05-09 PCL1 First release 1.3.3 Related documentation ABB Technical documentation Download the latest documents from the portal Symbols and conventions REC615 Installation Manual...
  • Page 12 Introduction 2NGA002471 A 1.4.1 Symbols The electrical warning icon indicates the presence of a hazard which could result in electrical shock. The warning icon indicates the presence of a hazard which could result in personal injury. The caution icon indicates important information or warning related to the concept discussed in the text.
  • Page 13 2NGA002471 A Introduction • Protective earthing is indicated in figures with the symbol REC615 Installation Manual...
  • Page 14 Environmental aspects 2NGA002471 A Environmental aspects Sustainable development Sustainability has been taken into account from the beginning of the product design including the pro-environmental manufacturing process, long life time, operation reliability and disposing of the device. The choice of materials and suppliers has been made according to the EU RoHS directive (2011/65/EU) and EU RoHS Directive (2015/863/EU).
  • Page 15 2NGA002471 A Unpacking, inspecting and storing Unpacking, inspecting and storing Removing transport packaging Protection relays require careful handling. Examine the delivered products to ensure that they have not been damaged during the transport. Remove the transport packaging carefully without force. Attach the protective film (supplied with the protection relay) on the top side of the unit for the installation phase.
  • Page 16 Returning a product damaged in transportation If damage has occurred during transportation, appropriate actions must be taken against the latest carrier. Inform the nearest ABB office or representative. ABB should be notified immediately if there are any discrepancies in relation to the delivery documents. Storing If the protection relay is stored before installation, it must be done in the original transport packaging in a dry and dust free place.
  • Page 17 2NGA002471 A Mounting Mounting Housing REC615 is available with two different housings sizes, standard and wide. The wide version offers more module slots for binary I/O, RTD/mA and analogue inputs compared to standard version. Otherwise, the mechanical construction is the same in both versions.
  • Page 18 Mounting 2NGA002471 A Figure 4: REC615 wide Checking environmental conditions and mounting space The mechanical and electrical environmental conditions at the installation site must be within the limits described in the technical manual. • Avoid installation in dusty or damp places. •...
  • Page 19 2NGA002471 A Mounting It is not allowed to push or touch the screen during the plug-in unit handling. Figure 5: An area that is not allowed to be pushed or touched during the plug-in unit handling Figure 6: Example of hand positions when handling the plug-in unit Detaching and installing plug-in unit REC615 Installation Manual...
  • Page 20 Mounting 2NGA002471 A 4.3.1 Detaching plug-in unit Before detaching the plug-in unit from the case, the auxiliary voltage must be disconnected. Turn off the power. Open the seal on the front panel by removing the sealing wire and screw the sealing screw all the way in.
  • Page 21 2NGA002471 A Mounting 4.3.2 Installing plug-in unit The protection relay is constructed in a way that a plug-in unit with voltage- or current-measuring inputs can only be plugged into a corresponding case. This prevents fitting an unsuitable plug-in unit into a wrong case. Before fitting the plug-in unit into the case, check that the unit and the case have the same serial number.
  • Page 22 Mounting 2NGA002471 A Lift the handle 90 degrees and push the plug-in unit into the case. Figure 9: Installing a plug-in unit into the case Let the handle swing down about 45 degrees. At the same time, push the plug-in unit into the case as far as it goes. Plug-in unit stops at about 7 mm (0.28 in) distance from the case.
  • Page 23 2NGA002471 A Mounting Turn down the handle to push the plug-in unit into its final position in the case. The handle must be locked or sealed to secure the mechanical performance under any conditions caused by vibration, pressure, shock or bump, seismic activity or other equivalent circumstances. REC615 Installation Manual...
  • Page 24 Mounting 2NGA002471 A 4.3.3 Sealing handle The front panel of the protection relay has an integrated sealing screw. By default the screw is screwed all the way in and is not used when installing or detaching the plug-in unit. Open the sealing screw about nine turns. Thread a sealing wire through the holes in the sealing screw and the handle.
  • Page 25 2NGA002471 A Mounting 4.3.4 Securing handle The front panel of the protection relay has an integrated sealing screw. By default, the screw is screwed all the way in and not used when installing or detaching the plug-in unit. Instead of sealing the plug-in unit, the sealing screw and the spacer supplied with the protection relay can be used for securing the handle in place.
  • Page 26 Mounting 2NGA002471 A 4.4.1 Required tools • T25 Torx screwdriver for mounting the case • T20 Torx screwdriver for connecting the protective earthing Only use adjustable torque screwdrivers. 4.4.2 Flush mounting protection relay All the mounting elements are integrated in the protection relay. Requirements for installation: •...
  • Page 27 2NGA002471 A Mounting Mount the case to the panel cut-out. 165.5 ±1 mm (6.52 inches) M5 fixing screws 161.5 ±1 mm (6.36 inches) Figure 13: Flush mounting a standard case into a panel cut-out REC615 Installation Manual...
  • Page 28 Mounting 2NGA002471 A 248 ±1 mm (9.76 inches) 162 ±1 mm (6.38 inches) Figure 14: Flush mounting a wide case into a panel cut-out REC615 Installation Manual...
  • Page 29 2NGA002471 A Mounting Tighten the M5 (T25) screws. The allowed range for the fixing screws’ tightening torque is 0.7...1 Nm (0.52...0.74 foot-pounds). Figure 15: Flush mounted case, tightening the M5 fixing screws Install the plug-in unit into the case. There is a protective film on the top side of the protection relay. Its purpose is to prevent debris falling inside the unit while installing electrical wiring.
  • Page 30 Mounting 2NGA002471 A 177 mm (6.97 inches) 153 mm (6.02 inches) 177 mm (6.97 inches) 48 mm (1.89 inches) 164 mm (6.46 inches) 160 mm (6.30 inches) 201 mm (7.91 inches) Figure 16: Flush mounted standard case and plug-in unit REC615 Installation Manual...
  • Page 31 2NGA002471 A Mounting 262 mm (10.31 inches) 153 mm (6.02 inches) 177 mm (6.97 inches) 48 mm (1.89 inches) 246 mm (9.69 inches) 160 mm (6.30 inches) 201 mm (7.91 inches) Figure 17: Flush mounted wide case and plug-in unit 4.4.3 Semi-flush mounting protection relay A mounting kit is needed for semi-flush mounting the protection relay.
  • Page 32 Mounting 2NGA002471 A Mount the raising frame into the panel cut-out with four screws. 173.5 ±0.3 mm (6.83 inches) ∅ 5.5 mm (0.22 inches) 165.5 ±1 mm (6.52 inches) Panel 161.5 ±1 mm (6.36 inches) Raising frame 133 ±0.3 mm (5.24 inches) M4 screw Figure 18: Mounting the standard size raising frame 263 ±0.5 mm (10.35 inches)
  • Page 33 2NGA002471 A Mounting Mount the case to the raising frame. Figure 20: Mounting the case Tighten the M5 screws. The allowed range for the fixing screws’ tightening torque is 0.7...1 Nm (0.52...0.74 foot-pounds). Attach the protective film back on the top side of the case. Install the plug-in unit into the case.
  • Page 34 Mounting 2NGA002471 A 280 mm (11.02 inches) 103 mm (4.06 inches) 177 mm (6.97 inches) 98 mm (3.86 inches) 201 mm (7.91 inches) 160 mm (6.30 inches) Figure 22: Semi-flush mounted wide size relay REC615 Installation Manual...
  • Page 35 2NGA002471 A Mounting 4.4.4 Semi-flush mounting protection relay inclined A mounting kit is needed for semi-flush mounting the protection relay inclined. In addition to the detailed mounting instructions, the mounting kit includes: • Angle frame • Gasket • Screws Requirements for installation •...
  • Page 36 Mounting 2NGA002471 A Mount the angle frame into the panel cut-out with four M4 screws. 177 ±0.3 mm (6.97 inches) 122 mm ±0.3 mm(4.80 inches) 167 ±1 mm (6.57 inches) 40.5 mm (1.59 inches) 203 ±1 mm (7.99 inches) ø 5.5 mm (0.22 inches) 40.5 mm (1.59 inches) 190 mm (7.48 inches) Figure 23: Mounting the standard size angled frame...
  • Page 37 2NGA002471 A Mounting 25° 190 mm (7.48 inches) 221 mm (8.70 inches) M4 screws 9 mm (0.35 inches) Gasket 107 mm (4.21 inches) Angled frame 133 mm (5.24 inches) Case 230 mm (9.06 inches) Plug-in unit Figure 25: Standard size relay semi-flush mounted inclined 25 °...
  • Page 38 Mounting 2NGA002471 A 4.4.5 Rack mounting protection relay A mounting kit is needed for rack mounting the protection relay. In addition to the detailed mounting instructions, the 19" rack mounting kit includes: • Mounting panel; the type of the mounting panel depends on the number of mounted devices •...
  • Page 39 2NGA002471 A Mounting Mount the case to the panel cut-out. 482.6 mm (19") 177 mm (6.96 inches) (4U) Figure 27: 19" rack mounting panels for standard size relay REC615 Installation Manual...
  • Page 40 Mounting 2NGA002471 A 482.6 mm (19") 177 mm (6.96 inches) (4U) Figure 28: 19" rack mounting panel for wide size relay Tighten the screws. The allowed range for the fixing screws’ tightening torque is 0.7...1 Nm (0.52...0.74 foot-pounds). Install the plug-in unit into the case. Seal or secure the handle.
  • Page 41 2NGA002471 A Mounting Figure 29: Rack mounted protection relay 4.4.6 Wall mounting protection relay 4.4.6.1 Wall mounting standard size relay A mounting kit is needed for wall mounting the protection relay. In addition to the detailed mounting instructions, the wall mounting kit includes: •...
  • Page 42 Mounting 2NGA002471 A 149 mm (5.87 inches) Back plate 156 mm (6.14 inches) Side part Ø 6 mm (0.24 inches) Screws M4x6 Mounting screws M5x12 and nuts Case Plug-in unit Rail Figure 30: Wall-mounting kit for standard size relay Open M4x6 screws and remove the side parts from the rails. Drill screw holes according to the dimensional drawing.
  • Page 43 2NGA002471 A Mounting 430 mm (16.93 inches) Figure 31: Wall mounting the protection relay 214 mm (8.43 inches) 270 mm (10.63 inches) 177 mm (6.97 inches) Figure 32: Wall mounted protection relay REC615 Installation Manual...
  • Page 44 Mounting 2NGA002471 A Minimum of 50 mm (1.97 inches) space is needed between two kits side by side. When connecting the wires, a wall-mounted protection relay can be pulled out and turned 45° (or 90°) degrees downwards or upwards. • To release the protection relay for pulling it out, push the locks beside the mounting frame.
  • Page 45 2NGA002471 A Mounting 293 mm (11.54 inches) Side part (2 pieces) ∅ 7.5 mm (0.30 inches) Hexagon socket head cap screw 66.5 mm (2.62 inches) M5x8 (4 pieces) 133 mm (5.24 inches) Wall mounting screws (not 66.5 mm (2.61 inches) included) Front part Torx screw M5x10 (4 pieces)
  • Page 46 Mounting 2NGA002471 A Detach the plug-in unit from the case and mount the case to the front part by tightening the integrated mounting screws 0.7...1.0 Nm (0.52...0.74 foot-pounds). Figure 35: Mounting the case REC615 Installation Manual...
  • Page 47 2NGA002471 A Mounting The frame can be swung out to access terminals for wiring. Remove the screws as seen to swing out the frame. 57 mm (2.24 inches) Remove the screws before 503 mm (19.80 inches) swinging out the frame Figure 36: Swing mechanism After finished wiring, turn the frame to the wall again and insert all removed screws.
  • Page 48 Mounting 2NGA002471 A 259 mm (10.20 inches) 186 mm (7.32 inches) 318 mm (12.52 inches) Figure 37: Wall-mounted protection relay Leave enough slack to wires and cables to allow installation movement. 4.4.7 Rack mounting protection relay and test switch RTXP into 19”...
  • Page 49 2NGA002471 A Mounting Figure 38: Mounting of the metallic frame for an RTXP 18 test switch Figure 39: Protection relay and the test switch RTXP 18 mounted into a 19" equipment panel REC615 Installation Manual...
  • Page 50 Mounting 2NGA002471 A Figure 40: Mounting of the metallic frame for an RTXP 24 test switch Figure 41: Protection relay and the test switch RTXP 24 mounted into a 19" equipment panel REC615 Installation Manual...
  • Page 51 2NGA002471 A Mounting 4.4.8 Rack mounting protection relay into combiflex 19" equipment frame (Type RHGT 19" 4U variant C) A mounting bracket is needed for rack mounting the protection relay into a combiflex 19" equipment frame, a different bracket is in installation with test switch.
  • Page 52 Mounting 2NGA002471 A Install the plug-in unit into the case. RHGT 19" 4U equipment frame, Mounting bracket variant C, with support frame Tapping screw ST3.5x13 Figure 42: Mounting the standard size relay into a 19" combiflex equipment frame REC615 Installation Manual...
  • Page 53 2NGA002471 A Mounting RHGT 19" 4U equipment frame, Washer variant C, with support frame Mounting bracket Screw M4x10 Figure 43: Mounting the wide size relay into a 19" combiflex equipment frame Seal or secure the handle. REC615 Installation Manual...
  • Page 54 Mounting 2NGA002471 A Install the optional RTXP 18 or 24 test switch. RHGT 19" 4U equipment frame, Mounting bracket for mounting variant C, with support frame with test switch RTXP 18 Tapping screw ST3.5x13 Figure 44: Protection relay and the test switch REC615 Installation Manual...
  • Page 55 2NGA002471 A Mounting Test switch RTXP 24 Figure 45: Protection relay and the test switch RTXP 24 4.4.9 Flush mounting the standard size relay with protection cover A mounting kit is needed for flush mounting the protection relay with a protection cover.
  • Page 56 Mounting 2NGA002471 A Mount the protection cover from the rear. Protection cover Figure 46: Mounting the protection cover Tighten the M5 (T25) screws. The allowed fixing screws’ tightening torque is 0.52...0.74 foot- pounds (0.7...1 Nm). Install the plug-in unit into the case. There is a protective film on the top side of the protection relay.
  • Page 57 2NGA002471 A Mounting 6.97 inches (177 mm) 6.69 inches (170 mm) 6.97 inches (177 mm) 1.89 inches (48 mm) 7.91 inches (201 mm) 7.48 inches (190 mm) 8.70 inches (221 mm) Figure 47: Flush mounted case and a plug-in unit with the protection cover 4.4.10 Flush mounting the wide size relay with protection cover A mounting kit is needed for flush mounting the IED with a protection cover.
  • Page 58 Mounting 2NGA002471 A Mount the protection cover from the rear. Protection cover Figure 48: Mounting the protection cover Tighten the M5 (T25) screws. The allowed fixing screws’ tightening torque is 0.7...1 Nm (0.52...0.74 foot-pounds). Install the plug-in unit into the case. There is a protective film on the top side of the IED.
  • Page 59 2NGA002471 A Mounting 10.32 inches (262.2 mm) 6.69 inches (170 mm) 6.97 inches (177 mm) 1.89 inches (48 mm) 11.58 inches (294.1 mm) 7.48 inches (190 mm) 8.70 inches (221 mm) Figure 49: Flush mounted case and a plug-in unit with the protection cover REC615 Installation Manual...
  • Page 60 Connecting 2NGA002471 A Connecting Required tools Only use a screwdriver and insert bits for Phillips (PH 1) cross-recessed head screws (M3.5) when handling CT/ VT terminals of screw-compression type. Max. ø5.5 mm (0.22 inches) Max. ø5 mm (0.20 inches) Figure 50: Screwdriver for CT/VT terminals of screw-compression type Min.
  • Page 61 2NGA002471 A Connecting Connecting protective earthing The earth lead must be at least 6.0 mm (AWG 10). If the earth lead is long, the cross section of the wire must be increased. Use fine copper wire as the earth lead. Loosen the protective earth screw (T20) to connect a separate earth protection lead.
  • Page 62 Connecting 2NGA002471 A Support the earth lead so that it cannot break or weaken. Be aware of the mechanical, chemical and electrochemical environment. Connecting analog signals A connection diagram is needed to connect the analog signals. When using the ring-lug type for CT/VT terminals, follow these steps. Open or remove the lid that covers the ring-lug fixing screw with the tip of a screwdriver.
  • Page 63 2NGA002471 A Connecting Figure 53: Example of AIM3 card variant (5 U, 2 RTD + 1 mA channel) REC615 Installation Manual...
  • Page 64 Connecting 2NGA002471 A Figure 54: Example of AIM5 card variant (7I with 1/5A Io channel) REC615 Installation Manual...
  • Page 65 2NGA002471 A Connecting Figure 55: Example of AIM6 card variant (5 U) REC615 Installation Manual...
  • Page 66 Connecting 2NGA002471 A Figure 56: Example of AIM7 card variant (3 BI+ 6 U) REC615 Installation Manual...
  • Page 67 2NGA002471 A Connecting Figure 57: Example of AIM13 card variant (4 I + 3 U with 0.2/1 A Io channel) REC615 Installation Manual...
  • Page 68 Connecting 2NGA002471 A Figure 58: Example of AIM17 card variant (4I with 0.2/1 A Io channel) REC615 Installation Manual...
  • Page 69 2NGA002471 A Connecting 5.4.2 Connecting sensors (non-conventional instrument transformers) Current measurement is based on Rogowski coil and voltage measurement is based on voltage divider. Both current and voltage measurements interface the relay via one RJ45 connector per phase. REC615 has one type of sensor input module (SIM0005) available which supports IEC 61869 standard.
  • Page 70 Connecting 2NGA002471 A Figure 59: Example of SIM1 card variant (6U) REC615 Installation Manual...
  • Page 71 2NGA002471 A Connecting Figure 60: Example of SIM4 card variant (3I + 6U) REC615 Installation Manual...
  • Page 72 Connecting 2NGA002471 A Figure 61: Example of SIM5 card variant (4I+3U with 0.2/1 A Io channel). Including red sensor connectors. REC615 Installation Manual...
  • Page 73 2NGA002471 A Connecting 5.4.3 Connecting RTD and mA inputs • Connect the wires from the transducers to the correct device according to the connection diagram. Each terminal for RTDs and mA inputs is dimensioned for one 0.5...2.5 mm (AWG 20...14) wire or for two 0.5...1.0 mm (AWG 20...17) wires.
  • Page 74 Connecting 2NGA002471 A Connecting binary signals • Connect the wires for the binary signals to the correct device according to the connection diagram. Each terminal for binary input and output signal is dimensioned for one 0.5...2.5 mm (AWG 20...14) wire or for two 0.5...1.0 mm (AWG 20...17) wires.
  • Page 75 2NGA002471 A Connecting Figure 64: Example of BIO0006 card variant (6 BI + 3 BO) REC615 Installation Manual...
  • Page 76 Connecting 2NGA002471 A BIO0007 X110 BI 1 BI 2 BI 3 BI 4 BI 5 BI 6 BI 7 BI 8 N.C. N.C. N.C. N.C. HSO1 N.C. N.C. HSO2 N.C. N.C. HSO3 Figure 65: Example of BIO0007 card variant (8 BI + 3 BO) REC615 Installation Manual...
  • Page 77 2NGA002471 A Connecting Connecting power supply The permitted auxiliary voltage range of the protection relay is marked on top of the protection relay's LHMI. • Connect the protection relay's auxiliary voltage to terminals X100-1 and X100-2. • Connect the positive lead to terminal X100-1. Figure 66: Connecting auxiliary voltage Connecting communication •...
  • Page 78 During the start-up, indications and self test procedures are shown in a certain order. Green Ready LED starts to flash. LCD lights up and ABB logo is displayed. LCD test patterns are displayed and all the LEDs are lit for a short period.
  • Page 79 Protection relay specific options can be found in Retrofit Solutions Database on the www.abb.com Internet by following the links within ABB Service Guide or via ABB Product Guide from the product-specific Service & Support sheet. Checking protection relay information The protection relay information includes detailed information about the device, such as version and serial number.
  • Page 80 Figure 68: Loosening the M5 screws Detach the case from the panel cut-out. Sending protection relay for repair • In case of product problems, contact the nearest ABB office or representative for consultation and instructions. Exchanging protection relay • To exchange the protection relay with another identical unit, remove the protection relay and install the new one.
  • Page 81 2NGA002471 A Removing, repairing and exchanging • To exchange a protection relay to a different unit, change the case and connect the wires. • When replacing only the plug-in unit for maximum system availability, check that the order code of the case and the spare plug-in unit are equal to ensure the type compatibility.
  • Page 82 Technical data 2NGA002471 A Technical data Case and LHMI display variants 7.1.1 Front side of the protection relay Figure 69: Standard size LHMI (IEC/ANSI variant) REC615 Installation Manual...
  • Page 83 2NGA002471 A Technical data Figure 70: Standard size LHMI (CN variant) Figure 71: Wide size LHMI (IEC/ANSI variant) REC615 Installation Manual...
  • Page 84 Technical data 2NGA002471 A Figure 72: Wide size LHMI (CN variant) Table 1: Display characters Character size Rows in the view Characters per row Small, mono-spaced (6 × 12 pixels) Large, variable width (13 × 14 pixels) 8 or more Depending on the selected language REC615 Installation Manual...
  • Page 85 2NGA002471 A Technical data 7.1.2 Rear side of the protection relay Figure 73: Rear view of a REC615 standard series protection relay with communication module Figure 74: Rear view of REC615 wide with one wide analog input module (X120) REC615 Installation Manual...
  • Page 86 Technical data 2NGA002471 A Figure 75: Rear view of REC615 wide with two wide analog input modules (X120 and X115) Dimensions REC615 Installation Manual...
  • Page 87 2NGA002471 A Technical data 177 mm (6.97 inches) 153 mm (6.02 inches) 177 mm (6.97 inches), 4U 48 mm (1.89 inches) 164 mm (6.46 inches) 160 mm (6.30 inches) 201 mm (7.91 inches) Figure 76: Standard size relay's main dimensions REC615 Installation Manual...
  • Page 88 Technical data 2NGA002471 A 262 mm (10.31 inches) 153 mm (6.02 inches) 177 mm (6.97 inches), 4U 48 mm (1.89 inches) 246 mm (9.69 inches) 160 mm (6.30 inches) 201 mm (7.91 inches) Figure 77: Wide size relay's main dimensions Table 2: Dimensions Description Value...
  • Page 89 2NGA002471 A Technical data Degree of protection of the protection relay Table 3: Degree of protection of the protection relay Description Value Front: When flush mounted IP 54 Rear (Connector side): IP 20 (with ring-lug signal connectors IP 00 or IP 10 depending on wiring) Top and bottom: IP 30...
  • Page 90 Accessories and ordering data 2NGA002471 A Accessories and ordering data Table 4: Mounting accessories for standard size relay Item Order number Semi-flush mounting kit 1MRS050696 Inclined semi-flush mounting kit 1MRS050831 19” rack mounting kit with cut-out for one relay 1MRS050694 19”...
  • Page 91 2NGA002471 A Glossary Glossary Analog input module BI/O Binary input/output Binary input and output Current transformer Electromagnetic compatibility Hardware International Electrotechnical Commission Liquid crystal display Liquid crystal polymer Light-emitting diode LHMI Local human-machine interface Polyamide Polybutylene terephthalate 1. Personal computer 2.
