Summary of Contents for IDS Plugin GSM
- Page 1 Plugin GSM Modem INSTALLATION & OPERATION MANUAL...
-
Page 2: Getting Started
GETTING STARTED 1. Connect the IDS Plugin to the Alarm Panel See the appropriate section for the Alarm Panel on the next page 2. Help with installing the ArmME app on a customer's mobile device Refer to the ArmME Installation Guide... -
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ............4 2. THE ArmME APP ............5 3. IDS X-SERIES PANEL SET UP ......... 6 4. IDS 806 PANEL SET UP ..........9 APPENDIX A FEATURES & FUNCTIONS ..........11... -
Page 4: Introduction
Wi-Fi network. The GSM network will then become secondary means communication in case of Wi-Fi connectivity issues. The IDS Plugin GSM Modem Wi-Fi has a serial interface to all IDS Alarm panels. IDS Plugin GSM Modem Wi-Fi Installation and Operational Manual... -
Page 5: The Armme App
2. THE ArmME APP Please note the following: 1. The IDS Plugin GSM Modem Wi-Fi can only be set up to connect to a Wi-Fi network via the ArmME app. 2. Make sure the IDS Plugin GSM Modem Wi-Fi is connected to the GSM network before setting up the Wi-Fi network connection. -
Page 6: Ids X-Series Panel Set Up
3. IDS X-SERIES PANEL SET UP 3.1 CONNECTING THE IDS PLUGIN GSM MODEM WI-FI TO THE PANEL N.B. Make sure the firmware on the IDS X-Series panel has been upgraded to V2.50 or later. 1. Plug the unit into the... - Page 7 [*] to go into the Installer Menu. communication format pressing [5] and then [*] to save 2. Enter [196] followed by [*]. Enter the serial code: 003456 and press [*] to save. IDS Plugin GSM Modem Wi-Fi Installation and Operational Manual...
- Page 8 2, enter location [212], [*] to save, etc. set option [16] to yes (Y) by pressing [*] to save, etc. . IDS Plugin GSM Modem Wi-Fi Installation and Operational Manual...
-
Page 9: Ids 806 Panel Set Up
2. On the IDS806 alarm panels with 1.1x firmware version range, the ArmME app is compatible with panel firmware version 1.12 or later. 682-01B 682-01B 1. Plug the unit into the expansion connectors on the IDS Panel as shown. IDS Plugin GSM Modem Wi-Fi Installation and Operational Manual... - Page 10 Modem 4.2 PANEL PROGRAMMING FOR APP CONNECTION VERY IMPORTANT: DO NOT install the IDS Plugin GSM Modem Wi-Fi unit to the alarm panel before or in the middle of panel programming as new programming settings will NOT be saved by the panel. Make sure the Plugin is installed AFTER programming of the panel has been concluded.
-
Page 11: Features & Functions
• Full programming and software updating via a computer serial port • Programming over-the-air Indicators and Controls • Status LEDS GSM Status Green - Connected Wi-Fi Status Blue - Connected Power Status Green - Power OK IDS Plugin GSM Modem Wi-Fi Installation and Operational Manual... -
Page 12: Limited Warranty
In no case shall seller be liable to anyone for any consequential or incidental damages for breach of this or any other warranty, express or implied, or upon any other basis of liability IDS Plugin GSM Modem Wi-Fi Installation and Operational Manual... - Page 13 No increase or alteration, written or verbal, of the obligations of this limited warranty is authorised. Note: Specifications are subject to change without notice. Patents issued and pending worldwide. IDS Plugin GSM ModemWi-Fi Installation and Operational Manual...
- Page 14 sales@amecor.com support@amecor.com www.fsk.co.za www.armme.app +27 11 477 2600 +27 11 477 7705 (technical support) +27 82 657 7852 (emergency contact) Amecor House, 14 Richard Road, Industria North, 1709...
