Belleze Lawson Manual

Lift top coffee table
Hide thumbs

Advertisement

Table of Contents

Lawson Lift Top Coffee Table
FOLLOW US:
@bellezefurniture
CONTACT INFO:
support@belleze.com
1-800-682-6376
www.belleze.com
ITEM NO. 014-HG-44307
The instruction booklet contains IMPORTANT
safety information. Please read it in full and
keep it for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lawson and is the answer not in the manual?

Questions and answers

Related Manuals for Belleze Lawson

Summary of Contents for Belleze Lawson

  • Page 1 Lawson Lift Top Coffee Table FOLLOW US: CONTACT INFO: ITEM NO. 014-HG-44307 The instruction booklet contains IMPORTANT support@belleze.com @bellezefurniture safety information. Please read it in full and 1-800-682-6376 keep it for future reference. www.belleze.com...
  • Page 2 Scan this QR Code to view our online tutorial Estimated time for assembly: 90 mins Weight limitations are as follows: Maximum Load 120 lb Maximum Load 90 lb Maximum Load 20 lb Maximum Load 70 lb Maximum Load 50 lb...
  • Page 3 Assemble the furniture on an empty carton, carpet, or rug to prevent scratches or damage. For safety, please keep pets and children away from the assembly area. Ensure the product is fully assembled before use. If you are missing any hardware or products, do not use it until you have restored the missing parts.

  • Page 4: Package Contents

    PACKAGE CONTENTS...
  • Page 5 PACKAGE CONTENTS CODE DESCRIPTION Table Top Panel Table Top Panel Small Top Panel Left Lateral Panel Right Lateral Panel Back Panel Bottom Left Medial panel Bottom Right Medial Panel Middle Panel Top Left Medial Panel Top Right Medial Panel Front Panel Storage Panel Bottom Panel Left Door Panel...
  • Page 6 PACKAGE CONTENTS 28x + 2x 28x + 2x 44x + 4x 28x + 2x 11x + 1x Install all hardware perpendicular to the opening.
  • Page 7 PACKAGE CONTENTS 12x+1x 12x+1x 18x+1x Install all hardware perpendicular to the opening. v.03132024...
  • Page 8 Required tools for assembly (Not included) Attach cam bolts to both sides of the middle panel (9). Turn 180°...
  • Page 9 Insert wood dowels to the middle panel (9), top left and top right medial panels (10, 11). Assemble the top left and top right medial panels (10, 11) to the middle panel (9). v.03132024...
  • Page 10 Attach cam bolts to the back panel (6) and the front panel (12). Insert wood dowels to the back panel (6) and the front panel (12).
  • Page 11 Attach sliding door rail to the front panel (12). Note the direction of the sliding door rail. Assemble the front panel (12) to the middle panel (9). v.03132024...
  • Page 12 Assemble the back panel (6) to the other side of the middle panel (9). Attach cam bolts to the left and right lateral panels (4, 5).
  • Page 13 Insert wood dowels to the lateral panels (4, 5) and bottom medial panels (7, 8). Assemble the lateral panels (4, 5) to the sides of the middle panel (9). v.03132024...
  • Page 14 Assemble bottom left and right medial panels (7, 8) to the middle panel (9). Assemble the bottom panel (14) to the table assembly.
  • Page 15 Attach legs (15) to the bottom panel (14). Attach protection pads to the legs. v.03132024...
  • Page 16 Insert shelf pegs into the table and put the storage panel (13) onto the pegs. Attach the rollers to the sliding doors (16, 17).
  • Page 17 Attach slide guide to the door panels (16, 17). Attach slide stopper to the door panels (16, 17). v.03132024...
  • Page 18 Insert the slide guide into the groove on the bottom panel and hang the sliding doors on the sliding rail.
  • Page 19 Unfold the table top folding lift up kit. Note:Unhook the locking hook. WARNING: Beware of nip injury. v.03132024...
  • Page 20 Attach the folding lift up kit to the table top panel (2) and small top panel (3). Pay attention to the position of the lock hook during installation. Make sure the lock hook is in this position. Elevate the panel(3) with a mat.
  • Page 21 Carefully slide the folding lift up kit with the table top into the table. v.03132024...
  • Page 22 Secure the folding lift up kit to the top left/right medial panel (10, 11).
  • Page 23 Connect table tops (1, 2) with folding hinges. YOU’RE FINISHED! v.03132024...

  • Page 24: User Instruction

    USER INSTRUCTION WARNING: DO NOT put hands close to the structure when lifting or lowering the desktop. Unhook the locking hook and fold down the table top.
  • Page 25 USER INSTRUCTION WARNING: DO NOT put hands close to the structure when lifting or lowering the desktop. Note: The top panel only be lifted from one direction. Pull up the table top and turn the locking hook to the lock position. v.03132024...
  • Page 26 USER INSTRUCTION WARNING: DO NOT put hands close to the structure when lifting or lowering the desktop. Un-fold the table top to use the full table size.
  • Page 27 USER INSTRUCTION When moving the table, lift the table from the bottom. Do not try to move the table by holding the table top. v.03132024...
  • Page 28 Warning Only place items on top of the product if they meet the recommended size and weight limits. Climbing on, stepping on, or placing overweighted objects on the product may cause property damage and/or injuries. Items placed onto this product must be resting on a support surface without hanging over the edges.
  • Page 29 FURNITURE CARE AND MAINTENANCE Medium - Density Fiberboard Thank you for your purchase. We want your item to last as long as possible. To ensure the product gives you years of longevity, please follow the recommendations in this care and maintenance guide. MAINTENANCE •...
  • Page 31 © All copyright of this document belongs to BELLEZE. This document may not be printed, translated, reproduced, or distributed in whole or in part without written permission from BELLEZE. v.03132024...

  • Page 32: Warranty

    WARRANTY BELLEZE products come with a 1-year warranty from the date of delivery. Register your product on our website to enjoy our limited lifetime warranty! AFTER-SALE SERVICE Encounter any difficulties or missing parts? Contact us at 1-800-682-6376 or email us at support@belleze.com We will send you replacement.
