WB700
WHEEL BALANCER
ORIGINAL USER'S MANUAL
Version:
1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO WB700 and is the answer not in the manual?

Questions and answers

Related Manuals for Nortec PRO WB700

Summary of Contents for Nortec PRO WB700

  • Page 1 ORIGINAL USER'S MANUAL Version: Nortec Sp. z o. o., Świerkowa 32, 62-020 Rabowice, Infolinia: 61 307 70 05, e-mail: biuro@nortec-pro.com, www.nortec-pro.com The user manual is an integral part of the product and must be stored together with the device in an easily accessible place.
  • Page 2 Warning This manual is a necessary part of the product. Please read carefully.  Keep the manual for later use when maintaining the machine.  This machine can only be used for the designated purposes. Never use it for any other purpose. ...

  • Page 3: Table Of Contents

    Contents 1. General---------------------------------------------------------------------------------------------------------------1 2. Machine assembly--------------------------------------------------------------------------------------------------1 3. Controls and components------------------------------------------------------------------------------------------3 4. Indication and use of wheel balancer-----------------------------------------------------------------------------5 5.Self-diagnoses/Setting machine/Self-calibration----------------------------------------------------------------12 6. Errors-----------------------------------------------------------------------------------------------------------------14 7. OPT function --------------------------------------------------------------------------------------------------------19 8. Spare parts list and Exploded drawings -------------------------------------------------------------------------17...

  • Page 4: General

    1. General 1.1. Technical data： Max wheel weight：70kg  Power：0.2kw;0.37kw  Power supply: 220v;230v;240v;110v;50hz;60hz  ± Balancing accuracy：  10balancing modes: DYN, ALU1, ALU2, ALU 3，ALU 4，ALU5，ALU-S1, ALU-S2, Moto-1,  Moto-2 Balancing speed：200r/min  Cycle time：8s  Rim diameter：10〃～24〃(256mm～610mm)  Sound pressure level during work cycle：<70db ...
  • Page 5 2.2. Install The equipment should be installed on the stable ground, not wooden pallet, otherwise not accurate.  Keep the back panel 0.6M away from the wall for good ventilation. Enough room should be left on both  sides for convenient operation. 2.3.

  • Page 6: Controls And Components

    Main shaft-wheel— Main shaft-suitable cone(big head towards inside) suitable cone( small head towards inside)—quick handle nut —wheel—quick handle nut Attention：May add a wheel, and hold the wheel to help install the thread hub. When installing or taking off wheel, do not let wheel move on the shaft, to avoid scratching shaft. 3．Controls and components Standard/Optio Item...
  • Page 7 Screen (G) 1. Inside amount of unbalance 2. Outside amount of unbalance 3. Balancing mode 4. Operating unit 5. Inside unbalance position indicator 6. Outside unbalance position indicator 7. Illustrated unbalance position 8. Function buttons to choose Eight balancing modes Balanci Icon Operation...
  • Page 8 1.Turn on machine Add adhesive weight on 2.Input a,b,d value inside rim shoulder, clip ALU5 o’clock o’clock on weight on outside 3.Press 【 】 button, indicator lit up ◀ 4.Start spin, after spin stop rim edge 1. Turn on machine Add adhesive weights ALUS-1 2.

  • Page 9: Indication And Use Of Wheel Balancer

    Data key/menu Choose/ Search for 4. Indication and use of confirmation location Selection of “ALU” wheel balancer Right click modes / Left click 4.1．DYN (Standard/Default) mode Start Stop/Cancel/ brake 4.1.1. Clean wheel, take off counterweights, check pressure of wheel.Choose the way of installation according to the type of wheel.
  • Page 10 Fig.1 Fig.2 a Fig.2 b 4.1.4. Put down the guard and press to perform a measuring spin. 4.1.5.In a few seconds the wheel is brought to operating speed and begin measuring unbalance, the unbalance values remain on instruments 1 and 3 when the wheel stopped. Press , select , and then press may check the real...
  • Page 11 Fig. 5 4.2． ALU-1 mode (ALU-1, ALU2, ALU 3， ALU 4， ALU5, same operation, only the position to add weights different) 4.2.1. Set “a” “d” “b” values 4.2.2. Press until ALU1 indicator lit up 4.2.3. Put down the guard and press to perform a measuring spin.
  • Page 12 Fig. 8 4.3．ALU－S1 mode This mode is used for special rim, if ALU1/ALU2 can not be used, you should choose ALUS mode. Input aI, aE, d value Set “aI”: pull gauge out let the gauge head touch the position of FI for 4 seconds, may press ...
  • Page 13 Fig. 10 Fig. 11 After finishing mounting the counterweights, put down the guard and press ，to perform balancing spin again, if comes out 00 00，means balancing succeed. (Fig.12) Fig. 12 4.4. ALU-S1 split function Note: Only ALU-S mode can use this function. And Operator must be experienced. When the result is displayed in ALU-S mode, press the key, select , and then press...
  • Page 14 Keep the next spock( either direction is ok) on the position of 12 o’clock, press Press key until the outer imbalance SP1 indicator light is fully on Press key until the outer imbalance SP2 indicator light is fully on Press key until the imbalance indicator light on the inside side is fully lit Put down safe guard and press...
  • Page 15 for selection, exit 5.1Self diagnosis press Press Order Function Function normal Position pick up board POS changes in 0-127 Pressure sensor Use hand to press main shaft, 4X-4X 6X-6X changes Pressure sensor Use hand to press main shaft, 4X-4X 6X-6X changes Width potentiometer turn ruler to another direction, data changes left window data is 327-340,...
  • Page 16 Distance potentiometer Left window data is 327-340, when pull gauge out, the data changes 5.2 instructions press Press 5.3 Video press Press 5.4 Rim distance gauge calibration press Press Turn the scale,let it on the main shaft, operation＞ press pull gauge to position “0” and hold, press operation＞...
  • Page 17 operation＞ Calibration finished 5.5. Radar Calibration of width gauge (No tyres need to be installed) press Press omes＞ Keep the shield in position Width gauge calibration finished 5.5.1 width compensation Tire installation required note (known tire width) A value must be entered explain＞...
  • Page 18 Press at the same time to modify the known tire width Put down the key to save automatically 5.6.Calibration of diameter gauge(Install a tire) press Press Pull the position of the transmission shaft sleeve of the ruler, keep it still, and then operation＞...

  • Page 19: Self-Calibration

    5.7 Calibration of laser (If have) press Press operation＞ keys to confirm. , the laser is aligned operation＞ operation＞ keys to confirm. operation＞ Calibration finished Self-calibration 5.81 Self-calibration of wheel balancer 5.82 Turn on balancer, install a medium size wheel (14″-18″)which can use clip-on weight, set “a b d” value, then...
  • Page 20 Do the self-calibration whenever you think the balancer is not accurate. The 100g weight must be accurate. Select the , press press Press Put down safe guard or press start spin, operation＞ after spin stop Open the safe guard and clip a 100 gram weight on the outside 12 o’clock position, put operation＞...

  • Page 21: Errors

    5.9 Unit of weight Press the key to modify Press 5.10 Unbalance display threshold Press the key to modify Press 5.11 mm/inch conversion (not saved) Press the key to modify Press 6. Errors Various abnormal conditions can arise during machined operation by the microprocessor, if comes the errors, must stop operation, find the reason and the solution according, if the error persists, consult the supplier.

  • Page 22: Opt Function

    1. Micro switch problem 1.Check or change Micro switch 2. Computer board problem 2.Check or change computer board 1. Power board problem 1.Check or change power board 2. Computer board problem 2.Check or change computer board 1. Program lost 1.Self calibration 2.
  • Page 23 Press the key, select , and comes＞ then press Put down safe guard and press comes＞ With the help of tire changer, change the rim and rubber 180 degree , press reference＞ Then put down safe guard and press comes＞ Rotate wheel until four indicators lit up (two on both sides, the dark spot reference＞...
  • Page 24 Press with the help of tire changer, change the rim and rubber to reference＞ make C and D match comes＞ If unbalance is less than before, OPT succeed Put down safe guard and press...
  • Page 25 DEKLARACJA ZGODNOŚCI WE Declaration of Conformity EC Nortec Sp. z o. o. Świerkowa 32 62-020 Rabowice, Poland Deklarujemy z całą odpowiedzialnością, że produkt Declare, undertaking sole responsibility, that the product: Wyważarka Numer seryjny WB700 Wheel balancer serial number wymieniony powyżej jest zgodny z odnośnymi wymaganiami Unijnego prawodawstwa harmonizacyjnego:...
