Page 1 Tumble Dryer / User Manual RHD2072S...
Page 2: Table Of Contents
CONTENTS 1.QUICK START....................5 2.PRIMARY CONSIDERATIONS ................6 3.DISPOSING THE OLD PRODUCT.................9 4.SAFETY INSTRUCTIONS..................10 4.1 Electrical Safety...................10 4.2 Children's Safety..................11 4.3 Product Safety....................12 5.UV RADIATION SAFETY...................14 6.CORRECT USE ....................16 7.INSTALLING ON TOP OF A WASHING MACHINE..........17 8.INSTALLATION....................18 8.1 Connection to Water Outlet (with optional drain hose).........18 8.2 Connecting the Water Drain Hose..............18 8.3 Adjusting the Feet..................
Page 3 19.1 Cleaning the Lint Filters................35 19.2 Emptying the Water Tank................35 19.3 Cleaning the Heat Exchanger...............36 19.4 Cleaning the Humidity Sensor..............36 19.5 Cleaning the Inner Surface of the Loading Door..........36 20.MACHINE SOUND..................37 21.TECHNICAL SPECIFICATIONS................38 22.TROUBLESHOOTING...................39 23.AUTOMATIC FAULT WARNINGS AND WHAT TO DO..........41 24.ENVIRONMENTAL PROTECTION AND PACKAGING INFORMATION....42 24.1 Packaging Information................42 24.2 Technical Data..................42...
Page 4: Risk Of Electric Shock
Thank you for choosing this product. This User Manual contains important safety information and instructions on the operation and maintenance of your appliance. Please take the time to read this User Manual before using your appliance and keep this book for future reference.
Page 5: Quick Start
1. QUICK START Please check the user manual for detailed information. Seperate your clothes accord�ng to the�r types, place �nto the mach�ne and close the door. Select the su�table programme for your laundry by rotat�ng the adjustment knob. You can select add�t�onal funct�ons for dry�ng. Run the programme by push�ng Start / Pause button.
Page 6: Primary Considerations
2. PRIMARY CONSIDERATIONS This appliance can be used by adults who can use it securily and aware of the risks. Children can’t play with the appliance. Cleaning and maintenance must be done only by adults. • Keep out of reach of pets •...
Page 7 • Before installation, check the product for visible damage. Never install or operate a damaged product. • Keep pets away from the dryer. • Fabric softeners or similar products should be used in accordance with the manufacturers instructions. • Remove all foreign objects from pockets such as lighters and matches.
Page 8 • The appliance must not be installed behind a lockable door, a sliding door or a door with a hinge on the opposite side of the tumble dryer, in such a way that blocks the full opening of the tumble dryer door. •...
Page 9: Disposing The Old Product
3. DISPOSING THE OLD PRODUCT This product complies with EU WEEE Directive (2012/19/EU). This product bears a classification symbol for waste electrical and electronic equipment (WEEE). This symbol, which is found on the product or information label, indicates that this product must not be disposed together with other household waste at the end of its service life.
Page 10: Safety Instructions
4. SAFETY INSTRUCTIONS This section contains safety instructions that will help protect you from risk of personal injury or property damage. Failure to follow these instructions will void any warranty. 4.1 Electrical Safety • The appliance must not be supplied through an external switching device, such as a timer, or connected to a circuit that is regularly switched on and off by a utility.
Page 11: Children's Safety
4.2 Children's Safety • This appliance can be used by adults who can use it securily and aware of the risks. • Children can’t play with the appliance. Cleaning and maintenance must be done only by adults. • Keep out of reach of pets •...
Page 12: Product Safety
4.3 Product Safety Due to risk of fire, the following laundry items and products should NEVER be dried in the dryer: • Do not dry unwashed items in the tumble dryer. • Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed in hot water with an extra amount of detergent before being...
Page 13 ATTENTION: Underwear that contains metal reinforcements should not be put in the dryer. The dryer may be damaged if metal reinforcements come loose and break off during drying. If possible, please leave the door open between cycles. FIRE: R290 Risk of fire and damage! This product contains enviromental friendly but flammable R290 gas.
Page 14: Uv Radiation Safety
5. UV RADIATION SAFETY • This warning only applies to models with Purebeam / Crystalight + Pro Technology. • The tumble dryer contains a LED that emits invisible UV-C rays. Do not look directly at the light source while the UV-C LED is operating.
Page 15 • You must not change the UV-C LED and related parts by yourself. Make sure that the machine is unplugged while waiting for the technical service personnel. • UV-C LED should not be disposed of with household waste. • Children should be kept away while programs involving Purebeam / Crystalight + Pro technology are active.
Page 16: Correct Use
6. CORRECT USE ATTENTION: Never stop a tumble dryer before the end of the drying cycle unless all items are quickly removed and spread out so that the heat is dissipated. ATTENTION: Make sure that pets do not enter the dryer. Check the inside of the dryer before using it.
Page 17: Installing On Top Of A Washing Machine
7. INSTALLING ON TOP OF A WASHING MACHINE ATTENTION: A washing machine cannot be placed on the dryer. Pay attention to the warnings below when installing the dryer on a washing machine. ATTENTION: The dryer can only be placed on washing machines that have a same capacity and above.
Page 18: Installation
8. INSTALLATION 8.4 Electrical Connection ATTENTION: There is risk of fire and electric shock. 8.1 Connection to Water Outlet (with optional drain hose) • Your dryer is set to 220-240 V and 50 Hz. In products with condenser unit, water •...
Page 19: Adjusting The Adjustable Feet
8.5 Adjusting the Adjustable Feet • Leave at least 3 cm of space between the side and rear walls of the product and the underside of the worktop when installing your product under a counter. • Assembly / disassembly under the counter if neccessary must be done by authorized service. •...
Page 20: Overview
9. OVERVIEW Upper tray Control panel Loading door Plinth Plinth opening slot Ventilation grills Adjustable feet Type plate Lint filter 10. Drawer Cover EN - 20...
Page 21: Preparing The Laundry
10. PREPARING THE LAUNDRY 10.1 Sorting the Laundry to be Dried Follow the instructions on the labels of the laundry to be dried. Only dry items that have a statement/ symbol that indicates "they can be dried in a dryer". •...
Page 22: Preparing The Laundry To Be Dried
11.1 Load Capacity IMPORTANT: Delicate fabrics, embroided Follow the instructions in the "Programme selection fabrics, woolen clothes*, silk fabrics, clothes made and consumption table". (See: 5.2 Programme of delicate and expensive fabrics, recycled fabrics, selection and consumption table). Do not load airtight clothes, tulle curtains, items made from the product with more laundry than the capacity rubber or plastics, fiberglass items, clothes with...
Page 23: Using The Tumble Dryer
12. USING THE TUMBLE DRYER 12.1 Control Panel The user interface and icons may change according to your product. Please select the one which is suitable to your product. EN - 23...
Page 24: Programme Selection Knob
12.2 Programme Selection Knob Drying Step Display: Use the programme selection knob to select the desired drying programme. Drying 12.3 Electronic Indicator and Display Iron dry Symbol Symbol Meaning Cupboard dry Water tank warning indicator Lint filter cleaning warning indicator The electronic display shows the drying steps throughout the program.
Page 25: Programme Selection And Consumption Table
13. PROGRAMME SELECTION AND CONSUMPTION TABLE Press the Start/Pause button to start the programme. The Start/Pause LED that indicates that the programme has started and the remaining the of the program is seen on the display. Washing Initial Duration Energy Consumption Programme Load (kg) machine...
Page 26: Auxiliary Functions
14. AUXILIARY FUNCTIONS The table that summarises the options that can be selected in programmes is given below. Option Description The humidity level obtained after drying can be increased by 3 levels. This way, level of Drying Level required dryness can be selected. The levels that can be selected other than the standard setting: 1, 2, 3.
Page 27: Remote Access Settings (Description Of Android And Ios Applications)
15. Remote Access Settings (description of Android and ios Applications) The Vestel Smart Life application allows you to remotely control and monitor your appliance using your smart device. In this way, you can select the appropriate program via application according to the laundry you will dry, and you can choose auxiliary options by using the additional features section.
Page 28 NOTE It is enough to introduce your machine to the Wi-Fi network once. (To connect to the Wi-Fi network, follow the instructions on the “Vestel Smart Life” application.) Before each use, you must activate the remote control by pressing the Delayed Start and Time Drying buttons simultaneously for 3 seconds. To cancel the remote control, simply press the same keys for 3 seconds simultaneously.
Page 29: Warnings Regarding Wi-Fi Mode
16. Warnings Regarding Wi-Fi Mode If you think you are experiencing any control or connection problems, perform the following. Observe if the problem persists after the operation you have performed. If you think the problem persists, take the next action. Check if the product is connected to the home network.
Page 30: Starting The Programme
17. STARTING THE PROGRAMME The Start/Pause LED will flash during programme selection.Press the Start/Pause button to start the programme. The Start/Pause LED that indicates that the programme has started and the drying LED will come on. Initial moisture Programme Description Load (kg) content (%) This programme dries thick and multi-layer fabrics, such as cotton...
Page 31 Initial moisture Programme Description Load (kg) content (%) Without providing hot air, refresh is done by selecting Time Drying Refresh option and bad odors can be eliminated. Express 34’/Express 1 kg of cotton shirts spun at a high speed in the washing machine 45’...
Page 32: Drum Light Information
*This explanation and table is valid for 17.1 Drum Light Information Woolmark certified models. Please check • The product features may change depend on your model whether “Woolmark Wool Care” the model. This information is valid for LED Drum logo is included on the facia pannel. Light included models.
Page 33: Programs Versus Options Activation Availability Table
18. Programs Versus Options Activation Availability Table EN - 33...
Page 34 EN - 34...
Page 35: Cleaning And Care
19. CLEANING AND CARE 10. Refit the Lint filter. After the dryer has been used for a certain period IMPORTANT: Do not use industrial chemicals of time, if you encounter a layer that will cause to clean your dryer. Do not use a dryer that has obstruction on the filter surface, clean the layer.
Page 36: Cleaning The Heat Exchanger
When the water tank is emptied, the warning Clean the front surface of the exchanger when indicator will go off and the program will resume. it is dry as shown with the help of a vacuum During cycling, it is recommended to use a direct cleaner.
Page 37: Machine Sound
20. MACHINE SOUND SOURCE OF SOUND DEFINITION Pump Sound Pump is activated when the machine starts to work and during the operation at certain intervals. It is normal to hear pump and water sound during this process. Compressor Sound It is normal to hear a metallic sound from the compressor from time to time while the machine is running.
Page 38: Technical Specifications
21. TECHNICAL SPECIFICATIONS Brand ROMO Model name RHD2072S Height Min: 845 mm / Max: 855 mm* Width 596 mm Depth 525 mm Capacity (max.) 7 kg** Net weight (with plastic door) 40,6 kg Net weight (with glass door) 42,1 kg...
Page 39: Troubleshooting
22. TROUBLESHOOTING Your dryer is fitted with systems that continuously perform checks during the drying process to take the necessary measures and warn you in case of any malfunction. WARNING: If the problem persists even if you have applied the steps in this section, please contact the your dealer or an Authorised Service Provider.
Page 40 The loading door might not be Make sure that the loading door closed properly. is properly closed. The programme has been There might have been a power Press the Start/Pause key to interrupted for no reason. failure. start the programme. The water tank might be full.
Page 41: Automatic Fault Warnings And What To Do
23. AUTOMATIC FAULT WARNINGS AND WHAT TO DO Your tumble dryer is equipped with a built-in fault detection system, indicated by a combination of flashing operation lights. The most common failure codes are shown below. ERROR CODE ERROR SOLUTION User Interface error Contact the nearest authorised service agent.
Page 42: Environmental Protection And Packaging Information
24. ENVIRONMENTAL 24.3 Energy Efficiency PROTECTION AND • You should operate the dryer to full capacity, PACKAGING INFORMATION but make sure that it is not overloaded. Loading up the dryer to its full capacity will contribute to energy savings. 24.1 Packaging Information •...
Page 43: Customer Care And Service
25. CUSTOMER CARE AND SERVICE Always use original spare parts. When contacting our Authorised Service Centre, ensure that you have the following data available: Model, Serial Number and Service Index. The information can be found on the rating plate. The original spare parts for some specific components are available for 10 years, based on the type of component, from the placing on the market of the last unit of the model.
Page 44 Sale of spare parts: tel: +420 599 529 250 email: servis@elmax.cz www.romocr.cz Exclusive distributor of the Romo brand for Slovakia: ELEKTRO STORE SK, s.r.o. Horná 116, 022 01 Čadca Slovenská republika Warranty and after-sales service: tel.: +421 915 473 787 email: hlaseni.reklamaci@elmax.cz...
