SERVICE MANUAL
Ver 1.0 2001.09
• MHC-S9D is composed of following models.
As for the service manual, it is issued for each component model, then, please refer to it.
COMPONENT MODEL NAME
AMPLIFIER
DVD PLAYER
TAPE PLAYER
FM STEREO, FM/AM SUPERHETERDYNE TUNER
FRONT SPEAKER
REAR SPEAKER
CENTER SPEAKER
HCR-S9D is composed of TA-S9D, DVP-S9, TC-S9, ST-S9,
SS-RS270 and SS-CT270.
SPECIFICATIONS
Power requirements
European model:
230 V AC, 50/60 Hz
Australian model:
230 – 240 V AC,
50/60 Hz
Mexican model:
120 V AC, 60 Hz
Korean model:
220 V AC, 60 Hz
Thailand model:
220 V AC, 50/60 Hz
Other models:
120 V, 220 V or
230 – 240 V AC,
50/60 Hz
Adjustable with voltage
selector
Power consumption
European model:
300 watts
0.6 watts (at the Power
Saving Mode)
Other models:
300 watts
Dimensions (w/h/d)
TA-S9D:
Approx. 280 x 128 x 350 mm
ST-S9:
Approx. 280 x 108 x 340 mm
DVP-S9:
Approx. 280 x 108 x 330 mm
TC-S9:
Approx. 280 x 128 x 330 mm
Mass
TA-S9D:
Approx. 7.7 kg
ST-S9:
Approx. 2.1 kg
DVP-S9:
Approx. 2.9 kg
TC-S9:
Approx. 2.4 kg
Supplied accessories:
AM loop antenna (1)
FM lead antenna (1)
Remote commander (1)
Batteries (2)
Speaker cords (5)
Video cable (1)
Optical cable (1)
Center and rear speaker
pads (12)
Design and specifications are subject to change
without notice.
Sony Corporation
9-873-311-01
2001I0500-1
Home Audio Company
C 2001.9
Shinagawa Tec Service Manual Production Group
MHC-S9D
PARTS LIST
MHC-S9D
Part No.
Description
TA-S9D
DVP-S9
TC-S9
ST-S9
1-476-600-11 REMOTE COMMANDER (RM-SD390AV) (AEP, UK)
1-476-758-11 REMOTE COMMANDER (RM-SD395AV)
SS-S9
SS-RS270
1-501-374-11 ANTENNA, LOOP (AM)
SS-CT270
1-501-659-71 ANTENNA (FM) (E, AUS, EA, MX, SP, TH)
1-501-804-11 ANTENNA (FM) (AEP, UK, KR)
1-574-264-11 CORD, LIGHT PLUG (OPTICAL CABLE)
1-769-306-11 CORD, SPEAKER (1.5m) (for SS-S9)
1-769-433-11 CORD, SPEAKER (10m) (for SS-RS270)
1-769-433-21 CORD, SPEAKER (2.5m) (for SS-CT270)
1-782-981-21 CORD, CONNECTION (VIDEO CABLE)
4-235-983-11 MANUAL, INSTRUCTION (ENGLISH) (UK, AUS, EA)
4-235-983-21 MANUAL, INSTRUCTION (FRENCH) (EA)
4-235-983-31 MANUAL, INSTRUCTION (SPANISH) (MX)
4-235-983-41 MANUAL, INSTRUCTION (ENGLISH, FRENCH, SPANISH)
4-235-983-51 MANUAL, INSTRUCTION (GERMAN, DUTCH, ITALIAN)
4-235-983-61 MANUAL, INSTRUCTION (SWEDISH, POLISH) (AEP)
4-235-983-71 MANUAL, INSTRUCTION (ARABIC) (EA)
4-235-983-81 MANUAL, INSTRUCTION (KOREAN) (KR)
4-235-983-91 MANUAL, INSTRUCTION (TRADITIONAL CHINESE) (SP)
4-235-984-11 MANUAL, INSTRUCTION (DANISH,FINNISH) (AEP)
4-235-984-21 MANUAL, INSTRUCTION (PORTUGUESE) (AEP)
4-235-984-31 MANUAL, INSTRUCTION (GREEK) (AEP)
4-235-984-41 MANUAL, INSTRUCTION (HUNGARIAN, CZECH) (AEP)
4-235-984-51 MANUAL, INSTRUCTION (TURKISH) (AEP)
4-235-984-61 MANUAL, INSTRUCTION (SLOVAKIAN) (AEP)
4-236-752-11 MANUAL, INSTRUCTION (ENGLISH, THAI) (TH)
4-236-961-01 FOOT (for SS-CT270/RS270)
4-232-032-01 COVER,BATTERY (for RM-SD390AV/SD395AV)
•Abbreviation
AUS : Australian model
EA
: Saudi Arabia model
KR
: Korea model
MINI Hi-Fi COMPONENT SYSTEM
HCR-S9D
AEP Model
UK Model
E Model
Australian Model
Remark
ACCESSORIES
************
(E, AUS, EA, KR, MX, SP, TH)
(AEP, E, SP)
MX
: Mexican model
SP
: Singapore model
TH
: Thailand model
(AEP)
