Product: BODY CONTROL UNIT
Model Name: BCM-E50
1. GENERAL DISCRIPTION
The SMART KEY ECU is a part of START-STOP BUTTON SYSTEM.
It is possible to output the LF(125kHz) signal by pushing the button of door handle and SSB.
This device is designed to vehicle Burglar alarm by the burglar alarm signal.
The IBU(-SMK) is controlled door actuator by the Transmitter.
The IBU(-SMK) is reset burglar alarm then receive transmitter signal and to key holder have car
key during 30secend over
2. ELECTRICAL CHARACTERISTICS
model name
Operating voltage
Dark current
Operating frequency
Modulation
Operating temperature
* This device was evaluated for RF exposure at 10cm distance in accordance with SPR-002 regulation.
Manual of BCM ECU
BCM-E50
9V ~ 16V
5mA Max.
125KHz
FSK
-40℃ ~ +85℃
