825W LED FOLLOWSPOT
Product
Updates:
V1
- FIRMWARE: V4.x
- RJ-LED2 FIRMWARE PLATFORM (Node Mode) full manual is
available for download at www.robertjuliat.com/LED/PDF_PAGE
DN41242100 (EN)
Released: 30/04/25
Robert Juliat S.A.S. 32, rue de Beaumont, F 60530 Fresnoy-en-Thelle - phone : +33 (0)3 44 26 51 89 - info@robertjuliat.fr
Angles
Standard / CE
7 - 14,5°
www.robertjuliat.com
North American
1189
1189C
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Robert Juliat Tristan
Summary of Contents for Robert Juliat Tristan
- Page 1 - RJ-LED2 FIRMWARE PLATFORM (Node Mode) full manual is available for download at www.robertjuliat.com/LED/PDF_PAGE DN41242100 (EN) Released: 30/04/25 Robert Juliat S.A.S. 32, rue de Beaumont, F 60530 Fresnoy-en-Thelle - phone : +33 (0)3 44 26 51 89 - info@robertjuliat.fr www.robertjuliat.com...
-
Page 2: Table Of Contents
4.6.3.3 Disable local ..................25 4.6.3.4 Reset......................26 4.7 Gobo .........................26 4.7.1 Range ........................26 4.7.2 Control ........................26 Robert Juliat reserves the right to change or alter any of the items detailed on this page, to increase or improve manufacturing techniques without prior notice. -
Page 3: User's Instructions
Maybe harmful to the eye. 2.7 m (8.86 ft) 40 m (131.23 ft) Risk group 2. Luminaires should be positioned so that prolonged staring into luminaire at a distance closer than 2.7 m is not expected. EN - 1 - Tristan 1189 Manual DN41241900... -
Page 4: Presentation
Frost glass 23. Remote display connector 10. Spare filter 24. Accessory connectors (x2) 11. Gobo slot 25. 1/4" Accessory mounting 12. Local display 26. Safety cable attachment point 13. Keypad 14. Identification plate EN - 2 - Tristan 1189 Manual DN41241900... -
Page 5: Identification Label
(North American version) DN41242200 Quick Start manual PF1011 Ø210 mm metal filter holder (x6) SGUP2 Universal "A" size gobo-holder (metal & glass) VDM100 Ø100 mm frosted glass with holder M270/2B 6-way "boomerang" colour changer EN - 3 - Tristan 1189 Manual DN41241900... -
Page 6: Accessories
One-function remote controller (with rotary potentiometer) - Ethernet connector P1FE-L1 One-function remote controller (with linear potentiometer) - Ethernet connector Followspot balancing kit (including 1 Kg counterweights) - Weight: 2.05 Kg DMXcat Bluetooth DMX/RDM Multifunction test tool - City Theatrical DMXcat® EN - 4 - Tristan 1189 Manual DN41241900... -
Page 7: Set-Up
Use lifting rings • Net weight: 39 Kg (116.6 Ibs) Lifting ring DIN 580 M8 Overhead view ( x4 Not supplied) 3.1.5 Safety cable • Safety cable attachment point Safety cable not supplied. EN - 5 - Tristan 1189 Manual DN41241900... -
Page 8: Stand Set-Up
3.1.6 Stand set-up The unit must be installed only on a Robert Juliat compatible stand / head : Monopod stand for overhead followspot GT4000 Tripod stand with safety chain - SWL: 130 Kg - max. height: 1030 mm GT4000S Tripod stand without safety chain - SWL: 130 Kg - max. height: 1030 mm... -
Page 9: Electrical Information
3G1.5 CEE7/7 Neutral: Blue Neutrik® version H07RNF 9.8 ft Ground: Yellow/Green powerCON TRUE1 TOP North 14AWG Live: Black 1.5 m NAC3FX-W-TOP American SJ TYPE Neutral: White 4.9 ft version (UL/CSA) Ground: Green EN - 7 - Tristan 1189 Manual DN41241900... -
Page 10: Data
DMX (+) 2nd conductor of 1st twisted pair Not used 1st conductor of 2nd twisted pair Not used 2nd conductor of 2nd twisted pair Daisy chain: Maximum : 32 units total Lighting desk EN - 8 - Tristan 1189 Manual DN41241900... -
Page 11: Art-Net / Sacn / Dual
(see Web Interface section of the manual). - Web interface is always available regardless of the protocol (Art-Net/sACN) selected. RJ-LED2 FIRMWARE PLATFORM (Node Mode) full manual is available for download at www.robertjuliat.com/LED/PDF_PAGE EN - 9 - Tristan 1189 Manual DN41241900... -
Page 12: Accessories
3.4 Accessories 3.4.1 Colour changer unit - boomerang Dimensions Cf. 4.8.1 EN - 10 - Tristan 1189 Manual DN41241900... -
Page 13: Colour Changer Unit - Push-Pull (Option)
3.4.2 Colour changer unit - push-pull (option) Dimensions Cf. 4.8.1 EN - 11 - Tristan 1189 Manual DN41241900... -
Page 14: Gobo Holder
3.4.3 Gobo holder 'A' size gobo Dimensions Cf. 4.7.1 3.4.4 Frost / Correction filter Dimensions Cf. 4.9.1 EN - 12 - Tristan 1189 Manual DN41241900... -
Page 15: Internal Glass Holder 120 X 120 Mm
3.4.5 Internal glass holder 120 x 120 mm 3.4.6 Remote controls P1FE-R1 P1FE-L1 1/4"-20 inserts 1/4"-20 inserts EN - 13 - Tristan 1189 Manual DN41241900... -
Page 16: Remote Display
3.4.7 Remote display R-DISPE1 1/4" screw 1/4"-20 inserts M4 inserts for Clear-Com® BP-MOUNT 3.4.8 Top accessory plate PSA1 1/4" screws (x2 included) 3/8"-16 inserts 1/4"-20 inserts EN - 14 - Tristan 1189 Manual DN41241900... -
Page 17: Double Slot Front Cassette For 215 X 215 Mm Accessories
3.4.9 Double slot front cassette for 215 x 215 mm accessories 3.4.10 Counterweight EN - 15 - Tristan 1189 Manual DN41241900... -
Page 18: Telrad Followspot Sight
Caution: - Do not install the followspot sight on the lamp house to avoid blocking the ventilation vents. - Secure the sight with a suitable safety cable. 3.4.12 RJ cable strap (accessory) EN - 16 - Tristan 1189 Manual DN41241900... -
Page 19: Flight-Case
3.4.13 Flight-case Inner side view Inner overhead view EN - 17 - Tristan 1189 Manual DN41241900... -
Page 20: Operations
Light output is the highest value selection in SETUP / DIMMER / PATCH Local control - Back Local control - Front* With remote controls P1FE-R1 P1FE-L1 Included Included Optional accessories (*) By default EN - 18 - Tristan 1189 Manual DN41241900... -
Page 21: Parameters
By using this function, it is possible to obtain synchronised fades with several spots or to give intensity limits (minimum and maximum) to the operator. Master is only active when DMX is detected. EN - 19 - Tristan 1189 Manual DN41241900... -
Page 22: Set Maximum Position
255 = 20ms 0 = OFF 1 = 1ms Strobe speed 0 = 0.1Hz 255 = 10Hz 4.2.2 Control DMX512-A Remotely with DMX512-A / Art-Net / sACN protocols 2, 3 & 4 Mode EN - 20 - Tristan 1189 Manual DN41241900... -
Page 23: Response Time
STANDALONE DMX512-A / Art-Net / sACN protocols 2, 3 & 4 Mode DMX 512-A / Art-Net / sACN protocols Mode 1 selection in SETUP / DIMMER / RESPONSE TIME (or HOME VALUE) EN - 21 - Tristan 1189 Manual DN41241900... -
Page 24: Beam Size Adjustment
4.4 Beam size adjustment 4.4.1 Range Beam angle Field angle Model Angles Minimum angle Maximum angle Beam angle 7,1° 13,6° TRISTAN 1189 & 1189C Field angle 7,3° 14,7° 4.4.2 Control ZOOM FOCUS ZOOM FOCUS EN - 22 - Tristan 1189 Manual DN41241900... -
Page 25: Pan / Tilt
4.5 Pan / Tilt 4.5.1 Range Function Range 0 T 360° TILT 71° 50° 50° 50° 50° 71° Standard position Suspended position Heavy duty adjustable yoke (option) 4.5.2 Control Lock Unlock EN - 23 - Tristan 1189 Manual DN41241900... -
Page 26: Iris
Light output is the highest value selection in SETUP / DIMMER / PATCH Local control - Back* Local control - Front With remote controls P1FE-L1 P1FE-R1 Included Included Optional accessories (*) By default EN - 24 - Tristan 1189 Manual DN41241900... -
Page 27: Parameters
Open iris Closed iris 4.6.3.3 Disable local selection through SETUP / LOCAL POTENTIOMETER / IRIS / SETUP / DISABLE "Control Mode" channel IRIS LOCAL ON IRIS LOCAL OFF P1FE-R1 P1FE-L1 P1FE-R1 P1FE-L1 EN - 25 - Tristan 1189 Manual DN41241900... -
Page 28: Reset
SETUP / IRIS / RESET 4.7 Gobo 4.7.1 Range Type Standard gobo - A size Ø100 mm Ø72 mm • Metal Dimensions Maximum • Glass image size Installation Cf. section: 3.4.4 4.7.2 Control EN - 26 - Tristan 1189 Manual DN41241900... -
Page 29: Colour
Type Coloured gel filter Ø210 mm Dimension Cf. section: 3.4.2 & section 3.4.3 Installation Place dark colours towards the front end. 4.8.2 Control Unlock = release colours Colour engaged Push / Pull EN - 27 - Tristan 1189 Manual DN41241900... -
Page 30: Frost And Correction Filters
4.9 Frost and correction filters 4.9.1 Range Type Frost or Correction filter Ø97 mm Dimension Installation Cf. section: 3.4.6 4.9.2 Control Frost glass Spare filter EN - 28 - Tristan 1189 Manual DN41241900... -
Page 31: Controls And Parameters
DHCP : OFF 192.168.000.013 Network information MASK 255.255.255.000 192.168.000.001 x1 push DUAL OFF RDM : ON Channel: 001 SACN UNi: 1 DMX information PROFILE 16B x2 push 000% Followspot Mode IRIS 000% x2 push EN - 29 - Tristan 1189 Manual DN41241900... -
Page 32: Menus
• RDM • FIXTURE ID • TERMINATOR • NODE POWER SUPPLY • VALUES CONTROL • BACK • FRONT • ACCESSORY PORT 1 TEMPERATURES • ACCESSORY PORT 2 • VALUES COOLING • MODE EXPERT EN - 30 - Tristan 1189 Manual DN41241900... -
Page 33: Parameters
ON, select : SETUP DISPLAY AUTO OFF Always ON Always on Auto-OFF Timer without warning Timer with warning Timer without warning press OK to validate Main display turns OFF after 20 seconds EN - 31 - Tristan 1189 Manual DN41241900... -
Page 34: Dmx512 - A Remote Control
Press OK PROFILE Start address: 00 1 to validate DMX address of the unit from 1 to 512 DATA MODE Personality Press OK PROTOCOL PERSONALITY DMX ADDI Press OK to validate to validate EN - 32 - Tristan 1189 Manual DN41241900... -
Page 35: Parameters
– Once defined, the User ID is displayed on the Home screen. Example: Installation with 6 units Home screen ID1 @ 101 ID2 @ 123 ID3 @ 145 ID4 @ 167 ID5 @ 189 ID6 @ 211 information User ID DMX address EN - 33 - Tristan 1189 Manual DN41241900... -
Page 36: Dmx Chart
5.2.5.2 Strobe speed Range min Range max Function Frequency: 0,1 Hz T 10 Hz 5.2.5.3 Response time Range min Range max Function 470 ms (medium) Response time: 0 s T 4 s EN - 34 - Tristan 1189 Manual DN41241900... -
Page 37: Control Mode
(*) Function activated after 5 seconds - needs to go back to zero to activate second function. 5.2.5.5 Iris Range min Range max Function Iris open Open T Closed Iris closed 5.2.5.6 Iris mode Range min Range max Function Fast Medium Slow None Not used (= Fast) EN - 35 - Tristan 1189 Manual DN41241900... -
Page 38: Rdm Remote Control
✔ ✔ ✔ ✔ 04 00 04 01 LAMP_HOURS E1.20 ✔ ✔ ✔ ✔ ✔ ✔ Display Settings 05 01 DISPLAY_LEVEL E1.20 ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ EN - 36 - Tristan 1189 Manual DN41241900... - Page 39 ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ 85 74 DMX_ERROR_COUNTER_DESCRIPTION E1.20 ✔ ✔ ✔ ✔ 85 75 DMX_ERROR_COUNTER E1.20 ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ EN - 37 - Tristan 1189 Manual DN41241900...
-
Page 40: Home Values
- sACN - See section 5.4.2 - Dual: Sacn + Art-RDM (DMX512 data signal + RDM) - See section 5.4.3 From July 2024 the Robert Juliat equipment based on RJ LED2 platform is configured as follows: - DHCP (Dynamic Host Configuration Protocol - RFC1531) ON https://www.rfc-editor.org/rfc/rfc1531... - Page 41 Most personal computers are configured with DHCP and Zeroconf enabled, so the IP address defaults to 169.254.X.X with a subnet mask of 255.255.0.0. When connected to a Robert Juliat device, since the IP address/mask range are in the same class, network communication works seamlessly.
-
Page 42: Art-Net Remote Control
Set mode through Web interface Local control (see 5.9 Web interface) protocol compatible device 1 - If necessary, change IP settings 2 - Set Art-Net Universe 3 - Set DMX address 2 - Set personality mode (see 5.2.4. DMX chart) EN - 40 - Tristan 1189 Manual DN41241900... -
Page 43: Local Set-Up
DHCP: ON or OFF to validate IP address of the unit DATA MODE IP CONFIG IP-ADDRESS DATA MODE IP CONFIG Address 192.168.000.0 1 3 press OK press OK DHCP ADDRESS MASK to validate to validate EN - 41 - Tristan 1189 Manual DN41241900... -
Page 44: Sacn Remote Control
Set mode through Web interface Set through local control (see 5.9 Web interface) 1 - If necessary, change IP settings 2 - Set sACN universe 3 - Set DMX address 2 - Set personality mode (see 5.2.4. DMX chart) EN - 42 - Tristan 1189 Manual DN41241900... -
Page 45: Local Set-Up
DHCP: ON or OFF to validate IP address of the unit DATA MODE IP CONFIG IP-ADDRESS DATA MODE IP CONFIG Address 192.168.000.0 1 3 press OK DHCP ADDRESS MASK press OK to validate to validate EN - 43 - Tristan 1189 Manual DN41241900... -
Page 46: Dual Remote Control
Set through local control Set mode through Web interface (see 5.9 Web interface) 1 - If necessary, change IP settings 2 - Set DUAL universe 3 - Set DMX address 4 - Set personality mode (see 5.2.4. DMX chart) EN - 44 - Tristan 1189 Manual DN41241900... -
Page 47: Local Set-Up
DHCP: ON or OFF to validate IP address of the unit DATA MODE IP CONFIG IP-ADDRESS DATA MODE IP CONFIG Address 192.168.000.0 1 3 press OK press OK DHCP ADDRESS MASK to validate to validate EN - 45 - Tristan 1189 Manual DN41241900... -
Page 48: Web Interface
SETUP Page EXPERT Page, password-protected (1280). NODE Page UID* list of devices detected by RDM on the DMX OUT link; (*) UID : RDM Unique Identifier the first UID is the fixture. EN - 46 - Tristan 1189 Manual DN41241900... -
Page 49: Llrp (Low-Level Reader Protocol)
In summary, LLRP simplifies the process of identifying and configuring the IP addressing of LLRP-compatible devices on your network. All Robert Juliat equipment based on the RJ LED2 platform includes LLRP functionality. Two LLRP Manager software tools are available for free: DMXworkshop by Wayne Howell from Singularity (UK): https://singularity-uk.com/product/dmx-workshop/... -
Page 50: Fan Cooling Modes
Minimum – constant speed Regulated – depending on ambiant NORMAL temperature FULL Maximum – constant speed 5.5.2 Control DMX512-A Remotely by DMX512-A Locally T selection in SETUP / COOLING Mode 2, 3 & 4 EN - 48 - Tristan 1189 Manual DN41241900... -
Page 51: Local Potentiometer
Invert (CCW): Anticlockwise Adjust to the minimum position Calibration Press OK to validate SETUP CONTROL SETUP CONTROL CALIB Calibration ROTATION CALIBRATION Adjust to the maximum position Press OK SETUP CONTROL CALIB to validate EN - 49 - Tristan 1189 Manual DN41241900... -
Page 52: Service
• Contact a certified RJ distributor in case of residuals or other objects located on the surface of the LED source. 6.1.5 Optics Only use solutions containing alcohol to clean optical parts (lenses). Lens tube access EN - 50 - Tristan 1189 Manual DN41241900... - Page 53 • Dry with a soft lint-free cloth. Removing the LED housing cover: 1 Clean external parts only Lens holder Remove the 4 screws Clean lens Clean lens EN - 51 - Tristan 1189 Manual DN41241900...
-
Page 54: Analysis
In case of overheating, light intensity will be reduced by the system. “Power reduction X%” will be shown on the display with the reducing percentage. 6.4 Firmware update 1. Firmware available on www.robertjuliat.com/followspots/Tristan 2. Download and unzip the file There are 4 files: - Firmware (.upd2 format) -
Page 55: Factory Defaults
(SELFTEST). dmxo If the problem persists, please take a photo of the test result and send it either to your Robert Juliat dealer or to the Robert Juliat After-Sales Service, if requested (email: service@robertjuliat.fr) EN - 53 -...
