Quickstart Guide
Nighthunter C35
Thermographic Camera
Thank you for choosing this product. Please read this Guide carefully
before use and keep it properly for future reference.
Pictures for reference only, please refer to the actual product you
receive.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Nighthunter C35 and is the answer not in the manual?

Questions and answers

Summary of Contents for Steiner Nighthunter C35

  • Page 1 Quickstart Guide Nighthunter C35 Thermographic Camera Thank you for choosing this product. Please read this Guide carefully before use and keep it properly for future reference. Pictures for reference only, please refer to the actual product you receive.

  • Page 2: Table Of Contents

    - CONTENTS - IMPORTANT NOTES ..............1 FCC WARNING..............2 PRECAUTIONS ..............4 LIST OF PARTS ..............7 INTRODUCTION TO PRODUCT PARTS ........8 QUICKSTART INSTRUCTIONS ..........9 COMMON TROUBLESHOOTING GUIDE ........16 STORAGE AND TRANSPORTATION ........17...

  • Page 3: Important Notes

    - IMPORTANT NOTES - This Guide is a general guide for a series of products, which means that the specific model you receive may differ from the pictures in this Guide. Please refer to the actual product you receive. This Guide is organized for the convenience of users to use and understand our products.

  • Page 4: Fcc Warning

    - FCC WARNING - This equipment may generate or use radio frequency energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the instruction manual. The user could lose the authority to operate this equipment if an unauthorized change or modification is made.
  • Page 5 there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: •...

  • Page 6: Precautions

    - PRECAUTIONS - DANGER 1) Please charge the battery with the method described in this Guide and follow the charging procedure and precautions. Improper battery charging will cause heating, damage and even physical injury; 2) Do not try to open or disassemble the battery at any time.
  • Page 7 accessories to avoid damage; 6) Do not disassemble the machine by yourself, which may cause device damage and loss of warranty rights; 7) Do not use soluble or similar liquids on device and cables, which may cause damage to the device; 8) Please do not use the device in an environment that exceeds the operating temperature of the device, which may cause damage to the device;...
  • Page 8 environment or close to high-temperature objects; 11) Do not short circuit the positive and negative poles of the battery; 12) Do not put the battery in wet environment or water. NOTES: 1) Do not expose the device to dust or moisture. Avoid water splashing to the device when being used in an environment with water.

  • Page 9: List Of Parts

    - LIST OF PARTS - Plug of Chinese, American, British, Australian, European standard 18650 charger 5V2A adapter Type-C cable Two-in-one video cable...

  • Page 10: Introduction To Product Parts

    - INTRODUCTION TO PRODUCT PARTS - POWER BUTTON FOCUSING RING BATTERY BOX...

  • Page 11: Quickstart Instructions

    - QUICKSTART INSTRUCTIONS - Current Device Buttons Short Press Long Press Status Power on Compensation Open menu Power button Power off Power on Display off Display on Display on Focusing button Power on Current Device Rotate Rotate Buttons Status Clockwise Anticlockwise Power on Photo...
  • Page 12 · Power off Enter menu and select “Power Settings”, and short press the Power button to display the shutdown progress bar until the progress bar is completed and the shutdown is successful. · Display off Enter menu and select “Power Settings”, and short press the Power button to display the shutdown progress bar.
  • Page 13 · Exit menu When it is turned on and the menu is called up, long press the Power button to back to the real-time interface without saving. · Take photos Rotate the Power button clockwise to take photos. · Take videos Rotate the Power button anticlockwise to start video recording, and rotate the Power button anticlockwise again to stop video recording and save the video.

  • Page 14: Function Description

    【FUNCTION DESCRIPTION】 · PIP: PIP can be switched among four states: upper left, upper middle, upper right and off. · Screen brightness: The screen brightness can be adjusted from level 1 to 10. · Hotspot tracking: A white crosshair will be displayed when it is enabled to track the spot with the highest temperature on the entire map.
  • Page 15 compensation. · WIFI: WIFI switch. When the mobile client and the device are connected, real-time videos can be transmitted to the mobile phone, the device can be operated through the APP. · Rough ranging: Go to the rough ranging interface and rotate the Power button clockwise/anticlockwise to move the upper horizontal line up and down.
  • Page 16 · Time settings: The device time and date can be adjusted in the time adjustment interface. · Language settings: The device support 5 languages: English/German/French/Italian/Spanish. · Memory card formatting: All files in the memory card can be deleted. · Restore default: The default values of the device can be restored, and then the device will automatically restart and the language guide interface appears.
  • Page 17 · Capacity indication When the thermographic camera is turned on and the battery capacity changes, the capacity indicator is displayed in the middle of the screen, and the part of the lit power indicator shows the remaining battery capacity. After starting up and entering the real-time screen, the icon corresponding to the above power capacity will be displayed in the middle of the screen.

  • Page 18: Common Troubleshooting Guide

    - COMMON TROUBLESHOOTING GUIDE - 1. The device cannot be powered on Solution: replace the battery or connect the adapter for power supply 2. The device cannot take photos/videos Solution: the internal storage space of the device is full. It is needed to format the memory card or disconnect the device from the computer 3.

  • Page 19: Storage And Transportation

    - STORAGE AND TRANSPORTATION - Storage: 1. The storage environment of packaged products is -30℃~60℃, the relative humidity is not more than 95%, without condensation and corrosive gas, and is well ventilated and clean indoor; 2. Please take it out and charge it every 3 months. Transportation: The thermographic camera shall be protected from rain, water, inversion, violent vibration and impact during...
  • Page 20 Special statement: The version of the Guide will be updated after the technical improvement of the product.
