Page 1 PSI-X-HPAB-S ADAPTER BOX User Manual...
Page 2 It is specified that the technical data, information and representations reported in this document maintain a purely indicative value. Peimar reserves the right to modify the data, drawings and information contained in this document at any time and without notice.
Page 5: Table Of Contents
3.3. Appearance description ................11 Electrical Connection ..............14 4.1. Connection of the RS485_INV Port ............15 4.1.1 Cable connection of RS485_INV port (PSI-X-HPAB-S side) ..15 4.1.2 Cable connection of the inverter side .........16 4.1.3 LCD setting on the inverter ............20 4.2.
Page 6: Overview Of Psi-X-Hpab-S
Overview of PSI-X-HPAB-S 1.1. Introduction PSI-X-HPAB-S, with 4 dry contact and 1 analog signal channels, can control devices that support these types of signals. In the field of photovoltaic system, it controls related devices based on the amount of surplus energy, battery SOC and preset system schedules.
Page 7: Application Scenarios
2 external dry contacts. See table 2-1 below for details. After connected to the PSI-X-HPAB-S through D1 and COM ports, the heat pump will switch its operation mode between the Normal State and Recommended On State.
Page 8: Control Through Dry Contact Signal
4 dry contacts. Users can set the heat pump to work at different steps from 0 to 15 on Peimar X portal, and configure each step based on their needs for control precision. For details on configuration, see 5 Configuration of APP.
Page 9: Control Through Analog Signal
PSI-X-HPAB-S supports a voltage range of 0 V -10 V. Users can divide the voltage range into 16 operating steps for the heat pump. For details on configuration, see 5 Configuration of APP.
Page 10: Installation
Check if there is any distortion or damage during transportation. If there is any damage or items missing, please contact the dealer. Specifications Quantity PSI-X-HPAB-S Self-tapping screws Expansion tubes 5 pin male pluggable terminal block 2 pin male pluggable terminal block...
Page 11: Appearance Description
3.3. Appearance description Step 1 Use a marking cardboard to locate the holes and drill them on the wall. • Drill holes with a Φ 6 drill; • Depth: at least 30 mm. 105 mm Step 2 Put the expansion tubes in the holes and tighten them with a hammer. Step 3...
Page 12 Dismantle the top cover of the PSI-X-HPAB-S. • Cross-shaped screwdriver torque: 1 N·m Step 4 Pass self-tapping screws through the channels in the four corners of the box and screw them tightly. • Self-tapping screws Torque: 1.5±0.1 N·m.
Page 13 PLEASE NOTE • Choose a place where the PSI-X-HPAB-S is not directly exposed to the sun and close to the heat pump. • The PSI-X-HPAB-S needs to be installed horizontally. Please refer to picture in step 4 for the right installation method of the adapter box.
Page 14: Electrical Connection
Electrical Connection The figure below introduces the ports the PSI-X-HPAB-S, which shall be connected to the ports of a heat pump and an inverter. 485_INV RS485_INV Dry contact RS485 other devices Analog output power adapter Inverter PSI-X-HPAB-S Heat Pump Port description of the PSI-X-HPAB-S No.
Page 15: Connection Of The Rs485_Inv Port
PLEASE NOTE Pin 3 and pin 6 of RS485_INV port and a power adapter both can supply power for the PSI-X-HPAB-S, and users can choose one to get PSI-X-HPAB-S powered. 4.1. Connection of the RS485_INV Port Functions of the RS485_INV port a) communication between the PSI-X-HPAB-S and the inverter.
Page 16: Cable Connection Of The Inverter Side
PSI-X-HPAB-S. For further matching questions of other Peimar inverters, please contact us for help before installation. Here is an introduction to the port of inverters supplying power for the PSI-X-HPAB-S. a) PSI-X1P-HY and PSI-X3S-HY series inverters. PSI-X1P-HY and PSI-X3S-HY series inverters support power for the PSI-X-...
Page 17 • COM Pin Definition of X1/PSI-X3S-HY series. +13 V RS485-A RS485-B b) PSI-X3P-TP series inverters. PSI-X3P-TP series inverters support power for the PSI-X-HPAB-S through RS485 port of the inverter. • RS485 Pin Definition of PSI-X3P-TP series +12 V RS485-A RS485-B...
Page 18 PARALLEL_485BB d) PSI-X3P-TPM series inverters PSI-X3P-TPM inverter series provide power for the PSI-X-HPAB-S through RS485 port. • RS485 Definition of PSI-X3P-TPM series 485A 485B e) PSI-X1S-TL series inverters PSI-X1S-TL inverter series provides power for the PSI-X-HPAB-S through the RS485 port.
Page 19 PSI-X1S-TLM series inverters PSI-X1S-TLM inverter series provide power for the PSI-X-HPAB-S through RS485 port. • COM Pin Definition of PSI-X1S-TLM series 485_A 485_B g) PSI-X1P-TLS series inverters PSI-X1P-TLS inverter series provides power for the PSI-X-HPAB-S through the RS485 port.
Page 20: Lcd Setting On The Inverter
14/16 RS485A RS485B When the inverter and the PSI-X-HPAB-S are well connected, users need to enable the RS485 communication with the PSI-X-HPAB-S in the settings of the inverter. PLEASE NOTE A splitter can be used if the communication port of the inverter is occupied.
Page 21 >Internal485 >Function Control >Baud Rate PSI-X-HPAB-S 9600 ==Internal485== ==Internal485== > > >PSI-X-HPAB-S Addr >PSI-X-HPAB-S COM STAT Connected d) Setting steps on PSI-X3P-TP series inverters > Export Control > Mode Select > > DRM function Meter > PSI-X-HPAB-S > Mode Select >...
Page 22: Connection Of The Rs485 Port
4.3. Connection of the Power Adapter Port (Optional) Function of a power adapter A power adapter is optional for the power supply of the PSI-X-HPAB-S. If the inverter matched cannot supply power for the PSI-X-HPAB-S, a power adapter is needed.
Page 23: Connection Of The Ao Port
Step 2 Check the rubber stopper without cable threading through are with plugs and then screw the waterproof connector tightly. 4.4. Connection of the AO Port AO Port Pin Definition AO1 (0 V - 10 V) PLEASE NOTE Open ports without cable threading through must be plugged to prevent water. And reserve a proper length of all connected cables in the box to reduce its pulling force for connected terminals.
Page 24 2 pin male pluggable terminal block Step 4 Plug the male pluggable terminal block with cables into the female pluggable terminal block fixed in the PSI-X-HPAB-S and screw them tightly. flat-blade screwdriver blade width: 3 mm Torque: 0.4 N·m female...
Page 25: Connection Of The Do Port
Step 5 Screw the waterproof connector tightly, align the recessed part of the top cover with the protrusion of the box and lock the top cover. cross-shaped protrusion of recessed part screwdriver the box of the top cover Torque: 1 N·m PLEASE NOTE Please refer to the manual of a heat pump for how the other end of the cable is connected to the heat pump.
Page 26 Step 3 Insert the cables with terminals into the male pluggable terminal block, screw them tightly. Insert the male pluggable terminal block with cables into the female pluggable terminal block fixed in the PSI-X-HPAB-S. 5 pin male female pluggable pluggable...
Page 27 Insert the cables with terminals into the male pluggable terminal block, screw them tightly. Insert the male pluggable terminal block with cables into the DO1 and COM port if the female pluggable terminal block fixed in the PSI-X-HPAB-S. flat-shaped screwdriver blade width: 3 mm Torque: 0.5 N·m...
Page 28 PLEASE NOTE Please refer to the manual of a heat pump for how the other end of the cable is connected to the heat pump.
Page 29: Operation On Peimar X Portal
The heat pump has been correctly set based on its external control mode. 5.1. Downloading and Installing App Scan the QR code below to download the App or search for the keyword “Peimar X portal” in App store to download the Monitoring App.
Page 30: Adding Plant And Network Configuration
5.2. Adding Plant and Network Configuration Step 1 Tap the icon “+” and fill the basic information to add a plant. Step 2 Tap Add to add the PSI-X-HPAB-S by scan the QR code or enter the registration number on the device.
Page 31 Confirm the device and configure the network. After successful configuration, PSI-X-HPAB-S will display on this device page. You can add a new device by tapping the “+” on the upper right corner. Tap on the PSI-X-HPAB-S to enter the device details page.
Page 32: Settings For The Psi-X-Hpab-S
5.3. Settings for the PSI-X-HPAB-S This details page include device name, device connection status, online status, select mode, load management, remote settings, and view the operating status. These will be detailed below. PLEASE NOTE When adapter box is offline, you cannot set the mode, cannot click the loads in the load list to enter the load details interface, you cannot add new loads, the Operating status is not displayed, and you cannot enter the remote setting interface.
Page 33: Settings For The Psi-X-Hpab-S
5.3.1 Settings for the PSI-X-HPAB-S Tap the PSI-X-HPAB-S to enter the following page of basic information of the device, including SN number, Registration no., Device model, Access time, Firmware version and Remove device button. Tap the icon “pencil“, you can modify the device name.
Page 34 • Reverse gear: This is to prevent the heat pump from remaining working at the preset gear after PSI-X-HPAB-S is disconnected from the inverter, which might cause extra usage of the grid power. When the connection method is DO or AO, the selectable range of the reverse gear is 0 to the maximum gear of the gear setting;...
Page 35 The following describes the interface of the three different connection methods. DO Connection method Tap Go to settings to enter the gear settings page, and tap “+” on the upper right corner of the page to add gears. D1-D4 correspond to 4bits of binary, with 0 and 1 to form 0-15 gears. DO port selection of each gear can not be repeated.
Page 36 • Heat Pump: Load name. Tap to enter the following page of basic information of the load, including Load type, Load ID, Load model, Communication method, Load rated power and Remove device button. Tap the icon “pencil“, you can modify the load name. •...
Page 37 When selecting Smart mode, tap the icon “pencil“ and then set the gear you want the load to be applied to when in manual mode. It is also supports to modify or add or delete gears for all gears. Modifications here will also be synchronized to the gears in smart mode.
Page 38 AO Connection method After selecting the AO Connection method, you can set 0-15 steps by sliding the progress bar., and tap Confirm to save the setting. After the setting is completed, the load information part is the same as selecting the DO connection method, but the interface of the mode setting is different, as shown as follows.
Page 39 SG ready Connection method In this connection, the dry contact control the default DO1 port and up to 4 port. When Signal ON Condition is met, DO1 port outputs signal; when Signal OFF Condition is met, DO1 port outputs signal off. Signal ON Condition: When set to and, both Threshold on Feed in power and Threshold of battery SOC need to satisfy the input value, and when set to or, only one of them needs to satisfy the input value.
Page 40 DO1 port will try to close and run after 30 seconds. • When the PSI-X-HPAB-S is connected to the inverter, and the inverter is connected to the battery with the battery turned on, the Threshold of battery SOC and "and/or”...
Page 41: Remote Setting
5.3.4 Remote Setting Tap the Remote settings to enter the following page, this page includes Switch, Grid data source, Timing. • Switch: Manual switch to control the load. Default ON. • Grid data source: Inverter or Electric meter can be selected.
Page 42 • Timing: Tap Timing to enter the following Timing setting page, and tap Create for the first time. PLEASE NOTE The range of Start time and End time should be at 00:00-23:59 and the End time must be later than the Start time. The Timing setting has the highest priority and controls the operation of the PSI-X- HPAB-S.
Page 44: Operating Status
5.3.5 Operating Status When the PSI-X-HPAB-S is online, you can tap the Operating status to enter the following page, this page displays the switching status of the 4 dry contact, the output voltage and the current gear of the load.
Page 45: Technical Data
Technical Data Product Name PSI-X-HPAB-S Product Name PSI-X-HPAB-S Max. Dry Contact 2 A 30 V d.c./ 0.5 A 230V a.c. x 4 Analog Output 0 - 10 Vdc Rated Input Voltage 9 - 14 Vdc Idle Power 0.5 W Rated Power EIRP Power 17.46 dBm (Measured Max.
