We really appreciate for your purchasing our ICEVAN.
◇ Please read and understand the user's manual carefully to take full advantage of the various and convenient functions of the
product.
◇ Please check the model you purchased before installing and using the product.
◇ Please read this manual carefully and keep it well as it contains important contents for the installer / user when installing the
product and using & managing it safely.
◇ You can remote control the product through communication.
User's Manual
For ICEVAN NID series
▣ ICEVAN Series
□ NID-0320B T3
□ NID-0520B T3
□ NID-0820B T3
□ NID-0840B T3
□ NID-1220B T3
□ NID-1240B T3
□ NID-1520B T3
□ NID-1540B T3
Korea Nakajo Co., Ltd
Advertisement
Table of Contents
Related Manuals for Korea Nakajo ICEVAN Series
Summary of Contents for Korea Nakajo ICEVAN Series
- Page 1 Korea Nakajo Co., Ltd User’s Manual For ICEVAN NID series ▣ ICEVAN Series □ NID-0320B T3 □ NID-0520B T3 □ NID-0820B T3 □ NID-0840B T3 □ NID-1220B T3 □ NID-1240B T3 □ NID-1520B T3 □ NID-1540B T3 We really appreciate for your purchasing our ICEVAN.
-
Page 2: Table Of Contents
Contents 1. For your Safety 2. Components of the machine 3. Installation and precautions 8~12 - Installation environment 8~10 - Supply and drain of water 11~12 4. How to use 13~14 5. Operation 15~19 - Function of selecting button - Starting the machine - Setup panel (FND) - Setting the function code 18~19... -
Page 3: For Your Safety
1. For Your Safety Waring indicates a potential danger which , if not avoided, will result in death Warning or serious injury. Caution indicates a hazardous situation which , if not avoided, could result in minor Cautions or moderate injury as well as damage to the property. Warning ▶... - Page 4 ▶ Do not touch the power plug with wet hand. ● There is a possibility of electric shock and fire. ▶ Always hold the body part of the plug. ● There is a possibility of fire due to the spark. ●...
- Page 5 Cautions ▶ Please pass this user’s manual together with the ice machine when it is transferred or moved to the others. ● This manual will be required to use the product safely. ▶ Do not put objects on the top of the ice machine. ●...
-
Page 6: Components Of The Machine 6~7
2. Components of Ice machine Upper Front case cover Front cover Power lamp Air vent Outlet Outlet lever Water receiver Discharge hose (cup support) Drain body Drain pipe Front view Side view Power switch Setup panel Set display Air exhaust Mode setup *Customers need to Dispense time adjusting button... - Page 7 2.1 Dimensions Dimension (㎜) Model Weight Name (㎏) NID-0320B T3 35Kg 40 ㎏ NID – 0520B T3 42 ㎏ NID – 0820B T3 47 ㎏ NID - 0840B T3 NID - 1220B T3 53 ㎏ NID - 1520B T3 NID - 1240B T3 58 ㎏...
-
Page 8: Installation And Precautions 8~12
3. Installation and precautions Installation environment ▶ Please keep two people in balance and do not tilt when moving the ice machine. ● This can be the cause of malfunction due to the shaking and noise. ● Be careful not to impact the product. ▶... - Page 9 ▶ Secure the space for the installation of the ice machine. 50cm ● Narrow space can be the cause of malfunction of the ice machine. Please follow the recommended standard for the checkup and management. [Recommended standard: Height – over 50㎝ Left &...
- Page 10 Caution! ★ Parts will be damaged if the ice maker is operated in the place where there is freezing risk! ★ When operating the ice maker, always keep the ambient temperature above 10℃! ★ Wait until the ambient temperature is above 10℃ and turn off the power, then the error will be cleared.
-
Page 11: Supply And Drain Of Water 11~12
Supply and drain of water ▶ Please check the water pressure before connect the water supply fit. Water pressure : 1~4Kgf/㎠ should be maintained When water pressure is low : use pressurizing pump (water flow: 1.5~2.0ℓ/min, Pressure: 1~4㎏f/㎠ pressure type operation pump is recommended) When water pressure is high : Use decompression valve when the pressure is higher than 4㎏f/㎠... - Page 12 ▶ Install the drain hose so that water can be drained smoothly. ● Be care so that the drain hose should not be installed lower than the drain out-let. ※ Overflowed water may cause a risk of malfunction, electric shock and property damage. ▶...
-
Page 13: How To Use
4. How to use Summary for the correct use of ice machine. ▶ Front cover ● Release the knob bolt and open the cover. ▶ Water supplying valve ● Check whether the water supply hose and drain hose are connected properly. ●... - Page 14 4. How to use the ice machine ▶ Power switch operation ● Lift up the power switch to “ON” position. ● Setup panel and power lamp will be turned on when power is supplied ※ Circuit breaker is to prevent the electric shock due to the short circuit.) ▶...
-
Page 15: Operation 15~19
5. Operation Summary The icemaker can be used as a standalone device or in conjunction with coffee machine. Only use clean and hygienic water (5~30 c) Function of selecting button ▶ When using “ICE” mode Ice will be dispensed if dispensing lever is pushed without any operation. Factory preset mode is “ICE”. -
Page 16: Starting The Machine
Starting the Machine ▶ Starting ice cube production If the temperature ranges specified in the Technical data are not observed, the ice cube production quantity may be reduced and faults may occur. Ice cube production starts after three automatic drainage procedures. As soon as the ice cube collecting container inside the device is full, ice cube production is stopped automatically. -
Page 17: Setup Panel (Fnd)
Setup panel (FND) Setup panel Display window: Displays the function, status value by each function, setup value within the function etc. Change button (function, setup value): Function and setup value changing button Select button: Function access, enter the changing setup value, return to the standby screen ▶... -
Page 18: Setting The Function Code 18~19
Setting the Function Code ● F0 (Dispenser standard type setup) Ex: [ 01: Ice dispense + Water dispense] Operation Operation Operation sequence button Push and hold “Select” button for 3 seconds. Push “Change” button and select “F0”. Existing setup value will be displayed if you push “Select” button once briefly. (factory default 00) Push “Change”... - Page 19 ● F8~F9 (Function to check the time of use of the ice machine) Ex : [ F8: Actual accumulated operation time of Geared Motor] Operation Operation Operation sequence button Push and hold “Select” button for 3 seconds. Push “Change” button and select “F8”. If you push “Select”...
-
Page 20: Cleaning Method 20~21
6. Cleaning method ※ Following is the must to be obeyed. Do not use abrasive powder, powder soap, oil, loofah, acid, thinner, benzene, or alkaline detergent as they may damage the paint or plastic. • Please use the cleaning agent and disinfectant after checking the precautions on the label of each product container. -
Page 21: Cleaning Cycle
▶Cleaning method 1) Loosen the bolt and open the 2) Push the lever and dispense the ice. front cover. 4) Clean the outlet area. 3) Turn off the power switch. Clean the outlet and front area with dishcloth 5) Remove the vessel support and clean. 6) Wipe off the cleaned area with clean dishcloth. -
Page 22: Measures For Stopping For A Long Time
7. Measures when stopped for a long time ▶ Obey the instruction below when not dispensing ice without turning off the power When without turning of the power 1) Dispense and waste at least 5 cups of ice on a regular basis (once a day) 2) Do not store the ice in the storage for longer than 1 week left. -
Page 23: Trouble Shooting
8. Trouble Shooting ※ Please check the followings first in case any problem occurs during operation of the ice machine. If the symptom is not resolved in spite of following counter actions, please contact with the purchased place for the help. Please provide following information when requesting the service. -
Page 24: Error Code
9. Error Code ※ Three front selection button lamps blink at the same time, and the ERROR indication code appears on the display window as follows. Error code Description of error Counter actions Check the connection of the water supply pipe and also check whether there is outage of water supply. -
Page 25: Parts List To Be Replaced On A Regular Basis
10. Parts list to be replaced on a regular basis Agitator Storage tank Mechanical seal Cutter ※ Be sure to replace the cutter and mechanical seal according to the replacement cycle (request to the purchased place) - Replacement cycle varies depends on the water quality, installation condition and operation rate. - We recommend beforehand checkup and maintenance. -
Page 26: Technical Data
11. Technical Data NID-0520B T3 Model Name NID-0320B T3 NID-0820B T3 NID-0840B T3 Manufacturer Korea Nakajo Co., Ltd Product Name Ice Dispenser Ice Machine Electrical safety Electrical Certification No. appliances safety Electromagnetic certification Dimension (W) * (D) * (H) (W) * (D) * (H) - Page 27 11.1 Technical Data Model Name NID-1240B T3 NID-1540B T3 NID-1220B T3 NID-1520B T3 Manufacturer Korea Nakajo Co., Ltd Product Name Ice Dispenser Ice Machine Electrical safety JH07789-20001 Electrical Certification No. appliances safety Electromagnetic R-R-K0N-NID-1520BT3WR certification (W) * (D) * (H)
-
Page 28: Check List
12. Check List ※ Once the installation is completed, check the items listed in the check list to see if there is any problem and put the check mark in the box [ V ] and sign on the check list and keep it. Check Check point Remarks... -
Page 29: Warranty
13. Warranty ※ Conditions of free of charge For the malfunctions in performance or function that occurs under the normal use within the warranty period ※ Paid Maintenance Service cost will be charged for the following cases even within the warranty period. When malfunction or damage occurred due to user's carelessness (moving, dropping, impact, excessive operation, etc.) after installation When malfunction occurs due to the disassembly of the product by the person other than the... - Page 30 Date of sale Name: Phone No.: Customer Address: Name: Phone No.: Sales Office Address: ■ Manufacturer : Korea Nakajo Co., Ltd ■ Salesperson : WWW.icevan.co.kr Address: 65, Yongdu-ro, Daegot-myeon, Gimpo-si, Contact No. : Gyeonggi-do, Republic of Korea Installed by: (031) 998-0671...
- Page 31 ■ Manufacturer : Korea Nakajo Co., Ltd 65 Yongdu-ro, Daegot-myeon, Gimpo-si, Gyeonggi-do 〶 10038 TEL : +82 - 31 - 998 - 0671 FAX : +82 - 31 - 998 - 0644 www.icevan.co.kr ■ First released date : 2020. 03. 24...
