Summary of Contents for MTF Lotta
- Page 1 Infrared sauna Lotta INSTALLATION AND USE INSTRUCTIONS 09/2024 Sauna: Discover the magic of relaxation and health...
-
Page 2: Safety Instructions
Thank you for choosing our infrared sauna and congratulations on your purchase. We are confident that your whole family will enjoy everything this product has to offer and that you will enjoy using it for years to come. Read this manual carefully and in detail before using the sauna for the first time. We recommend that you retain this manual for regular review and future reference. - Page 3 6. Warning: Do not touch the heaters while the sauna is in use; their temperature exceeds 70 °C and contact with their surface can cause burns. Do not cover the heaters, there is a risk of fire. When the sauna is in use, do not touch the outer part of the walls in the area of the heaters - they can be very hot, there is a risk of burns.
- Page 4 18. Dry your hands before inserting or removing the plug from the power circuit. Never touch the cable with wet hands or wet bare feet to avoid the risk of electric shock. Do not touch the metal terminals of the outlet or the plug of the power cord with your fingers. 19.
- Page 5 for them, the use of an infrared sauna is safe and beneficial to their health, the body temperature in children rises noticeably faster than in adults, and their ability to thermoregulate with the help of sweating is not yet as developed as in adults. Similarly, the ability to maintain optimal body temperature and the function of sweat glands decrease with age, so caution should be exercised in both of these age groups and infrared therapy should be discussed with your doctor.
-
Page 6: Product Presentation
PRODUCT PRESENTATION An infrared sauna (infrasauna) consists of a wooden cabin, infrared heating elements made of carbon fibers, a control system and an ionizer. Wooden cabin includes BOTTOM PLATE, TOP PLATE, LEFT PLATE, RIGHT PLATE, BACK PLATE, FRONT GLASS PLATE + DOOR, PLATE WITH BENCH HEATERS, BENCH SIDE PARTS, BENCH SEATS. 1. -
Page 7: Control Box
CONTROL BOX The control box is the control center of the sauna. It is mounted on the TOP PLATE, during assembly it is only necessary to connect the appropriate cable ends. HAZARD OF INJURY High Voltage, ELECTRICAL don't Open CURRENT, DO NOT OPEN CONNECTING CLAPS ASSEMBLY INSTRUCTIONS Please read the instruction manual carefully before installation. - Page 8 2) We recommend placing the sauna in a room with an air temperature of at least 15 °C. The external ambient temperature directly affects the internal temperature of the sauna. If you place the sauna in a cold environment, the internal temperature in the sauna will not reach the specified maximum values.
- Page 9 A. Place the BOTTOM PLATE Place the BOTTOM PLATE on the place where the infrared sauna will stand. Pay attention to the correct location, the cables of the floor heater are in the back of the infrared sauna. B. Place the BACK PLATE Place the BACK PLATE in the back of the floor - slide it in.
- Page 10 D. Install BENCHES WITH HEATERS Use the guide rails to place the heaters under the seat of the benches. Plug the cables from the floor heater and the cables from the heater under the bench into the sockets on the side walls. In the guide groove on the front face of the bench, insert the side part of the bench and finally place the bench seats.
- Page 11 F. Fitting the FRONT GLASS PLATE THE FRONT GLASS PLATE consists of a right glass panel with prepared holes for door hinges, a left glass panel and a glass door. Insert the right glass panel into the guide grooves in the right wall, ceiling and floor (the ceiling must be raised).
- Page 12 H. Connecting the plugs on the TOP PLATE After fitting the TOP PLATE, proceed to connect all the cable connections. You always connect the same cable ends. Note: Do not plug the power cord from the TOP PLATE into the power supply during installation. I.
- Page 13 INFRA SAUNA CONTROL To start, you need to connect the sauna to the socket with a cable, after which the control switches over panel to standby mode (the Power light is on on the control panel). The button is used to turn it on and turning off the infrared sauna.
- Page 14 IONIZER CONTROL The ozone generator creates O3 and disinfects the interior of the infrared sauna. The ionizer generates negative ions and creates fragrant and fresh air. Both devices can only work separately. Ozone, used primarily to destroy viruses, bacteria and fungi, has an important function for the human body - it oxygenates the blood, improves blood circulation and stimulates the production of oxygen in human tissues.
- Page 15 WHAT ARE INFRARED RAYS (IR) An infrared ray is actually an electromagnetic wave that lies between the wavelength range of visible light and the microwave range. This beam is similar to the natural rays from the sun that help warm our skin with direct IR even during cold days.
- Page 16 HOW TO USE THE INFRA SAUNA 1. You can best use the potential of infrared therapy if you set the temperature to the highest value. During the entire sauna, your body will use the full power of infrared radiation. If you set the temperature to a lower value, the heaters will continuously turn off and on again to maintain the set temperature.
- Page 17 CARE OF YOUR SAUNA It is very important to clean the sauna regularly: - sweep or vacuum the floor, or benches - wipe down walls where people have touched them - i.e. above benches, around doors and control panels - use warm water with a mild soapy detergent and a clean cloth, then wipe with a clean damp cloth –...
-
Page 18: Important Notice
IMPORTANT NOTICE The infrared rays emitted by your infrared sauna are recognized as a tool that offers a wide range of possible therapeutic benefits and effects, as evidenced by research conducted in various parts of the world. These benefits are presented here for reference purposes only and are not intended to imply that infrared saunas constitute a cure or cure for any disease, nor should such inferences be drawn from such statements. - Page 19 ERROR LOCATION PROBLEM SOLUTION 1. Check if the sauna is properly 1. Sauna does not work, control panel nothing connected to the electrical supply energy. does not display. 2. Check the cable plugs properly connected and secured. 3. Check the current fuse, if applicable replace it.
-
Page 20: Sound Signaling
SOUND SIGNALING Some types of saunas may have a self-check feature that only works when is something unusual. Types of self-monitoring alarms: control box malfunction - contact an authorized service 2 long beeps every 2 seconds 1 long beep every 2 seconds loose temperature sensor wire the temperature of the control box is higher than 80 °C, reduce... - Page 21 WARRANTY CONDITIONS, SERVICE AND SPARE PARTS The warranty period is stated on the sales document, but at least 24 months, and begins on the day of receipt of the product, which must be proven with the original sales document. The warranty applies to defects that the product has upon receipt, as well as to demonstrable manufacturing defects that occur during the warranty period.
- Page 24 Mountfield a.s., Mirošovická 697, mountfield-export.com 251 64 Mnichovice...
