Sonic Impact S100 delivers support for up to four speakers, phenomenal 3D positional audio, powerful PC performance and compatibility. Designed for those who demand high fidelity audio at an affordable price, the Sonic Impact S100 is by far the best value in PC audio today!
Page 4
® ⇒ Accelerates Microsoft’s DirectSound , DirectSound3D (with 16 Sensasura streams), Aureal’s A3D™ 1.0, EAX 1.0 and I3D Level 2. To ensure optimal operating system support, the Sonic Impact S100 accelerates Microsoft's ® Windows 95/98 and Windows 2000 (when available).
NSTALLING THE S100 ONIC MPACT This chapter provides an overview of the Sonic Impact S100 hardware and instructions on the Sonic Impact S100 hardware and software installation. ♦ G ENERAL YSTEM EQUIREMENTS ♦ H ARDWARE NSTALLATION ♦ S OFTWARE NSTALLATION ♦...
Contents Your Sonic Impact S100 kit includes the Sonic Impact S100 card, installation CD, CD audio cable, and additional software applications. To make the Sonic Impact S100 installation proceed smoothly, install the Sonic Impact S100 hardware, install the software drivers from the installation CD disk, and then install the optional software.
Page 7
2. 6. If your computer has a CD-ROM or DVD-ROM drive, connect the CD-ROM audio cable to the internal connector labeled CD In on your Sonic Impact S100 card. 7. Reattach any previously removed cables. Next, attach any external speaker(s), joystick, and microphone connections to the Sonic Impact S100 card.
OFTWARE NSTALLATION Now that you have installed your new Sonic Impact S100 digital audio accelerator card and rebooted your computer, complete the installation using the following directions. There are two ways to install the software for your Sonic Impact S100: ♦...
Page 9
3. You are offered several search options. Select the Specify a location check box. 4. Insert the Sonic Impact S100 Installation CD into your CD-ROM drive and set the path in the install window to D:\Win9X\English\Drivers (or replace D with the letter that corresponds to your CD-ROM drive).
Page 10
D with the letter that corresponds to your CD-ROM drive). You can also click Browse and navigate to your CD-ROM. 3. Windows 95 now copies the Sonic Impact S100 driver files to your hard drive. Click OK. 4. You may be requested to reboot your computer. If so, please restart your computer now—leaving the installation CD in the CD-ROM drive.
2. Insert the Sonic Impact S100 Installation CD into your CD-ROM drive and set the path in the install window to D:\Win9X\English\Drivers (or replace D with the letter that corresponds to your CD-ROM drive). You can also click Browse and navigate to your CD-ROM drive.
Sonic Impact S100 card. ARDWARE The Sonic Impact S100 card provides a number of ways for you to connect external devices such as headphones, microphones, speakers, and MIDI devices (keyboard). The following illustration describes the Sonic Impact S100 audio card connectors.
Attach your headphones to the Line Out connector only. MIDI Output The Sonic Impact S100 card can output and accept General MIDI data from your PC to external MIDI-compatible devices. Use your favorite music software to control MIDI devices through the Sonic Impact S100 card. You can also use the powerful, built-in Sonic Impact S100 wavetable to produce concert quality instrumental music directly from music software.
Page 14
To configure for the PC/PCI hardware implementation, you must connect one end of the PC/PCI cable to connector JP7 (PC/PCI) on the Sonic Impact S100 card, and the other end to the PC/PCI connector on your motherboard. Please consult the motherboard documentation for information on where to locate the PC/PCI cable and connector on your motherboard.
Q & A ENERAL Why am I prompted for the Windows 98/95 CD when installing Sonic Impact S100? The reason Windows 98/95 prompts you for the CD is because it needs one or more of Windows system components that are not installed on your system. These are typically audio components that are required when using Sonic Impact S100.
PDATING RIVERS Diamond publishes periodic updates to the drivers for Diamond hardware installed on your system. These updates address various issues from overall product performance enhancements, to software upgrades and other improvements. PDATE IZARD Diamond makes it easy for you to update your Diamond hardware drivers with its Update Wizard.
S3/D ONTACTING IAMOND Worldwide Support and Information Services Service Country Phone / Internet Address Technical Support (541) 967-2450 S3/Diamond Multimedia Systems, Inc. 7101 Supra Drive SW Albany, OR. 97321 +44-1189-4444-44 Germany +49-8151-266-330 France +33-1-55 38 16 16 Japan +81-(0)3-5695-8405 Email Support customersupport@diamondmm.com...
PECIFICATIONS Operating System Support ♦ Windows 98/95 and Windows 2000 (when available) ♦ Real-mode MS-DOS API Compatibility ♦ DirectSound, DirectSound3D, and DirectInput ♦ DirectMusic ♦ A3D version 1.0 ♦ MacroFX ♦ EAX 1.0 ♦ I3DL2 (reverb API) Minimum System Requirements ♦...
LOSSARY OF ERMS ONIC MPACT LOSSARY An API for handling 3D positional sounds and Doppler effects. Using algorithms developed for NASA, A3D is able to simulate 3D positional sounds on two speakers. A3D will support four or more speakers, but is optimized for two. DS3D Microsoft’s 3D audio API helps game developers define where sound should be placed in the 3D space and how loud it should be.
Page 21
MacroFX Creates special close-up 3D “near-field proximity effects,” so that sounds seem to be very close to the game player (i.e., whispering in the ear, wind noises and ultra close fly-by). ™ MultiDrive Sensaura's 3D positional audio technology that incorporates a patented multi- speaker capability for creating 3D sound fields using four or more loudspeakers.
S3/Diamond or an authorized S3/Diamond agent. This warranty applies only to the original purchaser of the Sonic Impact S100 kit and is not transferable. This warranty does not cover any incompatibilities due to the user’s computer, hardware, software or any other related system configuration in which Sonic Impact S100 interfaces.
Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Contact S3/Diamond Multimedia Systems, Inc., 7101 Supra Drive SW, Albany OR 97321. Technical Support tel: 541-967-2450. This device complies with Part 15 of the FCC Rules.
