Summary of Contents for iSinwheel V10
-
Page 2: Table Of Contents
Contents INTRODUCTION SAFETY INSTRUCTIONS PACKAGE CONTENTS PRODUCT OVERVIEW REMOTE CONTROL SETTINGS BATTERY & CHARGING INSTRUCTIONS SPECIFICATIONS CLEANING & STORAGE DISPOSAL CONTACT US... -
Page 3: Introduction
INTRODUCTION Before riding this electric skateboard, read all the information in this user manual. Keep the manual for future reference. This manual includes operating instructions, useful tips, and important safety instructions on the use and handling of the product. The manufacturer is not responsible or liable for any damage or injuries caused by inappropriate use or mishandling of this product. -
Page 4: Weight Limit
Weight Limit Please note that the product has a weight limit of 264 lbs. Overloading may lead to damage and injuries. Protection Level The product has a protection level of IP54 to prevent intrusion of solid objects (limited protection against dust) and provide protection from water splashing against the housing. IMPORTANT: The protection rating is not permanent and can decrease over time as a result of everyday usage of the product. -
Page 5: Package Contents
PACKAGE CONTENTS Electric Skateboard x1 (Wheels NOT Pre-installed) 2 in 1 USB C LED Light Bar x2 Spare Loop Fastener Cable for Light (Built-in Rechargeable Wheel x4 for Light Bars x2 Bars x1 Battery) Remote Control x1 USB C Cable Tool Kit x1 (Built-in Rechargeable Charger x1... -
Page 6: Product Overview
PRODUCT OVERVIEW Front Wheels Motors Rear Wheels Deck Power Button (Press to turn on/off the skateboard) Battery Compartment Charging Port Side LED Light Bars... -
Page 7: Remote Control
REMOTE CONTROL Thumbwheel Function button Power button Buttons Power button: Hold for about 2 seconds to turn on or off the remote control. Function button: Press to switch the riding mode. Thumbwheel: Push forward to accelerate, release to slow down, and pull back to brake. -
Page 8: Settings
Brake Force: 1, 2, 3, and 4 (Press the Function button while pulling back the thumbwheel to switch the brake force.) Moving Direction: Forward and Backward (Double press to switch directions) Battery Level of Remote: 4 Bars (100%-75%); 3 Bars (75%-50%);... -
Page 9: Battery & Charging Instructions
BATTERY & CHARGING INSTRUCTIONS Battery Instructions when the battery indicator bar flashes. battery. skateboard! Otherwise, it will affect its lifespan. Skateboard Charging Steps 1. Open the rubber cover of the charging port. 2. Plug the round DC connector of the charger into the charging port. 3. -
Page 10: Specifications
SPECIFICATIONS SPEC V10 Electric Skateboard Weight 26.5 LBS Size 43.9*12.6*6 IN. Power 1,500 W *2 Motor Belt Motors Load capacity 264 LBS Maximum range¹ 28 MILES Maximum incline Protection class IP54 Wheel 6” Honeycomb Solid Rubber Tires Deck 37” Long (8 Ply Maple, 1 Ply Bamboo, 1 Ply Fiber Glass) - Page 11 Charger Input AC 110-240 V, 50/60 Hz Output 50.4 V, 2.0 A Charging Time 6-7 H Charging Temperature 0°F ~ 100°F / 0°C ~ 40°C Remote 2.4 GHz Frequency Battery 300 mAh 1. About the range: The range on one charge depends on many factors. Proper mainte- nance and handling as well as moderate riding speed will maximize the range.
-
Page 12: Cleaning & Storage
- Risk of fire hazards. DISPOSAL The V10 electric skateboard, LED light bars, and the remote all contain a built-in battery, so they should not be disposed of with other household waste at the end of their lifespan. -
Page 13: Fcc Statement
FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
